- Page 1 P6615 WARNING IMPORTANT! KEEP INSTRUCTIONS FOR FUTURE REFERENCE. www.fisher-price.co.uk...
- Page 2 Important! DANGER To prevent electric shock, do not immerse in water; wipe clean with damp cloth. Do not expose the product to rain or moisture. Do not place objects filled with liquids on or near the product. WARNING To prevent strangulation with power cord, never place transmitter within reach of child.
- Page 3 • Transmitter operates on AC current. Receiver operates on AC current (use enclosed AC adaptor) or 3,6V, 750 mAh NiMH rechargeable battery pack (included). • Before first time use, charge the rechargeable battery pack for four hours. • Adult assembly is required for wall mounting. Tools needed for assembly: electric drill, 7mm (.25 inch) drill bit, hammer, Phillips screwdriver (tools not included). • Adult setup is required. • This product is not intended to be used as a medical monitor and its use should not replace adult supervision. • Test sound/video reception of receiver before first-time use and whenever you change location of the transmitter. • Adults Note: Periodically examine this product for damage to the cord, housing or other parts that may result in the risk of fire, electric shock or injury. If the product is damaged, do not use it. • Never use extension cords with the AC adaptor. • Never use transmitter or receiver near water (i.e. bathtub, sink, wet basement, etc.). • Always use transmitter and receiver where there is adequate ventilation. To prevent overheating, keep the the transmitter, receiver and battery pack away from heat sources such as radiators, heat registers, direct sunlight, stoves, amplifiers, fire, excessive heat or other appliances that produce heat. • Fisher-Price does not recommend the use of two monitors in one house. ® • Always remember that you are using public airwaves when using your monitor. Conversations, even from rooms near your transmitter, may broadcast to other nursery monitors, radios, cordless telephones or scanners outside your home. To protect the privacy of your home, always turn off the transmitter when not in use. • Do not connect to more than the recommended number of power supplies. • The AC adaptor is not a toy. • Disconnect the AC adaptor from the receiver before cleaning. • If this product begins to operate erratically, you may need to reset the electronics. Turn the transmitter power/volume dial off and then back on; press the receiver main power/menu button to turn power off and press again to turn power back on. • The receiver unit may generate a tone when there is radio interference present in the location of operation whilst monitoring. The unit will resume to normal when the interference stops. • Carrier Frequency: 2.4 Ghz • Product features and decoration may vary from photos. 0125 Hereby Mattel declares that the product is in compliance with the essential requirements and other relevant provisions of European Council Directives 99/5/EC, 89/336/EEC. Suitable for the U.K.
- Page 4 Features Receiver Transmitter AC Adaptor/Charger Transmitter Tabletop Stand...
- Page 5 Features Main Power/Menu Button – Press to turn receiver main power ON; press again for the main menu; press and hold for approximately five seconds to turn main power OFF. Power L.E.D. – Turns on when receiver power is ON. Menu Navigation/Volume Control Button – Press up, down or side arrows to scroll through menu options. When the menu is not on the screen, press the side arrows to adjust volume. Speaker Video Screen Video Screen On/Off Button – Press to turn the video screen on; press again to turn it off. Sound Lights – Shows you baby's sounds. DC Input Jack – Insert the AC adaptor/charger pin to use AC power/charge the battery. Camera Lens Power/Volume Dial – Rotate to turn transmitter power ON and adjust volume to a comfortable level for baby. Microphone Music, Sounds and Night Light Buttons Music – Choose from 5 lullaby songs. Sounds – Play nature sounds. Night Light – Turn on night light for baby. Power L.E.D. – Turns on when transmitter power is ON. Night Light – Lights room with a soft glow.
- Page 6 Wall Mount Parts Wall Mount Bracket Cord Wrap Base Stand Fasteners Shown Actual Size Wall Anchor – 4 #8 x 5 cm (2") Screw – 4...
-
Page 7: Charging The Battery
Charging the Battery (Inside the Receiver) DC Input Jack IMPORTANT! Fully charge the receiver (with battery pack inside) for four hours before first-time use. Use only the included AC adaptor charger! Do not use any other adaptor charger. • Fit the AC adaptor charger pin into the DC input jack on the receiver. • Plug the AC adaptor charger into a standard wall outlet. Notes: If power flow to the wall outlet is controlled by a switch, make sure the switch is “ON”. Use the AC adaptor charger only in a wall outlet. Do not plug the AC adaptor charger into a ceiling outlet. • If you are monitoring baby while charging the battery pack, you will see the charging icon on the video screen. - Page 8 Testing Sound/Video Reception Test transmitter transmission and receiver reception before installing the wall mount bracket and cord wrap (if used) and each time you change location of use. Power Dial Radio • Place the transmitter in the room where you intend to use it. • Point the transmitter toward the area you will be monitoring. Adjust the camera angle by rotating the top portion of the transmitter up or down. • Turn the power/volume dial ON. • Turn on a radio.
