INSTRUCTION MANUAL

VHF MARINE TRANSCEIVER
iM502
This device complies with Part 15 of the FCC rules. Operation is sub-
ject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.

Advertisement

Table of Contents
loading

Related Manuals for Icom IC-M502

Summary of Contents for Icom IC-M502

  • Page 1: Instruction Manual

    INSTRUCTION MANUAL VHF MARINE TRANSCEIVER iM502 This device complies with Part 15 of the FCC rules. Operation is sub- ject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 2: Important

    This in- before using the transceiver. struction manual contains important operating instructions for the IC-M502. IN CASE OF EMERGENCY If your vessel requires assistance, contact other vessels and Or, transmit your distress call using digital selective calling on the Coast Guard by sending a distress call on channel 16.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS I Position and time programming ..14 IMPORTANT ..........i 12 SPECIFICATIONS AND I Position indication ......15 IN CASE OF EMERGENCY ...... i OPTIONS ......42 – 43 I Distress call ........16 TABLE OF CONTENTS ......ii I Specifications .......

  • Page 4: Cautions

    Changes or modifications to this device, not ex- hot when operating continuously for long periods. pressly approved by Icom Inc., could void your authority to operate this device under FCC regulations. Place the transceiver in a secure place to avoid inadvertent NEVER use by children.

  • Page 5: Operating Rules

    OPERATING RULES (2) OPERATOR’S LICENSE PRIORITIES A Restricted Radiotelephone Operator Permit is the license • Read all rules and regulations pertaining to priorities and most often held by small vessel radio operators when a radio keep an up-to-date copy handy. Safety and distress calls is not required for safety purposes.

  • Page 6: Panel Description

    PANEL DESCRIPTION I Panel description q POWER SWITCH [POWER] r TRANSMIT POWER SWITCH [HI/LO] ➥ Toggles high and low power when pushed. (p. 8) Push to toggle the transceiver power ON and OFF. • Some channels are set to low power only. w VOLUME CONTROL [VOL] ➥...
  • Page 7 PANEL DESCRIPTION ➥ While pushing [HI/LO], rotate [CHANNEL] to adjust the i DISTRESS SWITCH [DISTRESS] brightness of the LCD and switch backlight. Transmits distress call when pushed for 5 sec. (p. 16) y ATTENUATOR/INTERCOM/SCRAMBLER SWITCH o CHANNEL/DUALWATCH/TRI-WATCH SWITCH [LO/DX•IC•SCR] [CH/WX•DW•U/I/C] ➥...

  • Page 8: I Function Display

    PANEL DESCRIPTION I Function display ➥ “Low battery” flashes when the battery voltage drops to approx. 10 V DC or below. ➥ “DUAL” appears during dualwatch; “TRI” appears dur- ing tri-watch. (p. 11) t SCRAMBLER INDICATOR (p. 10) Appears when an optional voice scrambler is activated. y DUPLEX INDICATOR (p.

  • Page 9: I Microphone

    PANEL DESCRIPTION I Microphone q PTT SWITCH [PTT] Push and hold to transmit; release to receive. (p. 8) w CHANNEL UP/DOWN SWITCHES [Y Y ]/[Z Z ] Push either switch to change the operating memory chan- nel, set mode contents, etc. (p. 8) e TRANSMIT POWER SWITCH [HI/LO] ➥...

  • Page 10: Basic Operation

    BASIC OPERATION I Channel selection ➥ Push [16•9] for 1 sec. to select the call channel of the se- lected channel group. • “CALL” and call channel number appear. Channel 16 • Each channel group may have an independent call channel after Channel 16 is the distress and safety channel.

  • Page 11: I Microphone Lock Function

    BASIC OPERATION • “DUP” appears for duplex channels. “Weather alert” on p. 31. • “A” appears for simplex channels. q Push [CH/WX] once or twice to select a weather channel. • “WEATHER” appears when a weather channel is selected. “WX ALT”...

