Thank you for purchasing this product.
Please read these instructions carefully before using this product, and save this manual for future use.
Software (Firmware) Update
To support the latest features, it's very important you install the latest updates to
maintain proper operation of your unit.
For details, refer to "Software (Firmware) Update" (
http://panasonic.jp/support/global/cs/ (This site is in English only.)
EG

Operating Instructions

DVD Recorder

Model No.
DMR-EX97C
DMR-EX97S
76) or
SQT0989

Advertisement

Table of Contents
loading

Related Manuals for Panasonic DMR-EX97C

Summary of Contents for Panasonic DMR-EX97C

  • Page 1: Operating Instructions

    Software (Firmware) Update To support the latest features, it’s very important you install the latest updates to maintain proper operation of your unit. For details, refer to “Software (Firmware) Update” ( 76) or http://panasonic.jp/support/global/cs/ (This site is in English only.) SQT0989...

  • Page 2: Safety Precautions

    Safety precautions WARNING CAUTION Unit Unit • To reduce the risk of fire, electric shock or • This unit utilizes a laser. Use of controls or product damage, adjustments or performance of procedures other - Do not expose this unit to rain, moisture, than those specified herein may result in dripping or splashing.

  • Page 3: Supplied Accessories

    (Alkaline or manganese batteries) About descriptions in these operating instructions • These operating instructions are applicable to models DMR-EX97C and DMR-EX97S. The illustrations in these Operating Instructions show images of DMR-EX97C unless otherwise indicated. • [EX97C] : indicates features applicable to DMR-EX97C only.

  • Page 4: Table Of Contents

    Table of contents Convenient functions Safety precautions ....2 Supplied accessories ....3 VIERA Link functions .

  • Page 5: Getting Started

    Getting started Watching broadcasts Recording Playing back video Editing video Copying video Photo and Music With Other Equipment Convenient functions Troubleshooting Reference SQT0989...

  • Page 6: Hdd And Media Information

    Getting started HDD and media information Getting started For more details, refer also to the specifications. ( Recordable/playable contents (–: Impossible) Media type Standard symbol Recordable contents Playable contents • Video • MP4 • MKV Built-in hard disk drive • AVCHD/AVCHD 3D •...
  • Page 7 The recording and playback of content on this or any other device may require permission from the owner of the copyright or other such rights in that content. Panasonic has no authority to and does not grant you that permission and explicitly disclaims any right, ability or intention to obtain such permission on your behalf.
  • Page 8 Getting started HDD and media information Information about contents ∫ Broadcast Recordings ∫ Photo files Numbers of titles that can be recorded: Compatible pixels: Between 34k34 and 8192k8192 pixels Maximum Sub sampling: 4:2:2, 4:2:0 Media titles (Motion JPEG is not supported.) 1000 Maximum numbers of contents: DVD-RAM, DVD-R, DVD-RW...
  • Page 9 Getting started Recording mode Recording Mode HG/HX/HE/HL/HM XP/SP/LP/EP/FR §1 Feature Programmes can be Recording can be done Recording can be done recorded in a nearly with reduced recording with reduced recording perfect broadcasted state. volume in High definition volume in Standard (HD) quality definition (SD) quality.
  • Page 10 Getting started HDD and media information Notes for the disc • Operation and sound quality of CDs that do not conform to • Region management information CD-DA specifications (copy control CDs, etc.) cannot be The unit can play back DVD-Video discs of the guaranteed.

  • Page 11: Unit Care

    Getting started Unit care HDD/USB HDD handling care When moving the unit Before moving the unit, ensure the disc tray is • The HDD is a high precision recording empty. instrument and is easily susceptible to damage. 1 Switch the unit to standby mode. (Wait until Therefore, be careful of the following points “BYE”...

  • Page 12: Control Reference Guide

    Getting started Control reference guide Instructions for operations are generally described using the remote control. Remote control 1 Transmit the remote control signal  • Point it at remote control signal sensor on this unit. ( 2 Switch the unit from on to standby mode or vice versa ...
  • Page 13 Getting started Main unit Display Display    COPY PLAY   1 Drive (HDD or DVD) indicator 2 Disc indicator Pull to flip down the 3 Copying indicator front panel. 4 USB port indicator 5 Remote control signal indicator 1 Remote control signal sensor 6 Timer recording indicator •...