- Page 9 Testing Sound/Video Reception Sound Lights Main Power/Menu Select Button • Place the receiver in the room where you intend to use it. • Press the main power/menu select button on the front of the receiver to turn power ON. • Adjust the receiver location for best reception. • When sound is picked up by the receiver, the sound lights will turn on. - One or two lights indicate quieter sounds. - Three or more lights indicate louder sounds. • If you cannot see an image on the receiver screen, adjust the transmitter location or camera angle.
- Page 10 Transmitter Wall Mount Installation WARNING To prevent strangulation with power cord, never place transmitter within reach of child. IMPORTANT! Test the reception of the monitor before installing the wall mount bracket and cord wrap. Use the assistance of one adult to hold the transmitter against the wall in the spot you want to install it. Then, test the reception of the receiver in several locations around your house. Please refer to the Testing Sound/Video Reception section of these instructions.
- Page 11 Transmitter Wall Mount Installation 1,8 Meters (6 Feet) • To provide the greatest viewing range, we recommend you install the wall mount bracket at least 1,8 meters (6 feet) from the floor. • Make sure the camera lens does not have an obstructed view of your baby. Adjust the camera up or down. • Allow adequate ventilation of the transmitter when mounted. Do not mount the transmitter above heating vents or other heat producing sources. Do not mount the transmitter where it can receive direct sunlight. • Install the wall mount bracket on a flat section of the wall. The wall mount bracket cannot be corner mounted. • Make sure the AC adaptor will reach a wall outlet before installing the wall mount bracket. To prevent entanglement, never use an extension cord.
- Page 12 Transmitter Wall Mount Installation Wall Mount Bracket • Hold the wall mount bracket against the wall in the location you want to install it. Make sure the wall mount bracket is straight. • Using a pencil, make a mark on the wall inside the upper hole and lower slot on the wall mount bracket. • Set the wall mount bracket aside. • Using a 7mm (.25 inch) drill bit, drill one hole through each pencil mark you made on the wall.
- Page 13 Transmitter Wall Mount Installation Wall Anchor • Fit a wall anchor into each of the drilled holes. • Tap each wall anchor lightly with a hammer until the ends of each wall anchor are even with the surface of the wall. • Align the holes on the wall mount bracket with the wall anchors. • Insert two screws into the holes in the wall mount bracket and tighten with a Phillips screwdriver. Do not over-tighten.
- Page 14 Transmitter Wall Mount Installation Wall Mount Bracket Cord Wrap • Position the cord wrap against the wall, so that it is centred below the wall mount bracket and as close to the floor as possible. • Move the cord wrap approximately 1,3 cm (.5 inch) towards the wall outlet. • Using a pencil, make a mark on the wall inside both holes in the cord wrap. • Set the cord wrap aside.
- Page 15 Transmitter Wall Mount Installation • Using a 7mm (.25 inch) drill bit, drill one hole through each pencil mark you made on the wall. Wall Anchor • Place a wall anchor into each of the drilled holes. • Tap each wall anchor lightly with hammer until the ends of each wall anchor are even with the surface of the wall.
- Page 16 Transmitter Wall Mount Installation Cord Wrap • Align the holes on the cord wrap with the wall anchors. • Insert two screws into the holes in the cord wrap and tighten with a Phillips screwdriver. Do not over-tighten. Transmitter Slot Base Stand Slot Wall Mount Bracket • Put the transmitter into the base stand. • Fit the transmitter cord into the slot in the base stand and the wall mount bracket. • Slide the stand into the slot on the wall mount bracket.
- Page 17 Transmitter Wall Mount Installation 1,8 Meters (6 Feet) Groove Cord Wrap IMPORTANT! Make sure the cord is taught between the transmitter and cord wrap. Excess cord can form loops or extend into the crib and present a strangulation hazard. • Extend the transmitter cord straight down the wall to the cord wrap. • Wrap the transmitter cord around the cord wrap, leaving just enough to reach the wall outlet. Make sure there is no slack in the transmitter cord. • Thread the transmitter cord through the groove in the front of the cord wrap. Make sure the transmitter cord is fully inserted in the groove. • Plug the transmitter cord into the wall outlet.
