Philips Cafe Essence HD 7605/A Service Manual

Service
Service
Service
!
Service
Information
Philips Domestic Appliances and Personal Care
PRODUCT INFORMATION
Voltage : 100, 120, 230V
Frequency : 50 - 60Hz
Power consumption : 850 + 550W
Contents jug : 1200cc
Coloursetting : ceramic white
SERVICE INFORMATION
Thermostat switch-off temp : 140°C
Thermal fuse cut-off temp : 298°C
REPAIR INSTRUCTIONS
1.
Electrical circuit
When the appliance does not work, check the electrical
circuit. If the thermal fuse or thermostat prove defective,
the complete pump unit has to be replaced.
2. De-scaling
If the water system is nearly or less clogged by scale
then operate the coffeemaker a few times with vinegar
or with a 10-15% solution of either vinegar-acid, citric
acid or tartar-acid, into cold tap water.
Do not use other de-scaling agents as these may harm
the appliance.
If this procedure does not restore the function, then switch
off the coffeemaker when the acid has passed through
during appr. 3 min. Keep the appliance in this condition
overnight and continue/repeat the cleaning operation.
After the de-scaling procedure, operate the coffeemaker
twice with tap water in order to rinse away any residual
substances.
Published by Philips Domestic Appliances and Personal Care
4322 277 00317
00/05
PCS 104 827
Coffee maker "Café Essence"
Service Manual 4322 277 00046 is herewith cancelled
3. Pump unit removal
To separate the pump unit from the hotplate unit (item 23),
the two plastic snaps at place A have to be loosened.
Then the pump unit can be lifted out easily.
4. Exchanging the switch unit
Remove the panel (13) by carefully pushing a small
screwdriver into the chink at point A and moving it towards
to point B (see exploded view). Do not damage the housing.
If the panel has been damaged, get a new one.
PRODUCTS MEETS THE REQUIREMENTS REGARDING
INTERFERENCE SUPPRESION ON RADIO AND TELEVISION.
- AFTER THE PRODUCT HAS BEEN REPAIRED IT SHOULD
FUNCTION PROPERLY AND HAS TO MEET THE SAFETY
REQUIREMENTS AS LAID DOWN OFFICIALLY ESTABLISHED
AT THIS MOMENT.
©
Printed in The Netherlands Copyright reserved
HD 7605/A
8827 605 00000
ROTARY
AUTO
SWITCH
SHUT
OFF
850W
Subject to modification
MSH coding
550W