  • Page 14: Ci (Common Interface) Module

    Getting started CI (Common Interface) module An appropriate CI module is required to view or record the encrypted broadcast. You need a CI module, CAM (Conditional Access Module) together with a certified Smart Card, and a subscription with the corresponding broadcaster. •...
  • Page 15 Getting started About CI Plus compatible broadcast Retention limit There are some titles for which the playback will “CI Plus” is a technical specification that imposes be disabled after a predetermined time. contents protection, etc. (e.g., Permitted playback period is 90 minutes CI Plus contents protection after recording.) •...

  • Page 16: Connection

    • Before connection, turn off all equipment and read the appropriate operating instructions. • Use the High Speed HDMI cables. Non-HDMI-compliant cables cannot be utilized. It is recommended that you use Panasonic’s HDMI cable. When outputting 24p signal, please use HDMI cables 5.0 meters or less.
  • Page 17 Getting started [EX97S] Basic connections The following two connection methods are available. Choose a method suited to your environment. A Using a single cable router. B Connecting a satellite cable directly. Satellite dish Satellite dish Single cable router This unit’s rear panel AC mains lead HDMI cable (supplied)
  • Page 18 Getting started Connection Amplifier/receiver connections ∫ Amplifier/receiver not compatible with 3D 3D programmes can be played back when this unit is connected to a 3D compatible TV. • This connection only supports up to 5.1ch. Amplifier/ receiver HDMI cable Amplifier/ HDMI cable receiver HDMI cable...

  • Page 19: Settings

    Manufacturer and Code No. TV operation buttons The TV can be operated from the TV operation Brand Code Brand Code Panasonic 01/02/03/04 buttons of the remote control. NOBLEX AIWA NOKIA 25/26/27/60/61 • Perform the setting if you cannot operate the TV...
  • Page 20 Getting started Settings [EX97C] Easy Setting 2 [DVB-C] Select “Start Auto Setup”, then press The tuner in this unit is compatible with digital [OK]. Cable broadcast services and digital terrestrial • Frequency broadcast services. Auto • In these operating instructions, The preset frequency will be [DVB-C] : indicates features applicable to digital automatically used.
  • Page 21 Getting started [EX97S] Easy Setting 2 Select “Start Auto Setup”, then press [OK]. Turn on the TV, then select the appropriate Auto Setup starts. AV input to suit the connections to this unit. These operations (Searching Satellite and Searching Channels) may take some time. Press [Í] on the remote control or [Í/I] on this unit.

  • Page 22: Function Menu Screen

    Getting started FUNCTION MENU screen You can easily access the desired functions, such FUNCTION MENU list as playback, timer recording, the unit’s settings • TV Guide ( etc. via the FUNCTION MENU. • Contents on HDD Press [FUNCTION MENU]. - Recorded Programmes ( - Video ( AVCHD ) ( FUNCTION MENU - Video ( MP4 / Xvid / MKV ) (...

  • Page 23: Watching Broadcasts

    Watching broadcasts Watching broadcasts Watching broadcasts Using channel information Press [CH W X] to select the channel. • You can also select the channel by the While watching a programme following operations. Press [STATUS - Using number buttons Channel information appears. - Using Channel List ( ...
  • Page 24 Watching broadcasts Watching broadcasts To show subtitle Aspect You can switch the screen mode. When “ ” appears in channel information Refer to “Switching the aspect ratio of the screen”. ( Press [STTL • Press again to hide subtitle. To select the contents in the broadcast To change subtitle language 1 Press [OPTION].
  • Page 25 Watching broadcasts Using Channel List Using TV Guide system You can select from the list of channel names. Press [GUIDE]. Press [OK]. e.g. Landscape view Landscape TV Guide All DVB Channels TUE 06.01.2015 8:05 Category: All DVB Channels Sorting 123... 8:00 - 9:45 TUE 06.01 8:00...

