B. General Operating Parts
WARNING! DO NOT operate appliance before reading and understanding operating instructions. Failure to operate appli-
ance according to operating instructions could cause fire or injury.
3. Fuel loading door
Control access door
(pull to open)
1. Smart Burn Technology -
Activation Button/Light
4. Battery Holder
(lift out)
Figure 3.4

General Operating Parts

10
HOT SURFACES!
Glass and other surfaces are hot during operation AND cool down.
Hot glass will cause burns.
• DO NOT touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as appliance.
• Alert children and adults to hazards of high temperatures.
High temperatures may ignite clothing or other flammable materials.
• Keep clothing, furniture, draperies and other flammable materials away.
Fuel loading door handle
(raise to open)
(push to activate)
Quadra-Fire • Adventure-III Owner's Manual • 4083-900 • Rev D • 09/15
WARNING
2. Programmable Thermostat
5. Fan Speed Control
Operating Instruction
Wiring Diagram Label
Fan Connection
Power Cord Connection
(optional)
Label
Control Board Cover
(lift to remove)
Discard if optional fan installed
Thermostat
Terminal Block
Pedestal Screen
(remove for optional
Outside Air Kit)
Fan (optional)
