PG-F200X
OPERATION MANUAL
[1] Specifications
Model
Display device
Resolution
Lens
F number
Zoom
Focus
Input terminal
DVI-D (Compatible with HDCP)
RGB/Component (mini D-sub 15 pin)
S-Video (mini DIN 4 pin)
Video (RCA)
Audio ( φ3.5 mm stereo minijack)
Audio (RCA)
Output terminal
RGB/Component (mini D-sub 15 pin)
Audio (φ3.5 mm stereo minijack)
Control, others
USB (Type B)
RS-232C (mini DIN 9 pin)
Speaker
Projection lamp
Rated voltage
Rated frequency
Input current
Power consumption (Standby)
Operation temperature
Cabinet
Dimensions (main body only)
Weight (approx.)
As a part of policy of continuous improvement, SHARP reserves the right to make design and
specification changes for product improvement without prior notice. The performance specifica-
tion figures indicated are nominal values of production units. There may be some deviations from
these values in individual units.
Service Manual
PG-F200X
0.55" DLP
Chip
R
XGA (1024 x 768)
F 2.5 - 2.6
Manual, x1.15 (f = 20.4 - 23.5 mm)
Manual
x1
x1
x1
x1
x1
x1 (L/R)
x1
x1
x1
x1
2 W (Mono)
200 W
AC 100 - 240 V
50/60 Hz
2.9 A
283 W (4.3 W) with AC 100 V
270 W (4.4 W) with AC 240 V
41°F to 95°F (+5°C to +35°C)
Plastic
41
33
10
/
" x 3
/
" x 10
64
64
(270 (W) x 89 (H) x 265 (D) mm)
6.4 lbs. (2.9 kg)
1 – 1