  • Page 26: Display Information

    Watching broadcasts Watching broadcasts REWIND LIVE TV/PAUSE LIVE TV To stop REWIND LIVE TV or PAUSE LIVE TV 1 Press [STOP ∫]. This unit temporarily saves a live TV programme 2 Select “Yes”, then press [OK]. you are watching with this unit’s tuner on HDD. REWIND LIVE TV To hide the display information You can rewind live TV programme to the point...

  • Page 27: Recording

    Recording Recording TV programmes Recording To set the recording time 1 Select “Recording Time” or “Continuous recording” in step 4 ( left). • About CI Plus restriction ( Recording Time: You can set the length of recording time from Select the channel to record. 30 minutes to 4 hours.
  • Page 28 Recording Recording TV programmes Operation during Recording To pause recording After displaying the recording programme, press To check the recording programme [PAUSE ;]. Press [STATUS • Press again to restart recording. (A title is not split into separate titles.) e.g., •...

  • Page 29: Timer Recording

    Recording Timer recording To use TV Guide system Refer to “Using TV Guide system”. ( • You can enter up to 32 programmes within a month in advance. (Each daily or weekly To edit the timer recording on the TV Guide programme is counted as one programme.) screen •...
  • Page 30 Recording Timer recording To search the programmes If “Overlapped Timer Recording” screen appears 1 On the TV Guide screen: Press the blue button. 2 Select the item, then press [OK]. Overlapped Timer Recording Timer programme overlaps with others. Keyword Search Some part or all of programmes may not be recorded completely.

  • Page 31: Operation During Recording

    Recording Manually programming timer Timer recording options recording Select the items and change the items. Press [PROG/CHECK]. e.g., Timer Recording 30:24 DR TUE 06.01.2015 8:05 Signal Supported : OFF Timer Recording 30:30 DR TUE 06.01.2015 8:05 Channel Day/Date Start Stop Mode Conv.
  • Page 32 Recording Timer recording Timer recording from channel Notes on timer recording information • When the programme recorded in DR mode is You can make timer recording of the current or converted, the audio content and subtitle next programme. language will be selected according to the following settings: While watching a programme - “Multi Audio”...
  • Page 33 Recording To confirm and edit a timer Screen icons programme Red: Timer recording standby is activated. Press [PROG/CHECK]. Grey: Timer recording standby is deactivated. e.g., Currently recording programme Timer Recording 30:30 DR TUE 06.01.2015 8:05 Channel Name Space Schedule Mode A part or all of the programme will not be MON 13.01 Guide...

  • Page 34: Playing Back Video

    Playing back video Playing titles on the HDD Playing back video Video Menu screen § e.g., “For recorded titles ( 9)” only §    Press [FUNCTION MENU]. Video Menu Grouped Titles Time Remaining 45:54 (DR) Select “Contents on HDD”, then press Not Viewed Movie Sport...
  • Page 35 Playing back video Title is recorded using a different Screen icons encoding system from that of the Currently recording programme unit. Change the “TV System” ( 73). Protected title Title was not recorded due to Radio programme recording protection Title cannot be played 3D contents (When data is damaged etc.) Recorded in 1080/50p contents...
  • Page 36 Playing back video Playing titles on the HDD Editing the grouped titles You can quickly find the recorded titles by 1 Select the title or the group, then press the selecting the tab. yellow button. • A check mark is displayed. Repeat this step. •...

  • Page 37: Playing Titles On The Media

    Playing back video Playing titles on the media Video list screen § e.g., “For data files ( 9)” only § Videos \ Video \ Parent Folder Insert the media. Folder 01 Folder 02 • AVCHD: If the menu screen is not video01.mpeg 00.00.0000 00:00 displayed...

