TopPage
In the interests of user-safety (Required by safety regulations in some countries) the set should be restored
to its original condition and only parts identical to those specified should be used.
[1]
Specifications ......................................... . ....... 1-1
[2]
Parts Name and Basic Operation........... . ....... 1-2
[3]
DIMENSIONS ........................................ . ....... 1-8
[4]
Regarding the lamp................................ . ....... 1-9
[1]
[2]
Removing the top body .......................... . ....... 2-1
[3]
PWB unit ................................................ . ....... 2-2
[4]
supply ballast unit................................... . ....... 2-2
[5]
R/C receiver PWB unit ........................... . ....... 2-3
[6]
[1]
THE OPTICAL UNIT OUTLINE.............. . ....... 3-1
[1]
ELECTRICAL ADJUSTMENT................ . ....... 4-1
[2]
Adjustment mode process menu............ . ....... 4-4
[1]
TROUBLESHOOTING TABLE............... . ....... 5-1
Parts marked with "
" are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the
safety and performance of the set.
SERVICE MANUAL
DATA PROJECTOR
MODEL
CONTENTS
[1]
MAJOR IC INFORMATION............................6-1
[1]
BLOCK DIAGRAM.........................................7-1
[2]
OVERALL WIRING DIAGRAM ......................7-3
[1]
MAIN Unit ......................................................8-1
[2]
DMD Unit .......................................................8-9
[3]
BALLAST POWER Unit............................... 8-11
[4]
BALLAST CONTROL Unit...........................8-17
[5]
PHOTO SENSOR Unit ................................8-19
[6]
R/C RECEIVER Unit....................................8-20
[7]
TERMINAL Unit ...........................................8-21
[8]
CAP Unit......................................................8-22
CHAPTER 9. WAVEFORMS
[1]
WAVEFORMS ...............................................9-1
CHAPTER 10. SCHEMATIC DIAGRAM
[1]
DESCRIPTION OF SCHEMATIC DIA-
GRAM..........................................................10-1
[2]
SCHEMATIC DIAGRAM ..............................10-2
No. S87P4PG-F320W
PG-F320W
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
PG-F320W
xxxxxxxxx

Advertisement

Table of Contents
loading

Related Manuals for Sharp PG-F320W

Summary of Contents for Sharp PG-F320W

  • Page 1: Table Of Contents

    TopPage PG-F320W xxxxxxxxx SERVICE MANUAL No. S87P4PG-F320W DATA PROJECTOR PG-F320W MODEL In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its original condition and only parts identical to those specified should be used.
