U-Line 3036RR Quick Reference Manual

QUICK REFERENCE GUIDE

3036RR
36" Solid Door Refrigerator
•
STAINLESS
SOLID

MODEL DETAILS

Model
U-3036RRS-00A
U-3036RRINT-00A
ACCESSORIES
Model
23074
23073
80-33027-00
INTEGRATED
SOLID
Voltage/Hz Door Swing
115 / 60 Double Doors
115 / 60 Double Doors
Description
Professional Door Handle, 1 1/4" Diameter (1 handle per box)
Commercial Door Handle, 7/8" Diameter
18" Slide and Divide Bin Organizer
Modular 3000 Series
•
FEATURES & BENEFITS
•
Volume of 6.9 cu ft holds up to 136 bottles (12 oz) or
208 cans (12 oz)
•
Temperature range: 34°F -70°F
•
Convection cooling system rapidly and efficiently takes items to
the set temperature
•
U-Select Control offers five distinct modes:
®
Beverage: 34°F - 65°F, Deli: 34°F - 40°F, Market: 34°F - 40°F,
Pantry: 34°F - 70°F, Root Cellar: 45°F - 55°F
•
U-Select Control with digital OLED display is ergonomically
®
located on top of door
•
Maintains temperature to within 1°F of the set point to maximize
preservation
•
Independently controlled dual-zones
•
Black interior is illuminated with LED theater lighting
•
Three full-extension, slide-out drawers in each compartment are
removable for easy cleaning
•
The middle bins have two possible positions and come with a
removable glass shelf to keep products stable
•
The lower bins are large enough to fit 2 one-gallon containers
with additional space for more storage
•
Standard commercial stainless steel handle is interchangeable
with professional handle accessory
•
Robust, concealed and covered hinges with built-in door stop
and closer
•
Adjustable grille can be shifted front-to-back and up-and-down
•
Integrated model requires 3/4" custom door panel (panels not
supplied by U-Line)
•
Grille can accept an integrated toe-kick
•
Four independently adjustable leveling legs; rear legs are
adjustable from the front for ease of installation
Finish
Stainless Solid
Integrated Solid
Finish
Stainless
Stainless
na
Shipping Weight
221 lbs
205 lbs
Shipping Weight
2 lbs
2 lbs
2 lbs
