- Page 1 MHD8015 User’s Guide 1.5 GB HardDisk Storage MP3/WMA Player Before operating this product, please read these instructions completely.
-
Page 2: Safety Precautions
SAFETY PRECAUTIONS CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE SERVICING TO QUALIFIED SERVICE PERSONNEL. DANGEROUS VOLTAGE: The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. -
Page 3: Road Safety
COPYRIGHT: • Distributing copies of MP3 or WMA with DRM tracks without permission is a violation of international copyright laws. SAFETY: • Vibration experienced during walking or exercising will not affect the player. However, dropping the player or dropping a heavy object on the player may result in damage or sound distortion. -
Page 4: Fcc Declaration
FCC DECLARATION This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) This device may not cause interference, and 2) This device must accept any interference received, including interference that may cause undesired operation. - Page 5 Dear Customer: Selecting fine audio equipment such as the unit you’ve just purchased is only the start of your musical enjoyment. Now it’s time to consider how you can maximize the fun and excitement your equipment offers. This manufacturer and the Electronic Industries Association’s Consumer Electronics Group want you to get the most out of your equipment by playing it at a safe level.
- Page 6 Decibel Level Example Quiet library, soft whispers Living room, refrigerator, bedroom away from traffic Light traffic, normal conversation, quiet office Air conditioner at 20 feet, sewing machine Vacuum cleaner, hair dryer, noisy restaurant Average city traffic, garbage disposals, alarm clock at two feet THE FOLLOWING NOISES CAN BE DANGEROUS UNDER CONSTANT EXPOSURE: Subway, motorcycle, truck traffic, lawn mower Garbage truck, chain saw, pneumatic drill...
-
Page 7: Location Of Controls
LOCATION OF CONTROLS 1. Headphone Jack 2. FWD Button 3. REV Button 4. DC IN 5V Jack z 5. Play/Pause ®p Button 6. Skip/Search m Button 7. Stop X Button 8. Volume (+/-)/Scroll (Up/Down) Control 9. Display 10. USB Cover and Port 11. -
Page 8: Power Sources
AC OPERATION To operate the unit using AC power, connect the AC adapter (included) to an AC outlet having 120V, 60Hz AC only. Plug the small end into the DC 5V jack on the side of the unit and connect the other end into the AC outlet. It is recommended to use the AC adapter when possible to save battery life, particularly when transferring files. -
Page 9: Downloading And Transferring Files
DOWNLOADING AND TRANSFERRING FILES TO INSTALL THE "DIGITAL AUDIO PLAYER" CD SOFTWARE For Windows ME, Windows2000 or Windows XP: Windows will automatically detect the audio player without installing the CD software when the USB cable is connected. For Macintosh OSX: Macintosh OSX will automatically detect the audio player without installing the CD software. - Page 10 WINDOWS 98 DRIVER INSTALLATION (CONTINUED) Then click “Windows 98 Driver” in the Installation CD Explorer. Then the “Windows 98 Driver Installation Guide” Explorer will appear on the computer screen. Follow the Installation Guide’s procedure to install the Driver to your computer.
-
Page 11: Formatting The Player
FORMATTING THE PLAYER Formatting the Player 1. Use the USB cable to connect the player and the computer. 2. The unit will restart or turn on automatically, “Welcome” will appear briefly and then the USB icon will appear in the display. (The player is now connected to the computer.) 3. - Page 12 After disconnecting the player from the computer, the player will restart again, “Welcome” followed by “Memorex” will appear briefly and then the player will check and update the index automatically if there are new tracks/files which were added to the player. It will take from several seconds to several minutes to check/update the index (depending on the total files/tracks added).
- Page 13 After disconnecting the player from the computer, the player will restart again, “Welcome” followed by “Memorex” will appear briefly and then the player will check and update the index automatically if there are new tracks/files which were added to the player. It will take from several seconds to several minutes to check/update the index (depending on the total files/tracks added).
- Page 14 DOWNLOADING AND TRANSFERRING FILES (CONTINUED) REALONE PLAYER INSTALLATION (PC ONLY): 1. Insert the Installation CD-ROM into the CD Drive and double click Software Setup.html, the screen to the right will appear. 2. Click desired downloading RealOne Player. 3. Click OPEN; the installation will automatically start.
- Page 15 12. After disconnecting the player from the computer, the player will restart again, “Welcome” followed by “Memorex” will appear briefly and then the player will check and update the index automatically if there are new tracks/files which were added to the player. It will take from several seconds to several minutes to check/update the index (depending on the total files/tracks added).
