  • Page 1 (Canada) Puma 40 9006403C...
  • Page 3 Handicare executes a policy of continuous improvement and reserves the right to changes and modifications. The information provided is valid for the product in its standard version. Handicare can therefore not be held liable for any damage resulting from specifications of the product deviating from the standard configuration.

  • Page 5: Table Of Contents

    Table of contents | 5 Introduction 1.1 This user manual 1.2 Symbols used in this manual Safety 2.1 Temperature 2.2 Electromagnetic radiation 2.3 Moving parts 2.4 Markings on the wheelchair General description 3.1 Main components 3.2 Configurations 3.3 The user 3.4 User environment 3.5 Adjustment options Wheelchair settings...
  • Page 6 6 | Table of contents Warranty 9.1 Provisions of warranty 9.2 Liability provisions...

  • Page 8: Introduction

    If one of the user manuals was not included with your wheelchair, please contact your dealer immediately. In addition to this user manual, there is also a service manual for qualified specialists. CONTACT HANDICARE IF YOU HAVE A VISUAL IMPAIRMENT.

  • Page 9: Safety

    Safety | 9 Safety 2.2 Electromagnetic radiation Warning! The standard version of your electric Always follow the instructions given next to wheelchair has been tested for compliance the warning symbols! Not following these with the applicable requirements regarding instructions may result in physical injury, electromagnetic radiation (EMC requirements).

  • Page 10: Moving Parts

    10 | Safety 2.3 Moving parts Warning! Contact with the moving parts of the wheelchair should be avoided. A wheelchair has moving and rotating parts. Contact with moving parts may result in serious physical injury or damage to the wheelchair. Moving/rotating parts (figure 1) 1.

  • Page 11: Markings On The Wheelchair

    Safety | 11 2.4 Markings on the wheelchair Note! Never remove or cover up the markings, symbols and instructions affixed to the wheelchair. These safety features must remain present and clearly legible throughout the entire lifespan of the wheelchair. Replace or repair any markings, symbols or instructions that have become illegible or damaged immediately.

  • Page 12: General Description

    (FWD, figure 3) or rear wheel-drive (RWD, figure 4). The wheelchair is available in different speeds (6 km/h & 10 km/h). In addition, the Puma 40 can be supplied with two 101248-05_22 different types of tyres (for indoor and outdoor use).

  • Page 13: The User

    General description | 13 3.4 User environment Caution! Parts of the wheelchair that are intended, for servicing or repair, to be removed without the This wheelchair has been designed for both use of tools (e.g. electronics and battery covers) indoor and outdoor use (EN12184 (2009) class can have an adversery effect on the electrical B).

  • Page 14: Adjustment Options

    14 | General description Prevent the wheelchair from coming into contact with sand: sand can permeate into the moving parts of the wheelchair, causing unnecessary fast wear of these parts. 3.5 Adjustment options The wheelchair can be supplied with the following electrical and/or mechanical adjustment options (figure 5): 1.

  • Page 15: Wheelchair Settings

    Wheelchair settings | 15 Wheelchair settings The average wheelchair user does not exist. This is why Handicare wheelchairs can be adjusted according to the specific needs of the user. In this, we make a distinction between wheelchair settings and wheelchair adjustment options. Settings are carried out only once and must be executed by qualified specialists, unless explicitly stated otherwise.

  • Page 16: Controller Height And Depth

    16 | Wheelchair settings In case of doubt, contact the technical support department at Handicare. 4.4 Controller height and depth & Seating system) 4.5 Control system programme This wheelchair is equipped with a control system that can be programmed by adjusting settings within the system.

  • Page 17: Use Of The Wheelchair

    Use of the wheelchair | 17 Use of the wheelchair 5.1 Checking the wheelchair before use Before driving check that: 1. The tyres are sufficiently inflated (see § 6.3). 2. The batteries are sufficiently charged. The green lights on the battery indicator must be on. &...

  • Page 18: Driving The Wheelchair

    18 | Use of the wheelchair Flipping up the central legrest footplate (figure 8) 1. Flip up (A). Sideways transfer Removing the armrest assembly (figure 9) 1. Tip (A) downwards. 2. Remove (B). Folding back the armrest (figure 10) 1. Press (A). 2.
  • Page 19 Use of the wheelchair | 19 Curves by the warnings! The stability and performance of a wheelchair Note! depend on a number of variables. Wheelchairs Never take curves at full speed. Decrease your are adapted to the needs of individual users. speed before taking a curve.

  • Page 20: Obstacles

    20 | Use of the wheelchair 5.4 Obstacles Driving up a kerb 1. Choose the place where the kerb is at its lowest. 2. Drive straight up to the kerb at a right angle to it (20 cm in front of the kerb). 3.