  • Page 12: I Receiving And Transmitting

    BASIC OPERATION I Receiving and transmitting u Push and hold [PTT] to transmit, then speak into the mi- crophone. CAUTION: • “TX” appears. Transmitting without an antenna may dam- • Channel 70 cannot be used for transmission (for GMDSS use). age the transceiver.

  • Page 13: I Call Channel Programming

    BASIC OPERATION I Call channel programming I Channel names The call channel is used to select channel 9, however, you Memory channels can be tagged with alphanumeric names can program your most often-used channels in each channel of up to 10 characters each. group for quick recall.

  • Page 14: I Optional Voice Scrambler Operation

    BASIC OPERATION I Optional voice scrambler operation Activating the scrambler Programming scrambler codes The optional voice scrambler provides private communica- There are 128 or 32 codes (0 to 127 or 1 to 32) available for tions. In order to receive or send scrambled transmissions programming when the optional UT-98 or UT-112 is installed.

  • Page 15: Dualwatch/Tri-Watch

    DUAL WATCH/TRI-WATCH I Description I Operation q Select the desired operating channel. Dualwatch monitors channel 16 while you are receiving an- w Select dualwatch or tri-watch in set mode. (p. 31) other channel; tri-watch monitors channel 16 and the call e Push [CH/WX•DW•U/I/C] for 1 sec.

  • Page 16: Scan Operations

    SCAN OPERATIONS I Scan types Scanning is an efficient way to locate signals quickly over a Set the tag channels (scanned channel) before scanning. wide frequency range. The transceiver has priority scan and Clear the tag channels which inconveniently stop scanning, normal scan.

  • Page 17: I Setting Tag Channels

    SCAN OPERATION I Setting tag channels I Starting a scan For more efficient scanning, add desired channels as tag Set scan type (priority or normal scan) and scan resume timer channels or clear tag channels for unwanted channels. Chan- in advance using set mode. (p. 31) nels set as non-tag channels will be skipped during scanning.

  • Page 18: Dsc Operation

    DSC OPERATION I MMSI code programming I Position and time programming The 9-digit MMSI (DSC self ID) code can be programmed at A distress call should include the ship’s position and time. If power ON. no GPS is connected, your position and UTC (Universal Time Coordinated) time should be input.

  • Page 19: I Position Indication

    When no GPS receiver is connected, the transceiver displays the manually entered position and time. A GPS receiver appropriate for the IC-M502 is not supplied from Icom. An NMEA0183 ver. 2.0 is required for position in- t Rotate the channel selector to select the digit of current dication.

  • Page 20: I Distress Call

    DSC OPERATION I Distress call A distress call should be transmitted if, in the opinion of the Master, the ship or a person is in distress and requires imme- diate assistance. r When receiving the acknowledgment, reply to the con- NEVER USE THE DISTRESS CALL WHEN nected station via the microphone.

  • Page 21: I Transmitting Dsc Calls

    DSC OPERATION I Transmitting DSC calls t Push [DSC/ENT] to transmit the individual call. • Channel 70 is selected and the individual call is transmitted to the selected station. Transmitting individual call • If channel 70 is busy, the transceiver standbys until the channel The individual call function allows you to transmit a DSC sig- becomes clear.
  • Page 22 DSC OPERATION Transmitting individual acknowledgement Transmit an acknowledgement (‘able to comply’ or ‘unable to comply’) when an individual call for you is received. q Select a desired channel other than channel 70. w Push [DSC/ENT] to select the DSC menu. y If you select ‘Unable,’...
  • Page 23 DSC OPERATION t The all ships call has been transmitted. Transmitting all ships call Large ships use channel 70 as their “listening channel.” When you want to announce a message to these ships, use the “all ships call” function. q Select a desired channel other than channel 70. w Push [DSC/ENT] to select the DSC menu.
  • Page 24 DSC OPERATION Transmitting position request call Transmit a position request call when you want to know your friend’s current position, etc. q Select a desired channel other than channel 70. w Push [DSC/ENT] to select the DSC menu. y Push [PTT] or rotate the channel selector to exit the condi- e Rotate the channel selector to select “POS request”...