- Page 16 DOWNLOADING AND TRANSFERRING FILES (CONTINUED) The unit will restart automatically, “Welcome” will appear briefly and then the USB icon will appear in the display. (The player is now connected to the computer.) 1. Open the 'Windows Media Player Browser' and click on 'Copy to CD or Device’.
- Page 17 DOWNLOADING AND TRANSFERRING FILES (CONTINUED) See page 12.
-
Page 18: Turning The Power On/Off
TURNING THE POWER ON/OFF To turn the unit on, press the (Power On/Off)/M (Main Menu) button; “Welcome” followed by “Memorex” will appear briefly and then the Main Menu will appear on the screen. To turn the unit off, press and hold the (Power On/Off)/M (Main Menu) button until “Continue... -
Page 19: Setting Menu
SCREEN DISPLAYS AND DESCRIPTIONS MAIN MENU Transport Indicator Title Bar Main menu Screen NOW PLAYING MENU Transport Indicator Song Title Artist Elapsed Time Mode Indicators Volume Level: The volume level can only be set in the Now Playing Menu. SETTING MENU Transport Indicator Repeat Indicator Random Indicator... -
Page 20: To Listen To Mp3S/Wmas
TO LISTEN TO MP3s/WMAs To turn the unit on, press the (Power On/Off)/M (Main Menu) button; “Welcome” followed by “Memorex” will appear briefly and then the Main Menu will appear on the screen. TO PLAY A SELECTED FOLDER: The selected screen will appear. Select a folder using the Volume (+/-)/Scroll (Up/Down) control 1, then press the Play/Pause ®p button 2 to start... -
Page 21: To Pause Playback
OPERATION (CONTINUED) To return to the previous menu, press the REV button 1. To advance to the next menu, press the FWD button 2. To return to the MAIN menu, press the (Power On/Off)/M (Main Menu) button 3. TO PAUSE PLAYBACK During playback, if you wish to pause the file momentarily, press the Play/Pause ®p button;... -
Page 22: Forward/Reverse Skip
OPERATION (CONTINUED) FORWARD/REVERSE SKIP During playback, press the Skip/Search n button to advance the player to the beginning of the next file in the folder. Press the Skip/Search n button repeatedly to advance the player to higher-numbered files in the folder. HIGH-SPEED MUSIC SEARCH During playback, press the Skip/Search o button to move the player back to the... -
Page 23: Random Playback
RANDOM PLAYBACK To turn the unit on, press the (Power On/Off)/M (Main Menu) button; “Welcome” followed by “Memorex” will appear briefly and then the Main Menu will appear on the screen. Select RANDOM MODE using the Volume/ Navigation control, then press the Volume/ Navigation control to select it;... - Page 24 OPERATION (CONTINUED) Select TRACKS using (+/-)/Scroll (Up/Down) control 1, then pressing the Volume (+/-)/Scroll (Up/Down) control 1 followed by the Play/Pause ®p button 2 to start Random playback of all the tracks installed. The unit will randomly playback all the tracks inside the folder or album and then stop.
-
Page 25: Repeat Playback
REPEAT PLAYBACK To turn the unit on, press the (Power On/Off)/M (Main Menu) button; “Welcome” followed by “Memorex” will appear briefly and then the Main Menu will appear on the screen. Select REPEAT MODE using the Volume (+/-)/Scroll (Up/Down) control, then press the Volume (+/-)/Scroll (Up/Down) control to select it;... - Page 26 OPERATION (CONTINUED) Select the TRACKS folder using the Volume (+/-)/Scroll (Up/Down) control 1, then press the Volume (+/-)/Scroll (Up/Down) control 1 to select it followed by the Play/Pause ®p button 2 to start Repeat playback of all tracks. Repeat playback will continue until the Stop X button has been pressed.
-
Page 27: Intro Playback
INTRO PLAYBACK To turn the unit on, press the (Power On/Off)/M (Main Menu) button; “Welcome” followed by “Memorex” will appear briefly and then the Main Menu will appear on the screen. Select INTRO MODE using the Volume/ Navigation control, then press the Volume/ Navigation control to select it;... - Page 28 OPERATION (CONTINUED) Select the TRACKS folder, using the Volume (+/-)/Scroll (Up/Down) control 1, then press Volume (Up/Down) control 1 followed by the Play/Pause ®p button 2 to start Into playback of all tracks. Intro playback will continue until all tracks have been played or the Stop X button has been pressed.
