Summary of Contents for Mitsubishi LVP-SA51U
- Page 1 Projector User Manual SA51 LVP-SA51U MODEL EN – 1...
- Page 2 CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. NOTE: SINCE THIS PROJECTOR IS PLUGGABLE EQUIPMENT, THE SOCKET-OUTLET MUST BE IN- STALLED NEAR THE EQUIPMENT AND SHOULD BE EASILY ACCESSIBLE. WARNING Use the attached specified power supply cord. If you use another power-supply cord, it may cause interfer- ence with radio and television reception.
-
Page 3: Table Of Contents
To operate projector power ON ... 13 Menu operation ... 15 Picture adjustment ... 18 Specification of RGB signals in each computer mode of the projector ... 20 Advanced feature for presentation ... 21 Expand ... 21 Still ... 21 Lamp replacement ... -
Page 4: Important Safeguards
Water and moisture Do not use this projector near water or in con- tact with water. Accessories Do not place this projector on an unstable cart, stand, tripod, bracket or table. - Page 5 • Never put any heat-producing device under the pro- jector so that the projector does not overheat. • Do not attach the projector to a place that is un- stable or subject to vibration. • Do not install the projector near any equipment that produces a strong magnetic field.
-
Page 6: Overview
Overview Control panel AUTO POSITION POWER COMPUTER SOURCE LAMP VIDEO VOLUME MENU TEMP Terminal board S-VIDEO COMPUTER OUT COMPUTER IN RS-232C VIDEO IN VIDEO AUDIO L AUDIO R EN – 6 Air inlet grill (Front) Front height adjuster button Air inlet grill (Side) Terminal board Speaker Remote control sensor (Front) -
Page 7: Bottom Side
STILL VOLUME Adjustment foot (right and left) Lamp cover Adjustment foot (up and down) Caution: Do not replace the lamp right after using the projector. The lamp will be very hot. COMPUTER button MENU button AUTO POSITION button STILL button + , –... -
Page 8: Using The Remote Control
The range for operation is about 10 m (about 32 feet) when the remote control points to the projector. The dis- tance to the screen back to the projector must be less than 6 m (about 20 feet). Depending on the type of the screen, the distance will be different. -
Page 9: Installation
Installation Orientation of the projector Picture size can be set by changing the distance between the screen and the projector. Front projection Screen (between the screen and the head of the projector) Screen Diagonal size Height inches Width feet (inch) -
Page 10: Basic Connections
Basic connections This projector can be connected to equipment such as PC, VCRs, video cameras and DVD players. Important: • Make sure that your equipment is turned off before connection. • Plug in firmly and unplug by holding the plug, not by pulling the AC power cord. -
Page 11: Projector + Personal Computer
Please contact your dealer. • The audio input for this projector is a stereo pin jack. (Speaker output is mono.) Please check the available cable for the audio input terminal of the PC. Some personal computer may not have the audio output terminal. -
Page 12: Preparing The Projector For Operation
2. Connect the power cord to the wall power outlet. 3. Remove the lens cap. Warning: • Do not look directly into the lens when projector is “ON”. • The lens cap is for protecting the lens. If you leave the power on with the cap on, the cap may be warped. -
Page 13: To Operate Projector Power On
VOLUME VIDEO TEMP 1. Turn on the equipment connected to the projector. 2. Put the projector into standby mode by pressing the main power switch. The POWER indicator lights up red. • The POWER indicator blinks red for 2, 3 seconds after the power switch ON. - Page 14 • After the lamp is turned off, the lamp cannot be switched on again for 60 seconds as a precaution- ary measure. If you wish to turn on the projector again, wait until the indicator is off then press the POWER button.
-
Page 15: Menu Operation
Menu operation IMAGE CONTRAST BRIGHTNESS COLOR MATRIX USER COLOR TEMP. SHARPNESS TINT COLOR INSTALLATION AUTO POWER ON AUTO POWER OFF IMAGE REVERSE FEATURES MENU POSITION EXPAND MODE AUDIO MODE VIDEO SIGNAL ANAMORPHIC LANGUAGE RESET ALL SIGNAL MEMORY CALL HORIZ.POSITION VERT.POSITION FINE SYNC. - Page 16 In this case, use the remote control to turn on the lamp. AUTO POWER OFF .. Use to select the length of time before projector switches to stand-by when there is no input signal selected source. IMAGE REVERSE Use to reverse or invert the projected image. MIRROR is used to rear projection. MIRROR INVERT is for ceiling-mount.