  • Page 38: Operation During Play

    Playing back video Operation during play Quick View Press and hold [PLAY/a1.3 1]. • Press again to return to normal speed. • Discs continue to rotate while menus are displayed. Press [STOP ∫] when you have finished playback to protect the unit’s motor, your TV screen, etc.
  • Page 39 Playing back video Frame-by-frame To display menu While paused, press [2] (2;) or [1] (;1). [DVD-V] • Each press shows the next frame. 1 Press [OPTION]. • Press and hold to change in succession forward 2 Select “Playback Menu”, then press [OK]. or backward.
  • Page 40 Playing back video Operation during play Changing audio 3D video playback Press [AUDIO]. Preparation • It will switch depending on the contents Connect 3D compatible TV to this unit. ( 16, 17) recorded every time it is pressed. • Perform the necessary preparations for the TV. Play back following the instructions displayed on the screen.
  • Page 41 Playing back video 3D settings during playback • Please refrain from viewing 3D images if you do not feel Change this setting when the screen is not well or are experiencing visual fatigue. correctly displayed for 3D compatible In the event that you experience dizziness, nausea, or other programmes.

  • Page 42: Editing Video

    Editing video Deleting/Editing titles Editing video Once deleted, divided or partially deleted, Editing recorded titles content cannot be restored to its original state. Make certain before proceeding. • If the title is contents protected, you may not perform editing other than deleting. ( §...
  • Page 43 Editing video Setting protection Dividing title [HDD] [USB_HDD] [RAM] [HDD] [USB_HDD] [RAM] [+R] [+RW] Protection setting prevents the title from 1 Select “Divide Title” in “Edit”, then press [OK]. accidental deletion. 2 Press [OK] at the point to divide the title. 1 Select “Set up Protection”...
  • Page 44 Editing video Deleting/Editing titles 3 Select the item, then press [OK]. File Conversion Convert & Delete: [HDD] [USB_HDD] The original title will be deleted to save HDD File Conversion is a function to convert the capacity after conversion. recording mode of the title in DR mode and Convert Only: AVCHD contents.

  • Page 45: Playback From Chapter View

    Editing video To confirm whether the conversion is To combine chapters (Delete chapter completed mark): Press [VIDEO MENU]. 1 Select the chapter, then press [OPTION]. e.g., 2 Select “Combine Chapters”, then press [OK]. Channel Date Title Name Titles 04.10 04.10 3 Select “Combine”, then press [OK].

  • Page 46: Copying Video

    Copying video Copying titles Copying video To register the external HDD (USB HDD) §1, 2, 3 Refer to “Registering the USB HDD”. ( To copy HD Video (AVCHD) to the DVD-R in High Definition Refer to “Copying HD Video (AVCHD) to the “For recorded titles ( 9)”...
  • Page 47 Copying video To change the selection Setting the copying options 1 Select the item in step 7 ( 46). 1 Select “No”, then press [OK] in step 6 ( 46). e.g., e.g., [HDD] > [DVD-RW] The order of copying Automatic Standby after Copy Remaining space Standby status can be changed if required.
  • Page 48 Copying video Copying titles Copying from media other than HDD Copying titles with copying list with Video Menu ,. [USB_HDD] [HDD] §1, 2, 3 [RAM] [+RW] > [HDD] [RAM] [DVD-R] [DVD-RW] [+R] > [HDD] Insert a disc. [+RW] The menu screen appears. ( >...
  • Page 49 Copying video Register titles for copy. Make other settings. 1 Select “Create List”, then press 1 Select “Other Settings”, then press [1] (right). [1] (right). 2 Select “New item”, then press [OK]. e.g., 3 Select the title, then press the yellow Copy button.
  • Page 50 Copying video Copying titles Editing the copying list Screen icons 1 Select the title after step 4-4 ( 49). Titles that cannot be copied in high speed mode Copy Cancel All Destination Capacity: 2:00 ( 50% ) Size: 1:00 Titles that cannot be copied Copy Direction Title Disc...
  • Page 51 Copying video Notes for copying Notes for normal speed copy • [DVD-R] [DVD-RW] [+R] [+RW] You cannot copy to Notes for high speed copy the disc in the following cases. High Speed Copying is the process of copying a - When there is not enough free space on the title to disc in high speed while maintaining the HDD.
  • Page 52 Copying video Copying titles Copying a finalised disc • Operations and on-screen displays during copy are also [DVD-V] > [HDD] recorded. While playing a disc, the content being played is copied to the HDD according to the set time. Copying Title Playing Press [FUNCTION MENU].
  • Page 53 - Without the AVCHD information (video recorded with copied to the HDD. We recommend that you create a folder certain non-Panasonic equipment, etc.) with an easily identifiable name on a PC or other device first • 3D video may not be copied correctly.

