- Page 1 Call 1-800-667-8721 anywhere in the US and Canada www.rangehoods.com ® GE Monogram rangehoods rangehoods Installation Instructions 36" Vent Hood Model ZV750 accessories rangehoods GE Monogram at kitchen is a division of...
-
Page 2: Table Of Contents
This appliance must be properly grounded. See “Electrical Supply”, page 4. CAUTION WARNING If you have questions concerning the installa- OBSERVE THE FOLLOWING: tion of this product, call the GE Answer A. Use this unit only in the manner intended ® Center Consumer Information Service at by the manufacturer. -
Page 3: Models Available
*The distance between the cooking surface and the bottom of the hood must be at least 24" and up to 30". The 25-1/2" recommended installation height, above the standard 36" countertop, will insure duct cover fit to the ceiling. accessories rangehoods GE Monogram at kitchen is a division of... -
Page 4: Advance Planning
• If the electrical supply does not meet the above requirements, call a licensed electrician before proceeding. • Route wiring as close to the installation location as possible, in the ceiling or soffit. accessories rangehoods GE Monogram at kitchen is a division of... -
Page 5: Installation Preparation
* Actual length of straight duct plus duct fitting Total Duct Run equivalent. Equivalent length of duct pieces are based on actual tests conducted by GE Evaluation Engineer- ing and reflect requirements for good venting performance with any ventilation hood. -
Page 6: Tools And Materials Required
• Install strain relief onto junction box. Junction Knockout Mounting Mounting Screw Screw S h ip p in g B o a Mounting Screw Sh ipp ing Bo ar d accessories rangehoods GE Monogram at kitchen is a division of... -
Page 7: Step 2: Check Installation Hardware
• Route house wiring as close to the installation location as possible; through the ceiling, soffit or back wall. Wiring should enter at least 4” above the bracket on the right side. accessories rangehoods GE Monogram at kitchen is a division of... -
Page 8: Step 4: Install Mounting Bracket
• Tighten the lower mounting screws. • Tighten screws “B” located at the top of the mounting bracket against the hood to clamp the position. Do not overtighten screws. Lower Mounting Screws accessories rangehoods GE Monogram at kitchen is a division of... -
Page 9: Step 6: Install Duct Bracket
Drive screws into the fasteners to allow anchors to expand against the wall material. Remove the screws. • Secure the bracket to the ceiling and wall with wood screws and/or wall fastener screws. accessories rangehoods GE Monogram at kitchen is a division of... -
Page 10: Step 7: Connect Ductwork
• Install the side utility bars as shown with and the screw holes at the top as illustrated. • Follow the same procedures shown above to screws provided. install the new duct cover. accessories rangehoods GE Monogram at kitchen is a division of... -
Page 11: Step 10: Install Filters
• Remove protective film covering the control panel on the front face of the hood and any Step remaining packaging materials. • Refer to the Use and Care book for operating instructions. Finalize Installation accessories rangehoods GE Monogram at kitchen is a division of...