  • Page 21: Pushing The Wheelchair

    Use of the wheelchair | 21 5.6 Pushing the wheelchair The wheelchair can also be moved by pushing. In order to do so, the motors must be disengaged using a freewheel switch. This feature was developed for the attendants of wheelchair users. The freewheel switch has two positions: 1.

  • Page 22: The Wheelchair As A Passenger Seat In A Car

    22 | Use of the wheelchair 5.8 The wheelchair as a passenger seat in a car Note! This wheelchair is crashtested according to ISO 7176- 19 (2008) with a maximum passenger weight of 136 kg. Wheelchairs are not primarily designed to be used as car seats and cannot offer the same degree of safety offered by standard car seats, no matter how securely they have been tied down in the vehicle concerned.
  • Page 23 No changes may be made to the tie-down points/car restraining points on the wheelchair, or to the design of the frame without consulting the manufacturer. The wheelchair should be inspected by a Handicare’s representative before reuse following involvement in any type of vehicle collision.

  • Page 24: Fastening The Seat Belt

    24 | Use of the wheelchair 5.9 Fastening the seat belt Warning! Use the three-point seat belt in order to reduce the risk of head and chest injuries in the event of the wheelchair colliding with parts of the car. The wheelchair should always be inspected by a representative of the manufacturer following any kind of collision.

  • Page 25: Maintenance Of The Wheelchair

    The batteries will then need to be replaced. Note! Warning! Do not use ‘wet’ batteries. The batteries in your PUMA 40 should only be serviced or replaced by a qualified Handicare Take into account the fact that the wheelchair’s dealer technican.
  • Page 26 This cover is between the left and right drive wheel shock absorbers. (Figure 18) If the PUMA 40 is in Front wheel drive configuration, the front riggings will need to be removed to gain access to cover.
  • Page 27 Maintenance of the wheelchair | 27 Flip down the battery guard (Figure 20, #1) and slide the battery guard out of the battery box (Figure 20, #2) Figure 20 Lower the battery tray to the floor by first lifting up on the battery guard (Figure 21, #1a). Then push inward and slowly lower the tray Figure 21, #1b).
  • Page 28 28 | Maintenance of the wheelchair Reconnect new batteries exactly as shown in the battery wiring diagram located on the inner surface of the battery access cover. The battery wiring diagram is also located in the owner’s manual for the controller. Connect the battery cables to the first battery (Figure 23, #1), place it onto the battery tray, and slide it into the battery box.
  • Page 29 Maintenance of the wheelchair | 29 Lift the battery tray back into the battery box by grasping the battery guard then lift the battery tray upward. Then pull the battery tray outward to allow it to dock onto two projection posts on both sides of the battery box.

  • Page 30: Cleaning The Wheelchair

    Tyre pressure Ensure that the controller is switched off while cleaning. If the joystick is accidently touched, the wheelchair can start to move or the Puma 40 electrical options can be operated accidentally. Castor wheel 9” 3.5 bar max. Take care with water in view of the electronic system Castor wheel 10”...

  • Page 31: Decommissioning The Wheelchair

    Maintenance of the wheelchair | 31 6.5 Decommissioning the wheelchair Under normal use and with prescribed maintenance, the wheelchair’s expected lifespan is approximately seven years. The environment If your wheelchair has become superfluous or needs to be replaced, it can usually be taken back by your dealer in consultation.

  • Page 32: Troubleshooting

    32 | Troubleshooting Troubleshooting If the wheelchair is not working as it should, check the following points. • Check whether the batteries are charged. • Turn the wheelchair off and then back on again. • Check whether the battery plugs are all securely in place.

  • Page 33: Technical Specifications

    Climatic tests for electric wheelchairs IPX4 Requirements and test methods for power and control systems ISO 7176-14 for electrically powered wheelchairs 1997 ISO 7176-19 The Puma 40 meets the crash test requirements as described in 75 kg ISO 7176-19 (2008) (2008) 8.2 Technical information Batteries Max.
  • Page 34 34 | Technical specifications Model PUMA 40 Class Description Unit Total length including legrests mm (inch) 1190 (46.9) 1115 (43.9) Total width 13” drive wheels mm (inch) 610 (24) Total width 14” drive wheels mm (inch) 655 (25.8) kg (lbs.) 97,6 (15.4)

  • Page 35: Electric Wiring Diagram

    Technical specifications | 35 8.3 Electric wiring diagram & The electric wiring diagram varies according to the type of controller used ( Controller).
  • Page 36 Handicare uses and/or parts of the are based on the product being used for product have been replaced without the...
  • Page 37 8. Handicare gives no warranty on repair to or reconditioning of the product carried out other than under order of and/or on the instructions of Handicare.
  • Page 38 38 |...
  • Page 39 | 39...
  • Page 40 Dealer: Serial number:...