-
Page 18: Main Menu
Setup/On Screen Displays Main Menu • First, turn both transmitter and receiver power ON. Then press the main power/ menu select button on the receiver to see the main menu. • Press the up, down or side arrows to scroll through menu options. As you scroll, the menu choices highlight and blink on the screen. • Press the main power/menu select to choose: Music Sounds MAIN POWER/ Night Light MENU SELECT Voice Activated Screen Contrast/Brightness Turn Main Menu Off Hint: The main menu turns off if you do not scroll through choices or make a selection within approximately 15 seconds. - Page 19 Setup/On Screen Displays Music Turn music off Turn music on and cycle through all five songs Select song number one Select song number two Select song number three Select song number four Select song number five Return to previous menu Exit menu If you turn the music ON the music icons will appear on the bottom of the screen. Sounds Turn sounds off Select nature sounds Select heartbeat sounds Return to previous menu Exit menu If you turn sounds ON one of the sound icons or will appear on the bottom of the screen.
-
Page 20: Night Light
Setup/On Screen Displays Night Light Turn night light off Turn night light on Return to previous menu Exit menu If you turn the night light on the night light icon will appear on the bottom of the screen. Voice Activated (For Nighttime Use) Video screen turns on for 30 seconds and then turns off. When baby makes noise, video screen automati- cally turns back on. It will remain on and turn off after 30 seconds from the last sound detected. You can also press any button on the receiver to turn video back on. Video screen does not turn on when baby makes noise. Press the video screen on/off button on the top of the receiver to turn the video screen on and off. Return to previous menu Exit menu... - Page 21 Setup/On Screen Displays Contrast/Brightness Press left or right side arrows to adjust contrast on the screen. Return to previous menu Exit menu Press left or right side arrows to adjust brightness on the screen. Return to previous menu Exit menu...
- Page 22 Setup/On Screen Displays Out of Range The out of range warning will flash on the screen and you will hear a tone when the receiver is out of range or the transmitter is turned off. Battery Indicators Indicates receiver is using battery power (only on the menu screen). Indicates battery power is low (and you will hear a tone). Plug in the AC adaptor/charger to use AC power and charge the battery. Indicates receiver is charging.
- Page 23 IMPORTANT! Test the sound and video reception of the monitor before first time use and whenever you change the location of the transmitter (see Testing Sound/Video Reception section of these instructions). • Place the transmitter in the same room with child. Fit the transmitter into the tabletop base. Position the camera lens so it is facing child. For the best viewing range, the transmitter should be approximately 1,5 metres (5 feet) away from baby. • Unwrap and fully extend the power cord for best transmission. Plug the power cord into a standard wall outlet. Use the power cord only in a wall outlet. Do not plug the power cord into a ceiling outlet. Note: The microphone is located on the power cord. Do not place the transmitter microphone within reach of your child or in front of the transmitter. For best results, allow the cord to extend behind the transmitter. • Turn the power/volume dial to turn the power ON. The power L.E.D. will light. • Press the music button to play lullaby songs. (Press again to turn off the music.) • Press the sound button to play nature sounds. (Press again to turn off the sounds.) • Press the night light button for a soft, glowing light. (Press again to turn off the night light).
