Specifications
Monitor
Specifications
LCD Module Diagonal :
Viewable Image Size :
Native Resolution (Pixel Count) :
Input Signal Video :
Display Colors
Maximum Left/Right :
Viewing Angles Up/Down :
Synchronization Horizontal :
Range Vertical :
Resolutions Supported
Active Display Area
Horizontal :
Vertical :
USB Hub
Load Current
Speakers Practical Audio Output :
Power Supply
Current Rating
Dimensions
Weight
Environmental Considerations
Operating Temperature:
Humidity:
Storage Temperature:
Humidity:
* 1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is
normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each
dot on the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
NOTE: Technical specifications are subject to change without notice.
MultiSync ® LCD
Monitor
15.0 inch
15.0 inch
1024 x 768
ANALOG 0.7 Vp-p/75 Ohms
Sync : Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
16,777,216
80°/80° (CR>5)
70°/80° (CR>5)
31.5 kHz to 60.0 kHz
56.2 Hz to 75.1 Hz
720 x 400* 1 :VGA text
640 x 480* 1 @ 60 Hz to 75 Hz
800 x 600* 1 @ 56 Hz to 75 Hz
832 x 624* 1 @ 75 Hz
1024 x 768 @ 60 Hz to 75 Hz .........
304.1 mm/12.0 inches
228.1 mm/9.0 inches
I/P USB Specification Revision 2.0
Port Upstream 1
Downstream 4
Maximum 0.5A per port
1.0W + 1.0W
100 – 240 V ~ 50/60 Hz
1.0 – 0.5A
344.8 mm (W) x 344.2 mm (H) x 166.0 mm (D)
13.6 inches (W) x 13.6 inches (H) x 6.5 inches (D)
4.4 kg
9.7 lbs
5°C to 35°C/41°F to 95°F
30% to 80%
Feet: 0 to 10,000 Feet
-10°C to 60°C/14°F to 140°F
10% to 85%
Feet: 0 to 31,500 Feet
13
™ Notes
1560M
Active matrix; thin film transistor (TFT)
liquid crystal display (LCD); 0.297 mm dot
pitch; 300cd/m 2 white luminence;
450:1 contrast ratio, typical
Digital Input: DVI
Dependent on display card used.
Automatically
Automatically
Some systems may not support
all modes listed.
NEC-Mitsubishi Electronics Display cites
recommended resolution at 75 Hz for
optimal display performance.