  • Page 54: Photo And Music

    Photo and Music Playing photos Photo and Music Photo Menu screen §2 §1 e.g., [HDD] “For data files ( 9)” only (JPEG, MPO) §1 [RAM] [DVD-R] [+R] only §2 Photo Menu 03.01.2012 [HDD] 29.10.2012 25.02.2013 15.03.2013 1 Press [FUNCTION MENU]. 2 Select “Photo”...
  • Page 55 Photo and Music Photo play option Slideshow settings While displaying a photo: On the Photo Menu screen: Press [OPTION]. Press the green button. Select the item, then press [OK]. Slideshow Start Slideshow Graphic Display Level Interval Normal You can change the 3D position of the Transition Effect Fade Repeat Play...

  • Page 56: Editing Photos

    Photo and Music Editing photos § Select the item, then press [OK]. Enter Folder Name [RAM] only § Refer to “Entering text”. ( On the Photo Menu screen: Combine Folders To edit the folder: [HDD] Select the folder. To edit the photo: Delete Folder 1 Select the folder, then press [OK].

  • Page 57: Copying Photos

    Photo and Music Copying photos §1 §2 Copying automatically “For data files ( 9)” only (JPEG, MPO) §1 [USB_HDD] [RAM] [DVD-R] > [HDD] [RAM] [DVD-R] [+R] only [+R] [CD] [USB] §2 Newly added photos will automatically be copied to the HDD. •...

  • Page 58: Playing Music

    Photo and Music Playing music §2 §1 Screen icons Folder “For data files ( 9)” only §1 [DVD-R] [+R] only §2 Music Playing music CD (CD-DA) Move to the parent folder [CD] (CD-DA) Playing music file on the HDD Insert the disc. Playback will automatically start.

  • Page 59: Copying/Deleting Music

    Photo and Music Copying/Deleting music §1 §2 Deleting [HDD] “For data files ( 9)” only §1 [DVD-R] [+R] only §2 On the music list screen: Select the file or folder. Copying • Multiple selection ( left) [USB_HDD] [DVD-R] [+R] [CD] [USB] > [HDD] Press [DELETE].

  • Page 60: With Other Equipment

    “For data files ( 9)” only § Title recorded using a different (NTSC) encoding system from that of the e.g., Connecting to the Panasonic video camera (PAL) unit. • Titles displaying these marks cannot be selected. USB connection cable (optional) Connect the video camera or insert the media.

  • Page 61: Registering The External Hdd (Usb Hdd)

    Please use a confirmed USB HDD. For the latest information on confirmed USB HDDs, please check the following website. http://panasonic.jp/support/global/cs/ • Certain non-confirmed USB HDDs cannot be used with this unit. • If a problem occurs with the USB HDD, please contact the manufacturer of the device.
  • Page 62 With Other Equipment Registering the external HDD (USB HDD) Disconnecting the USB HDD Registering the USB HDD Disconnecting without following this procedure • If the registering screen appears when may result in the loss of recorded content from connecting the USB HDD, go to step 4. the USB HDD or the internal HDD.

  • Page 63: Convenient Functions

    Easy control only with Panasonic TV’s VIERA Link is a convenient function which will link remote control the operations of this unit and a Panasonic TV You can operate this unit using the TV remote (VIERA) or an amplifier/receiver. You can use this control.

  • Page 64: Playback Menu

    Convenient functions Playback menu A variety of playback operations and settings can Basic Operation be performed from this menu. Soundtrack § Available options differ depending on the playing Show or change the soundtrack. contents and the condition of the unit. Multi Audio Switch in the case of multiple audio.
  • Page 65 Convenient functions Picture Settings Sound Settings Sharpness Adjustment Sound Effects Adjusts the sharpness of images. The greater • This function is effective when “Digital Audio the value is, the sharper images will be. Output” is set to “PCM”. ( Noise Reduction Night Surround Reduces unnecessary noise in videos.

