Summary of Contents for IBM Netfinity 5100

  • Page 1: Installation Guide

    ® ® Netfinity 5100 Installation Guide...
  • Page 3 ® ® Netfinity 5100 Installation Guide...
  • Page 4 © COPYRIGHT INTERNATIONAL BUSINESS MACHINES CORPORATION, 2000. All rights reserved. Note to U.S. Government Users — Documentation related to restricted rights — Use, duplication or disclosure is subject to restrictions set forth in GSA ADP Schedule Contract with IBM Corp.
  • Page 5: Table Of Contents

    Notices used in this book ......3 Major components of the Netfinity 5100 server ..4 Warranty Statements .
  • Page 6 IBM® Netfinity® 5100 Installation Guide...
  • Page 7: Safety

    Avant de procéder à l'installation de ce produit, lisez le manuel Safety Information. Vor Beginn der Installation die Broschüre mit Sicherheitshinweisen lesen. Przed zainstalowaniem tego produktu należy przeczytać broszurę Informacje Dotyczące Bezpieczeństwa. Prima di installare questo prodotto, leggere l'opuscolo contenente le informazioni sulla sicurezza. © Copyright IBM Corp. 2000...
  • Page 8 Preden namestite ta izdelek, preberite knjižico Varnostne informacije. Antes de instalar este producto, lea la Información de Seguridad. Läs säkerhetsinformationen innan du installerar den här produkten. Installálás el tt olvassa el a Biztonsági el írások kézikönyvét ! IBM® Netfinity® 5100 Installation Guide...
  • Page 9 Safety Statement 1 Danger Electrical current from power, telephone, and communication cables is hazardous. To avoid a shock hazard: • Do not connect or disconnect any cables or perform installation, maintenance, or reconfiguration of this product during an electrical storm. •...
  • Page 10 Statement 2 CAUTION: When replacing the lithium battery, use only IBM Part Number 33F8354 or an equivalent type battery recommended by the manufacturer. If your system has a module containing a lithium battery, replace it only with the same module type made by the same manufacturer.
  • Page 11 Safety Statement 4 ≥18 kg (37 lbs) ≥32 kg (70.5 lbs) ≥55 kg (121.2 lbs) CAUTION: Use safe practices when lifting. Statement 5 CAUTION: The power control button on the device and the power switch on the power supply do not turn off the electrical current supplied to the device. The device also might have more than one power cord.
  • Page 12 Safety IBM® Netfinity® 5100 Installation Guide...
  • Page 13: Chapter 1.Introduction

    Your server comes with a three-year limited warranty and 90-Day IBM Start Up Support. If you have access to the World Wide Web, you can obtain up-to-date information about your Netfinity 5100 model and other IBM server products at the following World Wide Web address: http://www.ibm.com/pc/us/netfinity/...
  • Page 14: Features And Specifications

    Features and specifications Table 1 provides a summary of the features and specifications for your Netfinity 5100 server. Microprocessor: Video: Environment: • Intel® Pentium® III • S3 video controller (integrated on • Air temperature: microprocessor with system board) — Server on: 10° to 35° C MMX™...
  • Page 15: Notices Used In This Book

    Notices used in this book This information product contains notices that relate to a specific topic. The Caution and Danger notices also appear in the multilingual safety booklet that came with your Netfinity product. Each notice is numbered for easy reference to the corresponding notices in the safety booklet.
  • Page 16: Major Components Of The Netfinity 5100 Server

    Major components of the Netfinity 5100 server The orange color on components and labels in your server identifies hot-swap components. This means that you can install or remove the component while the system is running, provided that your system is configured to support this function.
  • Page 17: Chapter 2.Installing Options

    This section is for all users, but is written with the experienced user in mind. If you need more detailed installation information, refer to the User’s Reference on the IBM Netfinity Documentation CD. Working with adapters p t e r s...
  • Page 18: Adapter Considerations

    To change the boot precedence for PCI devices, start the Configuration/Setup Utility program, and select Start Options from the main menu. Refer to the User’s Reference on the IBM Netfinity Documentation CD for details on using the Configuration/Setup Utility program.
  • Page 19 For details on handling these devices, refer to the following Web site and use a search term of ESD: http://www.ibm.com/ 1. Review the safety precautions listed in “Safety” on page v. 2. Turn off the server and peripheral devices and disconnect all external cables and power cords.
  • Page 20: Installing Memory Modules

    1. Install additional DIMMs in the order specified in the documentation that comes with your option. (See the following illustration for memory connector locations.) 2. Your Netfinity 5100 server supports 128MB, 256MB, 512MB, and 1GB DIMMs. Your server supports a maximum of 4GB of system memory. See the ServerProven list at http://www.ibm.com/pc/compat for a list of memory...
  • Page 21: Installing A Hot-Swap Drive

    Note: Refer to the User’s Reference on the IBM Netfinity Documentation CD for information on installing devices in the non-hot-swap bays. Refer to the following illustration to install a hot-swap drive.
  • Page 22: Installing A Microprocessor