  • Page 25: I Setting The Distress Information

    DSC OPERATION I Setting the distress information r The position information appears. Set the current position, then push [DSC/ENT]. • Rotate the channel selector to select the character. The nature of the distress call should be included in the dis- •...

  • Page 26: I Dsc Individual Id

    DSC OPERATION I DSC individual ID A total of 40 DSC address ID’s can be programmed and named with up to 10 characters. Programming address ID t Push [DSC/ENT] to program and to exit the condition. q Push [DSC/ENT] to select the DSC menu. w Rotate the channel selector to select “Set-up”...

  • Page 27: I Receiving Dsc Calls

    DSC OPERATION I Receiving DSC calls r Select the desired ID name with the channel selector, then push [DSC/ENT]. Receiving a distress call While monitoring channel 70 and a distress call is received: ➥ Emergency alarm sounds for 2 minutes. •...
  • Page 28 DSC OPERATION Receiving a distress relay acknowledgement Receiving an all ships call While monitoring channel 70 and a distress relay acknowl- While monitoring channel 70 and an all ships call is received: ➥ Emergency alarm sounds when the category is “Distress” edgement is received: ➥...
  • Page 29 DSC OPERATION Receiving a position reply call While monitoring channel 70 and a position reply call (for the area you are in) is received: ➥ “Received POS” appears in the display. Receiving a geographical area call While monitoring channel 70 and a geographical area call (for the area you are in) is received: ➥...

  • Page 30: I Dsc Set Mode

    DSC OPERATION I DSC set mode r Set the offset time from the UTC (Universal Time Coordi- nated) time, then push [DSC/ENT]. • Rotate the channel selector to select the number, ‘+’ or ‘–.’ Offset time • Push [CH/WX] to advance the cursor. This item sets the offset time from the UTC (Universal Time •...
  • Page 31 DSC OPERATION MMSI code check The 9-digit MMSI (DSC self ID) code can be checked in set mode. q Push [DSC/ENT] to select the DSC menu. w Rotate the channel selector to select “Set-up” and push [DSC/ENT]. e Rotate the channel selector to select ‘MMSI check,’ then push [DSC/ENT].

  • Page 32: I Receive Messages

    DSC OPERATION I Receive messages t Rotate the channel selector to scroll the message. • The stored message has several information and depends on the distress call types. The transceiver automatically stores up to 20 distress mes- sages and 20 other messages. The messages can be used as an assistance to the logbook.

  • Page 33: Intercom Operation

    • When a WX alert is received, “WX ALT” flashes and a • “TALK” or “LSTN” appears on the caller or listener function dis- play, respectively. beep sounds. The WX alert sounds after the intercom use • To adjust the IC-M502’s speaker output level, rotate [VOL]. is finished.

  • Page 34: Set Mode

    SET MODE I Set mode programming q Turn power OFF. Set mode is used to change the conditions of the trans- w While pushing [16•9], turn power ON to enter set mode. ceiver’s functions: scan mode (normal or priority), scan re- e After the display appears, release [16•9].

  • Page 35: I Set Mode Items

    SET MODE I Set mode items Weather alert An NOAA broadcast station transmits a weather alert tone be- Scan mode fore important weather information. When the weather alert function is turned ON, the transceiver detects the alert, then The transceiver has 2 scan modes: normal scan and priority flashes the “WX ALT”...
  • Page 36 SET MODE DSC watch DSC watch monitors channel 70 while you are receiving an- other channel. If a distress signal is received on channel 70, the transceiver monitors channel 16 and 70 alternately until the distress sig- nal disappears. If a signal is received on another channel, DSC watch pauses until the signal disappears.

  • Page 37: Set Mode

    SET MODE LCD contrast Scrambler code This item adjusts the contrast of the LCD in 8 steps. When an optional scrambler unit is connected, the scrambler code can be set depending on dealer setting. When the UT-98 or UT-112 is installed, 128 or 32 codes (0 to 127 or 1 to 32) can be selected, respectively.