  • Page 66: Basic Settings

    Convenient functions Basic Settings You can change the unit’s settings of DVB Tuning, [EX97C] DVB Tuning Sound, Display, Connection etc. in the menu. Favourites Edit Press [SETUP]. You can create four favourites of channels for making viewing and recording easier. Basic Settings DVB Tuning HDD / Disc / USB HDD...
  • Page 67 Convenient functions Auto Setup [DVB-C] Settings for DVB-C Channels You can restart the Auto Setup. ( [DVB-T] Settings for DVB-T Channels 1 Select “Yes”, then press [OK]. Channel List • If the country selection screen appears: You can edit the channel list. Select the country, then press [OK].
  • Page 68 Convenient functions Basic Settings Update Channel List Child Lock You can update the channel list to the latest You can restrict the viewing/playback/recording one. of channels unsuitable to children. • PIN is required to change. ( [DVB-C] Child Lock List •...
  • Page 69 Convenient functions [EX97S] DVB Tuning Update Channel List You can update the channel list to the latest one. Favourites Edit ( 1 Select the method and settings. Search Mode Channel List ( • Free Channels • All Channels Auto Setup You can restart the Auto Setup.
  • Page 70 Convenient functions Basic Settings Antenna System HDD / Disc / USB HDD You can receive several satellites if you have Settings for Playback DiSEqC control antenna system or single cable router. Soundtrack 1 Select “Antenna System”. Select the audio language. 2 Press [2, 1] to select antenna system.
  • Page 71 Convenient functions PIN Entry for Decrypt Recording Delete all music If your CAM requires a PIN for timer Delete all Music on the built-in HDD. recording, it can be entered here in advance. Format HDD Aspect for Recording Formatting deletes all contents on the built-in HDD, and they cannot be restored.
  • Page 72 Convenient functions Basic Settings Select the audio signal to output. Picture • Select “PCM” when the connected equipment cannot decode the respective Still Mode audio format. Select the type of picture shown when you pause • Not making the proper settings may result in play.
  • Page 73 Convenient functions Connection HDMI Connection HDMI Video Format 3D Settings You can only select items compatible with the connected equipment. 3D Type • If “Automatic” is selected, the output If 3D video cannot be played back in 3D, you resolution best suited to the connected TV may be able to play it in 3D by changing the (1080i, 720p or 576p/480p) is automatically setting.
  • Page 74 “Front Panel Display” in “Display” is fixed to and the remote control if you place other “Automatic”. ( Panasonic products close together. Automatic Standby • Use “DVD 1”, the factory set code, under Set the time to turn the unit to standby mode normal circumstances.
  • Page 75 Convenient functions Clock System Update If the time is not set correctly, use the settings Software Update in Standby listed in the method below. When you set this unit to standby mode, • Automatic software (firmware) updates ( 76) are This unit usually obtains time and date downloaded automatically at the time you information from digital broadcasts.

  • Page 76: Software (Firmware) Update

    • Operations such as view, playback, or record cannot be performed while upgrading the CAM. http://panasonic.jp/support/global/cs/ Any buttons on the remote control or the unit cannot be (This site is in English only.) used while upgrading the CAM.

  • Page 77: Other Operations

    Convenient functions Other operations Media management Delete all titles [RAM] [RAM] [DVD-R] [DVD-RW] [+R] [+RW] 1 Select “Yes”, then press [OK]. Press [FUNCTION MENU]. 2 Select “Start”, then press [OK]. Select “Media”, then press [OK]. • Photo data (JPEG/MPO) or computer data cannot be Select the media, then press [OK].
  • Page 78 [DVD-R] [DVD-RW] [+R] [+RW] • [DVD-R] [DVD-RW] [+R] If you finalise discs recorded on Panasonic equipment other than this unit, the background You can select whether to show the Top Menu selected as “Top Menu” may not be displayed.
  • Page 79 Convenient functions Entering text Switching the aspect ratio of the screen Preparation • Show the “Enter Title Name” screen, etc. When the image does not match the screen size of the TV, you can enlarge the image to fill the Select a character, then press [OK].