    Microprocessor internal clock frequencies and external clock frequencies must be identical. See the ServerProven list at http://www.ibm.com/pc/netfinity for a list of microprocessors for use with your server. Note: The illustrations in this document might differ slightly from your hardware.
  • Page 23: Installing A Power Supply

    If you install an optional power supply in this bay, LED PS1 on the system board diagnostics panel refers to this power supply. See the User’s Reference on the IBM Netfinity Documentation CD for the location of the PS1 LED. Power supply bay 2 If you install an optional power supply in this bay, LED PS2 on the system board diagnostics panel refers to this power supply.
  • Page 24 This green light provides status information about the power supply. During normal operation, both the AC power LED and the DC power LED are on. See the "Solving problems" section of the User’s Reference on the IBM Netfinity Documentation CD for more information.
  • Page 25: Adding A Power Supply

    Installing a power supply Adding a power supply Your server comes with one power supply. You can replace the power supply backplane with an optional backplane that will enable you to add a second power supply, which gives redundancy and will make the power supplies hot-swappable. You can also add a third power supply for additional capacity.
  • Page 26: Cabling The Server

    The Management connector is dedicated for use by the Advanced System Management processor. Additionally, for rack models, be sure to route all the cables through the cable- management assembly on the rack (see the following illustration). IBM® Netfinity® 5100 Installation Guide...
  • Page 27 Cabling the server Routing cables through cable-management assembly Cable straps Chapter 2. Installing Options...
  • Page 28 Cabling the server IBM® Netfinity® 5100 Installation Guide...
  • Page 29: Chapter 3.Starting The Server

    The device also might have more than one power cord. To remove all electrical current from the device, ensure that all power cords are disconnected from the power source. © Copyright IBM Corp. 2000...
  • Page 30 You can disconnect the server power cords from the electrical outlets to shut off all power to the server. Wait about 15 seconds after disconnecting the power cords for your Note: system to stop running. Watch for the Power-on light on the operator information panel to stop blinking. IBM® Netfinity® 5100 Installation Guide...
  • Page 31: Controls And Indicators

    Starting the server Controls and indicators The following illustrations show the controls and indicators on the front of the server. Tower model Operator information panel Power control button shield (if installed) Hard disk drive activity Power light (green) control button Hard disk drive status Reset...
  • Page 32: Operator Information Panel

    POST complete light This green LED lights when the server completes the power-on self-test (POST) without any errors. SCSI hard disk drive in-use light This green LED lights when there is activity on a hard disk drive. IBM® Netfinity® 5100 Installation Guide...
  • Page 33 This amber LED lights when a system error occurs. An LED on the diagnostic panel on the system board will also be on to further isolate the error. Refer to the "Problem solving" section of the User’s Reference on the IBM Netfinity Documentation CD for detailed information on using the diagnostic panel (light path diagnostics).
  • Page 34 Starting the server IBM® Netfinity® 5100 Installation Guide...
  • Page 35: Chapter 4.Configuring Your Server

    Chapter 4. Configuring your server The ServerGuide CDs provide software setup tools and installation tools that are specifically designed for your IBM Netfinity server. Use these CDs during the initial installation of your server to configure basic hardware features and to simplify your network operating system installation.
  • Page 36: After Installing The Nos

    Your server comes with the following Netfinity systems management software products: IBM Netfinity Manager™ program and Client Services for Netfinity Manager version 5.2. Some versions of the ServerGuide package contain the IBM Netfinity Manager software.
  • Page 37: Chapter 5.Solving Problems

    If you cannot locate and correct the problem using the information in this section, refer to the " Solving problems" section in the User’s Reference on the IBM Netfinity Documentation CD and the "Support for Netfinity Servers" flowchart in the front of this booklet for additional information.
  • Page 38: Post Error Messages

    Solving problems Refer to the "Solving Problems" section in the User’s Reference on the IBM Note: Netfinity Documentation CD for more detailed information about the POST beep codes. Beep code Descriptions of the POST beep codes No beep Call for service.
  • Page 39 Solving problems POST message Failing device or problem Suggested action found L1 cache of a microprocessor Check the installation of your microprocessors. Change in device configuration Verify that your optional devices are turned on and installed correctly. Time of day has not been set Set the correct date and time.
  • Page 40: Serverguide Startup Problems

    Be sure you have the Adobe reader installed (available from the publications TechConnect CD). from TechConnect CD, or text is unreadable. Diskette Factory Suggested action Get "time out" or Be sure you have access to the Internet through FTP directly. "Unknown host" errors IBM® Netfinity® 5100 Installation Guide...
  • Page 41: Troubleshooting Chart

    Solving problems Troubleshooting chart Notes: 1. See the "Solving Problems" section in the User’s Reference on the IBM Netfinity Documentation CD for more detailed troubleshooting charts. 2. If you cannot find the problem in the troubleshooting charts, run the diagnostic programs.
  • Page 42 If the above items are correct, run the memory diagnostic program. The system might have detected a bad memory module and automatically reallocated memory to enable you to continue to operate. If the memory tests fail, call for service or replace the failing DIMM. IBM® Netfinity® 5100 Installation Guide...
  • Page 43 Solving problems Option problems Suggested action An IBM option that was just Verify that: installed does not work. 1. The option is designed for the server. Refer to the "Support for Netfinity Servers" flowchart for information about obtaining ServerProven™ compatibility information from the World Wide Web.
  • Page 44: Solving Problems

