108 A A: T
PPENDIX ELEPHONE
Attaching and
Adjusting the
Articulating
Support Bracket
I M
NSTALLATION AND AINTENANCE
The articulating support bracket is common to the following devices:
3Com 3105 Attendant Console
3Com 3103 Manager's Telephone
Figure 6, Figure 7, and
apply to all telephones.
Figure 6 Attaching the Support Bracket
2
Figure 8 show a 3102 Telephone. The instructions
3
To attach the support
bracket, 1, snap the
bracket into the
mounting supports 2,
on the bottom of the
telephone.
After you connect the
1
cables to the phone,
press the cables into
the cable management
clamps 3, on the stand.