  • Page 38: Connections And Maintenance

    CONNECTIONS AND MAINTENANCE I Supplied accessories I Antenna The following accessories are supplied: Qty. A key element in the performance of any communication sys- q Mounting bracket ............1 tem is an antenna. Ask your dealer about antennas and the w Microphone hanger (OPC-562) ........

  • Page 39: I Connections

    CONNECTIONS AND MAINTENANCE I Connections CAUTION: Transmitting without an antenna may dam- age the transceiver. r GPS RECEIVER JACK Connects to an optional GPS receiver to input the position data and time data. • An NMEA0183 ver. 2.0 is required for position or time indication, etc.

  • Page 40: I Mounting The Transceiver

    CONNECTIONS AND MAINTENANCE I Mounting the transceiver • OVERHEAD MOUNTING Using the supplied mounting bracket The universal mounting bracket supplied with your transceiver allows overhead or dashboard mounting. • Mount the transceiver securely with the 2 supplied screws (M5 × 20) to a surface which is more than 10 mm thick and can support more than 5 kg.
  • Page 41 CONNECTIONS AND MAINTENANCE r Attach the clamps on either side of the IC-M502. Using the optional mounting bracket • Make sure that the clamps align parallel to the IC-M502’s body. An optional MB-75 is available for mounting FLUSH MOUNT the transceiver to a flat surface such as an instrument panel.

  • Page 42: I Optional Unit Installation

    CONNECTIONS AND MAINTENANCE I Optional unit installation CAUTION: w Remove the 4 screws from the shielding plate, then lift up DISCONNECT the DC power cable from the transceiver before performing any work on the transceiver. the shielding plate. e Plug an optional unit to J6 on the MAIN unit as shown Otherwise, there is danger of electric shock and/or equip- ment damage.

  • Page 43: I Dimensions

    CONNECTIONS AND MAINTENANCE I Dimensions...

  • Page 44: Troubleshooting

    TROUBLESHOOTING...

  • Page 45: Channel List

    CHANNEL LIST NOTE: Simplex channels, 3, 21, 23, 61, 64, 81, 82 and 83 CANNOT be lawfully used by the general public in U.S.A. waters.

  • Page 46: Specifications And Options

    SPECIFICATIONS AND OPTIONS I Specifications General Receiver • Frequency coverage • Receive system : Double conversion Transmit 156.025–157.425 MHz superheterodyne Receive 156.050–163.275 MHz • Sensitivity (12 dB SINAD) : Less than 0.25 µV (typical) • Mode : FM (16K0G3E) • Squelch sensitivity : Less than 0.3 µV DSC (16K0G2B) •...

  • Page 47: I Options

    SPECIFICATION AND OPTIONS I Options • MB-75 FLUSH MOUNT For mounting the transceiver to a panel. • SP-5 EXTERNAL SPEAKER A large, external speaker for superior audio output. • SP-10 EXTERNAL SPEAKER A compact, external speaker. Features easy installation. • UT-98 VOICE SCRAMBLER UNIT (pgs. 10, 33) •...

  • Page 48: Hm-127 Remote-Control Microphone

    Push and hold to transmit; release to receive. e CHANNEL UP/DOWN SWITCHES [Y Y ]/[Z Z ] The optional HM-127 remotely controls the IC-M502 and pro- ➥ Push either switch to change the operating channel, set vides an optional intercom function.
  • Page 49 • Some channels are set to low power only. ➥ While pushing this switch, other switches perform sec- (pgs. 29, 56) ➥ Calls the IC-M502 when pushed and held while in inter- ondary functions. ➥ Toggles the all key lock function ON or OFF when com mode.

  • Page 50: I Function Display

    HM-127 REMOTE-CONTROL MICROPHONE I Function display ➥ In set mode, indicates the selected condition. (pgs. 30, r VOLUME INDICATOR (p. 51) Appears while audio output level is adjusted. t SQUELCH INDICATOR (p. 51) Appears while noise squelch level is adjusted. y CHANNEL NAME INDICATOR ➥...

