3 Top Right Button — When the handset is off hook, this button invokes
the action list for a corresponding call. When a phone call is associated
with the button, the button opens or closes a call action list. Scroll
through the list and select an action by pressing the corresponding right
button or press the Select button (see 6).
When the handset is on hook, this button displays the Personal Speed
Dial Index.
Middle Right Button — When the handset is off hook, this button
invokes the action list for a corresponding call. When a phone call is
associated with the button, the button opens or closes a call action list.
Scroll through the list and select an action by pressing the corresponding
right button or press the Select button (see 6).
When the handset is on hook, this button displays the Systm Speed Dial
Index.
Bottom Right Button — Displays a list of Advanced Settings that
provides users access to configure the phone to the call processor server.
Settings include:
Set Primary PBX IP — sets the primary IP address of the call
processor server
Set Secondary PBX IP — sets the secondary IP address of the call
processor server
Set Dialing Domain — sets the dialing domain for your phone. The
default dialing domain is 000.000.000.000.
Set My Phone Number — set the phone number for the phone
Set My Password — sets the user password
Change Login Status — sets the login status associated with the
system.
Set External IP — sets the IP address of the Media Gateway for the
external telephone network
View Debug Events — used by network administrators
Refer to the VCX System Administrator's Guide for details on how to use
the Advanced Settings feature.
4 Access Buttons — Your administrator assigns default functions for these
buttons and may allow you to reprogram a button's function (for
example, create more personal speed dial buttons). See
and Status Lights for Access
Telephone Buttons and Controls
Buttons.