    Solving problems IBM® Netfinity® 5100 Installation Guide...
  • Page 45: Appendix A. Product Warranties And Notices

    1.The warranties provided by IBM in this Statement of Limited Warranty apply only to Machines you purchase for your use, and not for resale, from IBM or your reseller. The term "Machine" means an IBM machine, its features, conversions, upgrades, elements, or accessories, or any combination of them.
  • Page 46 Machine. If a Machine does not function as warranted during the warranty period, and IBM or your reseller are unable to either 1) make it do so or 2) replace it with one that is at least functionally equivalent, you may return it to your place of purchase and your money will be refunded.
  • Page 47 IBM or your reseller of changes in a Machine's location. IBM is responsible for loss of, or damage to, your Machine while it is 1) in IBM's possession or 2) in transit in those cases where IBM is responsible for the transportation charges.
  • Page 48: Ibm Statement Of Warranty Worldwide Except Canada, Puerto Rico, Turkey, United States (Part 1 - General Terms)

    IBM in this Statement of Warranty apply only to Machines you purchase for your use, and not for resale, from IBM or your reseller. The term "Machine" means an IBM machine, its features, conversions, upgrades, elements, or accessories, or any combination of them.
  • Page 49 WITHOUT WARRANTIES OF ANY KIND. Warranty Service To obtain warranty service for the Machine, contact your reseller or IBM. You may be required to present proof of purchase. IBM or your reseller provides certain types of repair and exchange service, either at your location or at a service center, to keep Machines in, or restore them to, conformance with their Specifications.
  • Page 50: Part 2 - Worldwide Country-Unique Terms

    IBM is responsible for loss of, or damage to, your Machine while it is 1) in IBM's possession or 2) in transit in those cases where IBM is responsible for the transportation charges. Neither IBM nor your reseller is responsible for any of your confidential, proprietary or personal information contained in a Machine which you return to IBM or your reseller for any reason.
  • Page 51 Limitation of Liability: The following is added to this Section: Where IBM is in breach of a condition or warranty implied by the Trade Practices Act 1974, IBM's liability is limited to the repair or replacement of the goods or the supply of equivalent goods.
  • Page 52 EGYPT: Limitation of Liability: The following replaces item 2 in this Section: 2. as to any other actual direct damages, IBM's liability will be limited to the total amount you paid for the Machine that is the subject of the claim.
  • Page 53 The following item is added to this paragraph: 3. breach of IBM's obligations implied by Section 12 of the Sale of Goods Act 1979 or Section 2 of the Supply of Goods and Services Act 1982.
  • Page 54: Notices

    Web sites. The materials at those Web sites are not part of the materials for this IBM product and use of those Web sites is at your own risk.
  • Page 55: Year 2000 Readiness And Instructions

    This IBM PC product cannot prevent errors that might occur if software you use or exchange data with is not ready for the Year 2000. IBM software that comes with this product is Year 2000 Ready. However, software from other companies might come with this IBM PC product.
  • Page 56: Important Notes

    IBM. Unless otherwise stated, IBM makes no representations or warranties with respect to non-IBM products. Support (if any) for the non-IBM products is provided by the third party, not IBM. Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.
  • Page 57: Industry Canada Class A Emission Compliance

    Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits. IBM is not responsible for any radio or television interference caused by using other than recommended cables and connectors or by unauthorized changes or modifications to this equipment. Unauthorized changes or modifications could void the user's authority to operate the equipment.
  • Page 58: Taiwan Electrical Emission Statement

    Japanese Voluntary Control Council for Interference (VCCI) statement Power cords For your safety, IBM provides a power cord with a grounded attachment plug to use with this IBM product. To avoid electrical shock, always use the power cord and plug with a properly grounded outlet.
  • Page 59 IBM power cord part Used in these countries and regions number 13F9940 Argentina, Australia, China (PRC), New Zealand, Papua New Guinea, Paraguay, Uruguay, Western Samoa 13F9979 Afghanistan, Algeria, Andorra, Angola, Austria, Belgium, Benin, Bulgaria, Burkina Faso, Burundi, Cameroon, Central African Rep., Chad, Czech Republic, Egypt,...
  • Page 60 IBM® Netfinity® 5100 Installation Guide...
  • Page 61: Index

    FCC Class A notice voltage regulator module features installing VRM See voltage regulator module adapters heat output bus A hot-swap drive bus B year 2000 readiness and instructions installing expansion slots specifications power cords © Copyright IBM Corp. 2000...
  • Page 62 IBM® Netfinity® 5100 Installation Guide...
  • Page 64 Part Number: 06P4554 Printed in the United States of America on recycled paper containing 10& recovered post-consumer fiber. SC06-P455-40 *07SC06P45540*...
