- Page 1 Operating and Installation Instructions Ceramic Cooktop KM 5820 en - US, CA To prevent accidents and appliance damage, read these instructions before installation or use. M.-Nr. 07 844 700...
-
Page 3: Table Of Contents
Clean the cooktop ........ -
Page 4: Important Safety Instructions
SAVE THESE INSTRUCTIONS for a future user. Correct usage Only use the cooktop for residential cooking, and for the purposes described in this manual. Other uses are not permitted and can be dangerous. - Page 5 Technical safety Installation, repair and maintenance work should be performed by a Miele authorized service technician. Work by unqualified persons could be dangerous and may void the warranty. Be sure your appliance is properly installed and grounded by a qualified technician.
- Page 6 COOKING AREA - During operation, the cooking area and its surroundings will get hot and can cause burns. When the cooktop is shut off, the surface may remain hot enough to cause harm, even though the glow is not visible through the dark glass.
- Page 7 IMPORTANT SAFETY INSTRUCTIONS To prevent damage to the cooktop do not use pots and pans with thin bases on the cooktop. Never heat an empty pan unless the pan manufacturer states that you can do so. Before using glass, glass/ceramic,...
- Page 8 NEVER set down hot pots or pans in the area of the control panel. This can damage the underlying electronics. If the cooktop built in behind a cabinet door, it should only be operated with the door open. Close the door only when the appliance is shut off and the Residual Heat indicators have gone out.
-
Page 9: Description Of The Appliance
Cooktop Three-zone variable burner Two-zone variable burner One-zone burner Control panel Burner Left 5 11/16" Right rear Right front 5 11/16" Description of the appliance C Diameter inches 14.5 8 1/4" 10 5/8" 4 3/4" 7 1/16" 14.5 Output in watts at... -
Page 10: Control Panel
Description of the appliance Control panel... - Page 11 Touch controls Cooktop On/Off Settings bar - Setting the power level - Setting the time Child safety lock Variable burner On/Off Burner On/Off Stop and Go - Timer activation - Switching between timer functions - Selecting the shut-off time (see "Automatic burner shut-off")
-
Page 12: Before Using For The First Time
Heat the cooktop Only for facet cooktops: A small gap between the cooktop and the work surface may be visible in the first days of operation. It will become smaller during use. Despite this small gap, the electrical safety of your appliance is always ensured. -
Page 13: How The Burners Operate
One-zone burners use one heating strip; two-zone burners and grill zones have two heating strips. Depending on the model, the heating strips may be separated by a ring. Each burner has overheating protection (internal temperature limiter) feature to prevent the ceramic glass from overheating (see "Overheat protection"). -
Page 14: Use
^ Touch the s On/Off touch control . The power-ON indicator will turn on and - will appear in all the burner displays. If no further entry is made, the cooktop will turn itself off after a few seconds for safety. -
Page 15: Power Settings
Power settings The cooktop is factory-programmed with 9 power levels. If you would like finer setting control, you can extend the power levels (see "Programming"). The intermediate levels will appear with a lighted dot next to the number. Cooking process Melting butter, chocolate, etc. -
Page 16: Cooking With Auto-Heat
Cooking with Auto-heat When Auto heat-up has been activated, the burner automatically turns on at the highest setting (heat-up boost) and then switches to the previously selected continued power level. The heat-up time depends on which continued power level has been chosen (see chart). -
Page 17: Variable Burner
Variable burner With some cooktop models (see "Description of the appliance"), you can turn on a second or third burner zone when using larger pots. If you add another burner zone, the indicator light will be on as long as the power level is flashing in the burner display. -
Page 18: Turning Off And Residual Heat Indicators
A 0 flashes for a few seconds in the burner display. If the burner is still hot, the residual heat will be displayed. To turn the cooktop off ^ Touch the s touch control. This turns off all the burners. The power-ON indicator light goes out. -
Page 19: Selecting Cookware
These melt at high temperatures. – Copper bottom and aluminum pans may leave a residue on the cooktop in the form of metallic lines. This is normal. These lines can be removed using a non-abrasive ceramic cooktop cleaner or a shielded scraper blade. -
Page 20: Timer
Timer The cooktop must be turned on to use the timer. The timer can be used for two different functions: – To time kitchen activities. – To set a burner to turn off automatically. You can select a time from 1 minute (01) to 9 hours (9^). -
Page 21: Setting The Timer
Setting the timer Minutes Example: You want to set a time of 15 minutes. ^ Turn the cooktop on. ^ Touch the m control. 00 appears in the timer display, and the right 0 will flash. ^ Touch the first number of the time you wish to set (in this case 1) on the settings bar. - Page 22 Timer To change the set time ^ Touch the m control. ^ Set the desired time as described in "Setting the timer". To clear the set time ^ Touch and hold the m control until 00 appears in the timer display.