  • Page 80: Troubleshooting

    Troubleshooting Troubleshooting guide Troubleshooting Before requesting service, make the following Cannot eject a disc. checks. If the problem still persists, consult 1 When the unit is Off, press and hold [OK], the your dealer for instructions. yellow button and the blue button at the same Updating to the latest software (firmware) may time for more than 5 seconds.
  • Page 81 Troubleshooting Displays There is a lot of image lag when playing video. • Set to “0” all items in the “Noise Reduction”. “0:00” is flashing on the front panel display. • Set the clock. ( • Set “Audio Delay”. ( The clock does not display on the unit when The images do not appear on the TV.
  • Page 82 Troubleshooting Troubleshooting guide Auto Renewal Recording does not work Sound properly. • The programme will not be overwritten in the No sound. following cases: Distorted sound. - the programme is protected • Check the connections. ( 16, 17) - any programme is being played back or copied •...
  • Page 83 Troubleshooting Play Edit Cannot play back. Cannot edit. • The disc is dirty. ( • You may not be able to edit on the HDD if there • The disc is scratched or marked. is no available space. Delete any unwanted titles to create empty space.
  • Page 84 Troubleshooting Troubleshooting guide Broadcast Language code list Picture regularly breaks up on some Lingala: 7678 Abkhazian: 6566 channels. Afar: 6565 Lithuanian: 7684 Afrikaans: 6570 Macedonian: 7775 • Adjust the reception with “Manual Tuning”. Albanian: 8381 Malagasy: 7771 67, 69) Malay: 7783 Amharic: 6577...
  • Page 85 Troubleshooting Messages on the front panel display NoWRIT You cannot write to this disc. The following messages or service numbers The disc may be damaged. Use a new disc. appear on the front panel display when something unusual is detected. PLEASE WAIT •...
  • Page 86 Troubleshooting Troubleshooting guide UPD / (“∑” stands for a number.) The unit fails to operate properly. Press [Í/I] on the main unit to switch the unit to standby mode. The software (firmware) is being updated. Now press [Í/I] on the main unit again to turn the You cannot operate the unit until the update is unit on.

  • Page 87: Reference

    Reference Specifications Reference Specifications are subject to change without ∫ HDMI terminal notice. HDMI out (19 pin type A): 1 pc. ∫ General Dimensions: 430 mm (W) ∫ Internal HDD capacity 59 mm (H) 500 GB (including the projecting parts) 210 mm (D) ∫...
  • Page 88 Reference Specifications ∫ XP, SP, LP, EP modes Recording modes and approximate recording times Recording HDD (500 GB) Depending on the content being recorded, the Mode recording time may become shorter than indicated. 107 hours ∫ DR mode 215 hours Recording HDD (500 GB) 430 hours...

  • Page 89: Licenses

    Basic Settings menu. At least three (3) years from delivery of this product, Panasonic will give to any third party who contacts us at the contact information provided below, for a charge no more than our cost of physically performing source code distribution, a complete machine-readable copy of the corresponding source code covered under GPL V2.0, LGPL V2.1 or the other licenses with the...

  • Page 90: Index

    Reference Index Favourites [EX97C] ..... . 66 Aspect ......73, 79 Favourites [EX97S] .

  • Page 91: Usb Memories

    Reference Xvid ........8 Setting Auto Setup [EX97C] ....20, 67 Auto Setup [EX97S] .
  • Page 92 Directive for the chemical involved. (Inside of product) [EX97C] [EX97S] Manufactured by: Panasonic Corporation Kadoma, Osaka, Japan Importer for Europe: Panasonic Marketing Europe GmbH Panasonic Testing Centre Winsbergring 15, 22525 Hamburg, Germany Panasonic Corporation Web Site: http://www.panasonic.com SQT0989 F0515TA0...

This manual is also suitable for:

Dmr-ex97s