-
Page 24: Night Vision Mode
• To use AC current, unwrap and fully extend the AC adaptor cord (for best reception). Insert the AC adaptor pin into the DC input jack on the receiver and plug into a standard wall outlet. • Press the main power/menu button on the receiver to turn the power on. • Press the side menu navigation buttons to turn the receiver volume up or down . • To monitor baby without video, press the video on/off button at the top of the receiver. To turn video back on, simply press the button again. • The receiver can be used to stay in touch with baby around your house or yard. The receiver’s range is up to 122 metres (400 feet) away from the transmitter. The out of range warning will flash on the screen and you will hear a tone when the receiver is out of range. • To turn off the receiver, press and hold the main power/menu button for approximately five seconds. Night Vision Mode When the light in baby’s room is too low, the transmitter will automatically switch to night vision mode. The image on the receiver screen will appear in black and white, not colour. -
Page 25: Battery Replacement
Battery Replacement If you need to replace your NiMH rechargeable battery pack, please contact Mattel Consumer Relations. • Locate the battery compartment door on the back of the receiver. • Loosen the screws in the battery compartment door with a Phillips screwdriver. Remove the battery compartment door. • Remove the exhausted battery pack and dispose of it properly. • Plug the new rechargeable battery pack into the receiver’s battery connector. Then, insert the battery pack in the battery compartment. • Replace the battery compartment door and tighten the screws with a Phillips screwdriver. Do not over-tighten. • Protect the environment by not disposing of this product with household waste (2002/96/EC). Check your local authority for recycling advice and facilities (Europe only). Battery Safety Information In exceptional circumstances, batteries may leak fluids that can cause a chemical burn injury or ruin your product. To avoid battery leakage: • If replacing the battery pack, insert it as indicated inside the battery compartment. • Always remove an exhausted battery pack from the product. Dispose of the battery pack safely. Do not dispose of product in a fire. The battery pack inside may explode or leak. Contact Mattel Consumer Relations to purchase a battery pack. • Never short-circuit the battery pack terminals. • Use only batteries of the same type, as recommended. -
Page 26: Problems And Solutions
Problems & Solutions Problem Solution No image on receiver screen Press the video screen on/off button. You can also change the voice activated setting to . The video screen automatically turns on when baby makes noise. Batteries in receiver are weak or dead. Use AC adaptor as power source and to charge the battery. Transmitter camera lens is obstructed. Adjust the camera angle on the transmitter. Receiver beeps and out of range Receiver is out of range of transmitter. Move receiver closer screen displays to transmitter. Note: Range varies depending on surrounding conditions such as noise levels, physical obstructions and signal interference. Under optimal conditions, the range is up to 122 metres. Transmitter power is off. Turn transmitter power on. Loose power cord connection and transmitter power is off. Check transmitter power cord plug-to-outlet connection. No power to wall outlet and transmitter power is off. Make sure light switch that controls power flow to wall outlet is on. Power is off because circuit breaker for room is off. Make sure house fuses and circuit breakers are on. Receiver power L.E.D. Receiver power is off. Turn receiver power on. does not light Battery pack in receiver is weak or dead. Use AC adaptor as power source and to charge the battery for four hours. Power is off because circuit breaker for room is off. Make sure house fuses and circuit breakers are on. No power to wall outlet and power is off. Make sure light switch that controls power flow to wall outlet is on. - Page 27 Problems & Solutions Problem Solution Receiver beeps and displays Battery pack in receiver is weak or dead. Use AC adaptor as low battery icon on screen power source and to charge the battery for four hours. Transmitter power L.E.D. Transmitter power is off. Turn transmitter power on. does not light Loose power cord connection and transmitter power is off. Check transmitter power cord plug-to-outlet connection. No power to wall outlet and transmitter power is off. Make sure light switch that controls power flow to wall outlet is on. Power is off because circuit breaker for baby’s room is off. Make sure house fuses and circuit breakers are on. You can hear conversations or There is signal interference due to other nursery monitors on sounds from other homes same channel or cordless telephone use. You may need to pair the receiver and transmitter. Remove the receiver battery door and press the pairing button with a paperclip. The power LED will blink when the pairing button is released. Then, turn over the transmitter and press the pairing button with a paperclip. The signal L.E.D. on the receiver will flash and you will hear a confirmation tone. Hint: If, after checking all of these solutions, you believe that your transmitter power cord or AC adaptor are damaged, please contact Mattel.
- Page 28 Care Excess dirt in transmitter microphone will hamper transmission of sound. Wipe all parts with a damp cloth. Do not immerse any part of this monitor. Questions? www.service.mattel.com/uk 0168 5000 Great Britain: Mattel UK Ltd, Vanwall Business Park, Maidenhead SL6 4UB. Asia: Mattel East Asia Ltd, Room 1106, South Tower, World Finance Centre, Harbour City, Tsimshatsui, HK, China. Malaysia: Diimport & Diedarkan Oleh: Mattel SEA Ptd Ltd. (993532-P) Lot 13.5, 13th Floor, Menara Lien Hoe, Persiaran Tropicana Golf Country Resort, 47410 PJ. Tel: 03-78803817, Fax: 03-78803867. Fisher-Price, Inc., a subsidiary of Mattel, Inc. East Aurora, New York 14052, U.S.A. P6615pr-076 ©2009 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc. PRINTED IN CHINA...