-
Page 17: User Memory For Signal Setting
HORIZ. POSITION ... Use to adjust the horizontal position of the image. VERT. POSITION ... Use to adjust the vertical position of the image. FINE SYNC..Use to synchronize the projector with PC input signals so that the image is not blurred. -
Page 18: Picture Adjustment
The white, which temperature is low, becomes reddish white. When the color temperature is higher, the white becomes more bluish. This projector sets this color temperature by changing the numbers of contrast blue and red. -
Page 19: Adjustment From Personal Computer
Adjustment from personal computer Although this projector sets proper signal systems automatically for the image signal from personal computers, it cannot be applied to some of personal computers. In this case, press the AUTO POSITION button. If the images are still not projected correctly, use the MENU display to adjust the projected im- ages. -
Page 20: Specification Of Rgb Signals In Each Computer Mode Of The Projector
Picture adjustment (continued) Specification of RGB signals in each computer mode of the projector Signal mode resolution (H x V) TV60 – TV50 – 1080i – 720p – PC98 640 x 400 CGA70 640 x 400 CGA84 640 x 400... -
Page 21: Advanced Feature For Presentation
Advanced features for presentation Expand By pressing the EXPAND button on the remote con- trol, you can magnify the detailed image of the picture. You can also view the screen displaying the picture as its original size (native resolution display). Setting the Expand mode 1. -
Page 22: Lamp Replacement
• Be sure that the projector guide is firmly inserted between the right and left lamp guides. Important: • The projector will not turn on if you do not secure the lamp lid. • You must reset the operation time meter after you replace the lamp. -
Page 23: Maintenance
Maintenance Caution: Be sure to turn off the projector and unplug the power cord from the wall outlet before you perform any main- tenance on the projector. Cleaning the air-filter Clean the air-filter frequently (about once a month). If the filter or ventilation slots become clogged with dirt... -
Page 24: Troubleshooting
(In this case, the TEMP indicator does not light up.) The image is • The projector is not at a right angle to the screen. distorted. The image is dark. • Brightness, tint and color are not adjusted correctly. -
Page 25: Indicators
Indicators The projector has three LED Indicators which shows the working condition of the projector. The following offers solutions to possible problems. If a problem persists, turn the projector off and consult your dealer. POWER indicator LAMP indicator TEMP indicator... -
Page 26: Specifications
(performance guarantee) Kensington Lock This projector has a Kensington Security Standard connector for use with a Kensington MicroSaver Security System. Refer to the information that came with the Kensington System for instructions on how to use it to secure the projector. Please contact to Kensington Technology Group as shown below. -
Page 27: Connectors
Replacement part (Option / Not included in the box) Spare Mercury lamp 11 15 RS-232C input Use to control the projector with the personal computer, or control the personal computer with remote con- trol. Use the provided RS-232C cable (Mini DIN 8P-D-SUB 9P) for the connection. -
Page 28: Lcd Projector
LCD Projector LVP-SA51U Control projector by using a personal computer This projector can be controlled by connecting a personal computer with RS-232C terminal. Functions can be controlled by a personal computer: • Turn the ON or OFF • Changing input signals •... - Page 29 (1) Send the command from a personal computer to the projector. (The commands must be sent at least 400ms apart.) (2) The projector will send a return command 400ms* after it has received an end code. If the command is not received correctly, the projector will not send the return command.
- Page 30 INPUT COMPUTER INPUT VIDEO When a personal computer sends the command, data code will not be attached. On the other hand, the projector which has received a command will attach the recent operating status and then send. [Example ] Input was Video when the operating status of the input terminal was confirmed.
- Page 31 000 - 299 000 - 299 000 - 398 000 - 398 Status code from projector 30 30 41 50 4F 4E 30 0D '0' '0' 'A' 'P' 'O' 'N' '1' ' Status code from projector 30 30 50 2B 31 30 2B 30 30 2D 30 35 0D...
