  • Page 1 21-406 Cat. No. USER GUIDE TRC-506 before usinTRC 1- Channel Radio Transceiver...

  • Page 2: Care And Maintenance

    FCC authorization to operate it. If your transceivers are not performing as they should, take them to your local Radio Shack store. Our personnel can assist you and arrange for service if needed.
  • Page 3 Features The Realistic TRC-506s are compact, portable FM 2-way radios with handsfree operation. You can communicate with another TRC-506 or any FM transceiver operating on the same frequency. Use your TRC-506s to add to your fun while at sporting events, on camping trips, biking, or hiking with your friends.

  • Page 4: Operation

    If you selected manual operation, press PUSH TO TALK to transmit. Release PUSH TO TALK to receive. The TRC-506 cannot receive while transmitting. Wait for the other person to stop talking before you transmit. FCC NOTICE Your transceiver might cause TV or radio interference even when it is operating properly.

  • Page 5: Parts List

    PARTS LIST To order parts call 1-800-843-7422 or visit your local RadioShack store. Reference # Cat.No. Description NP Part # ------------------------------------------------------------------------ 11319605 1S2473 10517613 REPLACED BY MPS9626 1TR0114 10517845 REPLACED BY MPS9634C 1TR0217 10517886 REPLACED BY MPS9681 1TR0223 10518181 REPLACED BY MPS9426B 1TR0302 10540474 ANTENNA...
  • Page 8 Specifications GENERAL: Operation Frequency..........49.830 MHz Number of Channels............1 Input Voltage............9 V DC Current Drain (Standby)..........13 mA (Receive)..........40 mA max (Transmit).........40 mA max Dimensions..4 5/8 x 2 5/8 x 1 1/8 Inches (118 x 67 x 28.5 mm) (HWD) Weight............7.3 oz (207.3 g) RECEIVER: Sensitivity (20 dB S/N).........0.5 microV Squelch Sensitivity (Threshold).........0.5 microV...