-
Page 29: Creating A Playlist
CREATING A PLAYLIST To turn the unit on, press the (Power On/Off)/M (Main Menu) button; “Welcome” followed by “Memorex” will appear briefly and then the Main Menu will appear on the screen. Select CREATE A NEW PLAYLIST using the Volume (+/-)/Scroll (Up/Down) control, then press the Volume (+/-)/Scroll (Up/Down) control to select it;... -
Page 30: Playing A Playlist
PLAYING A PLAYLIST To turn the unit on, press the (Power On/Off)/M (Main Menu) button; “Welcome” followed by “Memorex” will appear briefly and then the Menu will appear on the screen. Select a desired playlist using the Volume (+/-)/Scroll (Up/Down) control 1, then press the Play/Pause ®p button 2 to start playback. - Page 31 MODIFYING A PLAYLIST (Adding or Deleting a Track) To turn the unit on, press the (Power On/Off)/M (Main Menu) button; “Welcome” followed by “Memorex” will appear briefly and then the Main Menu will appear on the screen. Select MODIFY EXISTING PLAYLIST using the Volume (+/-)/Scroll (Up/Down) control, then press the Volume (+/-)/Scroll (Up/Down) control to select it.
- Page 32 OPERATION (CONTINUED) TO ADD: Select ADD TRACKS using the Volume (+/-)/Scroll (Up/Down) control, then press the Volume (+/-)/Scroll (Up/Down) control to select it. Select the desired playlist using the Volume (+/-)/Scroll (Up/Down) control, then press the Volume (+/-)/Scroll (Up/Down) control to select it. TO DELETE: Select DELETE TRACKS using the Volume (+/-)/Scroll (Up/Down) control, then press the Volume (+/-)/Scroll...
-
Page 33: Deleting A Playlist
DELETING A PLAYLIST To turn the unit on, press the (Power On/Off)/M (Main Menu) button; “Welcome” followed by “Memorex” will appear briefly and then the Main Menu will appear on the screen. Select DELETE EXISTING PLAYLIST using the Volume (+/-)/Scroll (Up/Down) control,... -
Page 34: Adjusting The Backlight Setting
OPERATION (CONTINUED) ADJUSTING THE BACKLIGHT SETTING While in the Main Menu, select SETTINGS using the Volume (+/-)/Scroll (Up/Down) control, then press the Volume (+/-)/Scroll (Up/Down) control to select it; the Settings menu will appear. ADJUSTING THE CONTRAST While in the Main Menu, select SETTINGS using the Volume (+/-)/Scroll (Up/Down) control, then press the Volume (+/-)/Scroll (Up/Down) control to select it;... - Page 35 OPERATION (CONTINUED) ADJUSTING THE EQUALIZER SETTING While in the Main Menu, select SETTINGS using the Volume (+/-)/Scroll (Up/Down) control, then press the Volume (+/-)/Scroll (Up/Down) control to select it; the Settings menu will appear. PRESET EQ: Select the desired preset EQ (Normal, Bass Boost, Rock, Jazz, Classical or Pop) using the Volume (+/-)/Scroll (Up/Down) control, then press the Volume...
- Page 36 OPERATION (CONTINUED) SETTING THE POWER SAVING OPTION This option is useful to set lower to save battery life. While in the Main Menu, select SETTINGS using the Volume (+/-)/Scroll (Up/Down) control, then press the Volume (+/-)/Scroll (Up/Down) control to select it; the Settings menu will appear.
- Page 37 OPERATION (CONTINUED) ABOUT RESET NOTE: To return to the Main Menu, press the (Power On/Off)/M (Main Menu) button. The “About” menu displays information describing the revision of the firmware loaded in the unit and the maximum capacity of the hard drive. While in the Main Menu, select SETTINGS using the Volume (+/-)/Scroll (Up/Down) control, then press the Volume (+/- )/Scroll (Up/Down) control to select it;...
-
Page 38: Troubleshooting Guide
TROUBLESHOOTING GUIDE If you experience a problem with this unit, check the chart below before calling for service. PROBLEM PLAYER will not turn on. PLAYER will not respond buttons pressed. There is no sound from headphones. Files appearing in the playlist when I try to download to the unit. -
Page 39: Specifications
PC System Requirements • Pentium Class 300MHz processor or better • Windows® 98/Me/2000/XP • 96 MB RAM (32 MB for Win98) • 50 MB hard drive space • Video display card • Soundcard • Microsoft Internet Explorer 5.0 or later •... - Page 40 OR CONTACT CUSTOMER SERVICE AT (954) 660-7100. PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90 DAYS IN CASE YOU NEED TO RETURN THIS PRODUCT TO YOUR PLACE OF PURCHASE OR TO MEMOREX. FOR PARTS AND ACCESSORIES, CONTACT FOX INTERNATIONAL AT 1-800-321-6993.
- Page 41 Memcorp, Inc. Weston, FL Printed in China Visit our website at www.memorexelectronics.com...
