DISASSEMBLY / ASSEMBLY ADVICE TO OPEN THE PRODUCT ASSEMBLY ADVICE Remove STYLING COMB ( 1, 2 ) Take care, that the nocks of the comb holder ( 7 ), fi t perfectly into Remove CUTTER ( 3 ) the grooves of the zoom ring ( 6 ) Remove TRIMMER CLAMP ( 4 ) Remove CAP ( 5 ) Remove ZOOM RING ( 6 ) +...
Page 3
EXPLODED VIEW + PARTS LIST HQ-C 688 Description Service code Description Service code Large comb 4203 035 74070 Set housing sets NiCD 4203 035 74010 Small comb 4203 035 74080 ON/OFF knob 4203 035 74020 Cutter 4203 035 74060 Scissors...