-
Page 23: Turning A Burner Off Automatically
Turning a burner off automatically You are able to set a time in which a burner turns off automatically. If desired, all of the burners can be programmed at the same time. If the programmed time is longer than the maximum time allowed, the burner will turn off automatically after the maximum time allowed (see "Safety cut-out feature"). -
Page 24: Using Both Timer Functions At The Same Time
Timer Using both timer functions at the same time The kitchen timer and automatic shut-off functions can be used at the same time. If you have programmed one or more shut-off times and would also like to set the kitchen timer: Tap the m touch control until the indicator lights for the programmed burners come on steady and 00... -
Page 25: Safety Features
Child safety lock / System lock Your appliance is equipped with a safety lock to prevent the cooktop and the burners from accidentally being turned on or any settings changed. The Child safety lock can be activated when the cooktop is turned on. When... -
Page 26: Stop And Go
1. The burner power-levels and the timer setting cannot be changed, the cooktop can only be turned off. When Stop and Go is deactivated, the cooking zones resume at the power level which was last set. -
Page 27: Safety Shut-Off
An F will flash in the timer display. ^ Clean the control panel or remove the object covering the control. F will go out. The cooktop can now be time in hours used again. Safety features... -
Page 28: Overheat Protection
Safety features Overheat protection Each burner is equipped with a temperature limiter. This feature automatically turns off the heating element before the glass ceramic surface becomes too hot. When the overheat protection is triggered, the heating element turns on and off even at the highest power level. Once the glass ceramic surface has cooled to a safe temperature the heating element will automatically turn... -
Page 29: Cleaning And Care
Stubborn soiling is best removed with a shielded scraper blade. ^ Apply a ceramic cleaner (available from Miele) using a soft cloth or paper towel. ^ To remove any limescale deposits or metallic residue apply a ceramic cleaner using a soft cloth or use a shielded scraper blade if necessary. -
Page 30: Programming
This is completed when an indicator above the On/Off s touch control lights up briefly. Do not turn the cooktop on again until the reset process is completed. To start programming ^ With the cooktop turned off, touch... - Page 31 Program* P 00 Demo mode and factory default settings P 02 Extended power levels P 04 Keypad tone when a control is touched P 05 Audible timer tone P 06 Child safety lock * Programs / Settings not listed here have no allocation. ** The factory default settings are shown in bold.
- Page 32 Programming Program* System lock Auto-heat Second burner zone of the left front burner Second burner zone of the right front burner Second burner zone of the right back burner Second burner zone of the center back burner Audible tone when the touch control areas are accidentally covered Touch control reaction...
-
Page 33: Frequently Asked Questions
"dE" appears in the timer display for several seconds after switching on the cooktop. Burners do not heat up. The device is in demo mode. Deactivate demo mode (see "Programming"). The cooktop turns off while it is in use. One of the burners has been on for too long. - Page 34 Frequently asked questions The cooktop turns off while in use, and a flashing F appears in the timer display. Possible fault One or several of the touch controls are covered, for example by fingers, food boiling over or by an object.
