LG800G Quick Start Guide
• Depending on the software installed or your service provider or
country, some of the descriptions in this guide may not match your
phone exactly.
• Depending on your country, your phone and accessories may
appear different from the picture in this guide.
Bluetooth QD ID B000000 P/N: MMBB0000000 (1.0)
Phone Components
Volume keys
• When the screen is at the Home screen:
Ring tone and touch tone volume.
• During a call: Earpiece volume.
• Down volume key: Press and hold to
activate/ deactivate Silent mode.
Power/Lock key
• Short press to turn on/off the screen.
• Long press for power on/off.
Handsfree or Stereo earphone
connector
*Many of the features and services described are network dependent and may require
additional subscription and/or usage charges. Not all features are available for purchase
or use in all areas. Other conditions and restrictions may apply. See carrier for more
information.
© 2010 LG Electronics, Inc.
Using your touch screen
Touch screen tips
• To select an item, touch the centre of the icon.
• Do not press too hard. The touchscreen is sensitive enough to pick up a
light, firm touch.
• Use the tip of your finger to touch the option you require. Be careful not
to touch any other keys.
• Whenever your LG800G is not in use, it will return to the lock screen.
Control the touch screen
The controls on the LG800G touch screen change dynamically
depending on the task you are carrying out.
Installing the SIM card and the handset battery
Installing the SIM Card Illustrations
When you subscribe to a cellular Always switch the device off and
network, you are provided with disconnect the charger before
a plug-in SIM card loaded with removing the battery.
your subscription details, such as
1 Remove the back cover.
your PIN, any optional services
available and many others.
Important!
The plug-in SIM card and its
contacts can be easily damaged
by scratches or bending, so be
careful when handling, inserting
or removing the card. Keep all SIM
cards out of the reach of small
children.
2 Lift battery away.
Calls
Making a Call
1 Touch to open the keypad.
2 Key in the number using the keypad.
3 Touch
to initiate the call.
TIP! To enter + for making an international call, press and hold
.
0 +
Press the power key to lock the touchscreen to prevent calls being made
by mistake.
Making a call from your contacts
1 From the home screen touch to open the Contacts.
2 Tap the Name field box on the top of the screen and enter the first few
letters of the contact you would like to call using the keypad.
3 From the filtered list, touch the Call icon next to the contact you want
to call. The call will use the default number if there is more than one
for that contact.
4 Or, you can touch the contact name and select the number to use if
there is more than one for that contact to use. You can also touch
to initiate the call to the default number.
Answering and rejecting a call
When your phone rings, press key to answer the call.
To mute the ringing, touch on Silent tab in alerting screen. This is useful
if you forgot to change your profile to Silent for a meeting. Touch on
Reject tab to reject an incoming call in alerting screen.
Installing the SIM card and the handset battery
3 Insert the SIM card. 5 Attach the back cover.
6 Charge the battery.
4 Insert the battery pack.
Calls
Changing the common setting
1 Touch Call in the Settings menu.
2 Scroll and touch Common settings.
• Call reject - Slide the switch left for ON. You can touch the Reject list to
choose All calls, Contacts, Groups, All unknown callers and All unknown
numbers.
• Send my number - Choose whether to display your number on an
outgoing call.
• Auto-redial - Slide the switch left for ON or right for OFF.
• Answer mode
Press send key: Allows you to only answer an incoming call by
pressing the key.
Press any key: Allows you to answer an incoming call by pressing any
key, except the key.
• Minute minder - Slide the switch left to ON to hear a tone every
minute during a call.
• BT answer mode - Select Handsfree to be able to answer a call using a
Bluetooth headset, or select Handset to press a handset key to answer
a call.
• Save new number - Select ON or OFF to save a new number.
Phone Components
Earpiece
Call key
Dials a phone number and
answers incoming calls.
Clear key
Go back to a previous screen.
End key
Contacts
Searching for a contact
1 Touch Contacts.
2 You see a list of contacts. Typing in the first letter of a contact's name
in the Name field will jump the menu to that alphabetical area of the
list.
Adding a new contact
1 Touch Contacts and touch Add.
2 Choose whether to save the contact to your Internal memory or SIM.
3 Enter your first and last name.
4 You can enter up to five different numbers per contact.
5 Add an email addresses. You can enter up to two different email
addresses per contact.
6 Assign the contact to one or more groups.
7 Touch Save to save the contact.