  • Page 51: I Hm-127 Supplied Accessories

    HM-127 REMOTE-CONTROL MICROPHONE I HM-127 supplied accessories !1 DUAL/TRI WATCH INDICATOR (pgs. 11, 54) “DUAL” appears during dualwatch; “TRI” during tri-watch. Accessories included with the HM-127: Qty. !2 WEATHER CHANNEL INDICATOR (pgs. 7, 50) q Connection cable (OPC-1000: 6 m; 20 ft) ...... 1 ➥...

  • Page 52: I Installation

    HM-127 REMOTE-CONTROL MICROPHONE I Installation w To use the supplied cable as a wall socket, follow the fol- lowing steps. e Using the mounting base, carefully mark off the 2 spots The optional HM-127 can be connected to the transceiver di- where the cable and screws will be fastened.
  • Page 53 HM-127 REMOTE-CONTROL MICROPHONE...

  • Page 54: I Channel Selection

    HM-127 REMOTE-CONTROL MICROPHONE I Channel selection Channel 16 U.S.A., International and Canadian q Push [16] to select channel 16. channels w Push [CH/WX] to return to the q Push [CH/WX] to select regular channel. condition before selecting chan- • Push [CH/WX] again, if weather channel appears. nel 16, or push [Y] or [Z] to se- w Push [CH/WX•U/I/C], while pushing [H/L], to select chan- lect operating channel.

  • Page 55: I Receiving And Transmitting

    HM-127 REMOTE-CONTROL MICROPHONE I Receiving and transmitting t Push and hold [PTT] to transmit, then speak into the mi- q Push [PWR] to turn power ON. crophone. w Push [VOL], then [Y]/[Z] to adjust audio output level. • “ ” appears. •...

  • Page 56: I Lock Functions

    HM-127 REMOTE-CONTROL MICROPHONE I Lock functions I Display backlighting The lock function electronically locks keys and switches to The function display and switches can be backlit for better prevent accidental changes and function access from the mi- visibility under low light conditions. And the backlighting con- crophone.

  • Page 57: I Call Channel Programming

    HM-127 REMOTE-CONTROL MICROPHONE I Call channel programming I Optional voice scrambler operation q Push [CH/WX•U/I/C] several times while pushing [H/L] to select the Activating the scrambler desired channel group (USA, INT, q Select an operating channel, except channel 16 or weather CAN) to be programmed.

  • Page 58: I Starting A Scan

    HM-127 REMOTE-CONTROL MICROPHONE I Starting a scan I Setting tag I Dualwatch/Tri- channels watch operation q Push [CH/WX•U/I/C] several times while pushing [H/L] to select the q Push [CH/WX•U/I/C] several times q Push [Y]/[Z] to select the desired channel group (USA, INT, CAN), if while pushing [H/L] to select the channel.

  • Page 59: I Set Mode Programming

    HM-127 REMOTE-CONTROL MICROPHONE I Set mode programming Set mode is used to change the condition of the transceiver’s • Beep tone “BEEP” ➥ Push [Y] to turn ON, [Z] to turn OFF the beep output. functions and the microphone’s own functions: Transceiver’s functions—...

  • Page 60: I Intercom Operation

    HM-127 REMOTE-CONTROL MICROPHONE I Intercom operation I Channel names q Push [LO/DX•IC] for 1 sec. to ac- q Push [Y]/[Z] to select a channel to program. tivate the intercom function. • Push [CH/WX•U/I/C] several times while pushing [H/L] to select the channel group (USA, INT, CAN), if desired.

  • Page 61: Template

    TEMPLATE...
  • Page 62 Count on us! A-5663H-1EX-r Printed in Japan 1-1-32 Kamiminami, Hirano-ku, Osaka 547-0003 Japan © 2000 Icom Inc.