- Page 35 Frequently asked questions Solution First, ensure that the cooktop is not in direct sunlight or strong artificial light and that the area around the cooktop is not too dark. Make sure that neither the cooktop or the touch controls are covered.
-
Page 36: Technical Service
In the event of a fault which you cannot easily fix yourself, please contact the Miele Technical Service Department at the address on the back of this booklet. When contacting Technical Service please quote the serial number and model of the appliance. -
Page 37: Installation Instructions
Installation Instructions IMPORTANT: SAVE FOR THE LOCAL ELECTRICAL INSPECTOR'S USE Information is subject to change. Please refer to our website to obtain the most current product specification, technical & warranty information. To prevent accidents and appliance damage read these instructions before installation or use. -
Page 38: Important Installation Safety Instructions
However, under certain conditions it may be possible for installation in these applications. Please contact the Miele Technical Service Department with specific requirements. You must ensure the power cable... -
Page 39: Safety Distances Above The Appliance
Safety distance from divider Installation of a divider under the cooktop is not required. If a divider is fitted under the cooktop, the distance between the upper edge of the work surface and the upper edge of the divider must be at least 4 ½ "... - Page 40 IMPORTANT INSTALLATION SAFETY INSTRUCTIONS Safety distances to the sides of the appliance The appliance should only be installed as shown in the illustrations, while maintaining the required safety distances shown. Do not install the appliance between two tall cabinets, this is a fire hazard. 1 5/8""...
-
Page 41: Installation
Safety distance from the wall covering If a wall covering is installed, a minimum safety distance must be maintained between the countertop cut-out and the covering, since high temperatures can damage these materials. If the covering is made of a combustible material (such as wood), the distance between the countertop cut-out and the wall covering must be a minimum of 2"... -
Page 42: Sealing
Installation Frame/Facet Cooktops Sealing The appliance must not be permanently sealed into the countertop when installed. The sealing strip under the edge of the appliance provides a sufficient seal for the countertop. If the appliance is sealed into position, the countertop or appliance could be damaged if it needs to be removed for maintenance or service. -
Page 43: Installation Dimensions
Installation dimensions Spring clips Front Installation height Connecting cable, Length = 56 11/16" (1440 mm) Rating label... -
Page 44: Installation
"Installation dimensions" of each unit. Facet cooktops: A special sealing strip ensures the slip-proof seating of the cooktop in the cutout. The gap between the frame and the countertop will narrow after a little time has passed. ^ Create the countertop cutout as shown in the "Installation... - Page 45 (for facet cooktops only) The spring clips and the securing strips must be on or flush with the top edge of the cooktop. ^ Coat the lateral edges and the lower edge of the spring clips and securing strips with silicon.
- Page 46 Installation Insert the cooktop ^ Feed the power cord down through the cut-out. ^ Place the cooktop lightly on the spring clips. ^ With a hand on each side of the appliance press down evenly on the edges until it clicks into position.
-
Page 47: Electrical Connection
CAUTION: Before installation or servicing, disconnect the power supply by either removing the fuse, shutting off the main power or manually "tripping" the circuit breaker. Installation work and repairs should only be performed by a qualified technician in accordance with all applicable codes and standards. -
Page 48: Help Protect Our Environment
Help protect our environment Disposal of packing materials The cardboard box and packing materials are biodegradable and recyclable. Please recycle. Ensure that any plastic wrappings, bags, etc. are disposed of safely and kept out of the reach of children. Danger of suffocation! Disposal of an old appliance Old appliances contain materials that can be recycled. - Page 52 Alteration rights reserved / 4210 M.-Nr. 07 844 700 / 01 INFORMATION IS SUBJECT TO CHANGE. PLEASE REFER TO OUR WEBSITE TO OBTAIN THE MOST CURRENT PRODUCT SPECIFICATIONS, TECHNICAL & WARRANTY INFORMATION.
