- Page 1 MVD2032 User’s Guide DVD/VCD/MP3/PHOTO CD Player Before operating this product, please read these instructions completely.
-
Page 2: Table Of Contents
Contents...1 Important Safety Instructions ...2 Precautions...5 Power Source ...5 Location of Controls ...6 • Front...6 • Rear ...6 • Remote ...7 Remote Control ...8 • Battery Installation ...8 • Effective Distance of the Remote Control Transmitter ...8 Connection...9 • Connecting the DVD to a TV Using the Audio/Video Output Jacks ...9 •... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. CAUTION: THIS DIGITAL VIDEO DISC PLAYER EMPLOYS A LASER SYSTEM. - Page 4 PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90 DAYS IN CASE YOU NEED TO RETURN THIS PRODUCT TO YOUR PLACE OF PURCHASE OR MEMOREX. Before using the unit, be sure to read all operating instructions carefully. Please note that these are general precautions and may not pertain to your unit.
- Page 5 IMPORTANT SAFETY INSTRUCTIONS (CONTINUED) should be taken to keep from touching such power lines or circuits as contact with them might be fatal. 15. OVERLOADING Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock. 16.
-
Page 6: Precautions
When the DVD player is not in use, be sure to remove the disc and turn off the power. • If you do not use the DVD player for a long period, the unit may not function properly in the future. Turn on and use the DVD player occasionally. -
Page 7: Location Of Controls
FRONT 1. STANDBY Button 2. STANDBY Indicator 3. Disc Tray 4. OPEN/CLOSE Button 5. STOP ( ) Button 6. SKIP ( ) and ( ) Buttons REAR 1. Stereo Audio Left/Right Output Jacks 2. Video Output Jack 3. S-Video Output Jack 4. -
Page 8: Remote
LOCATION OF CONTROLS (CONTINUED) REMOTE 1. DISPLAY Button 2. Number (0–9) Buttons 3. TITLE MENU Button 4. 3D Button 5. ANGLE Button 6. SETUP Button 7. Navigation ( ) Button 8. Navigation ( ) Button 9. PLAY ( ) Button 10. -
Page 9: Remote Control
BATTERY INSTALLATION Follow these precautions when using batteries in this device: 1. Use only the size and type of batteries specified. 2. Be sure to follow the correct polarity when installing the batteries as indicated next to the battery compartment. Reversed batteries may cause damage to the device. -
Page 10: Connection
If your TV only has one audio input, the use of a “Y” connector may be necessary. Visit your local electronics supply store. • Connect the DVD player to your TV directly. If you connect the DVD player through a VCR, the playback picture will be distorted because DVD video discs are copy protected. -
Page 11: Connecting The Dvd To A Tv Using The Y/Pb/Pr Jacks
When connecting the DVD to the TV, make sure the power is off and both units are unplugged before making any connections. • Connect the DVD player to your TV directly. If you connect the DVD player through a VCR, the playback picture will be distorted because DVD video discs are copy protected. •... -
Page 12: Connecting The Dvd To A Home Theatre System
When connecting, make sure the power is off and all units are unplugged before making any connections. • Connect the DVD player to your TV directly. If you connect the DVD player through a VCR, the playback picture will be distorted because DVD video discs are copy protected. -
Page 13: About Discs
It is important that you read the manual that accompanies the DVD disc, as there are features that are on the DVD player that cannot be used with certain DVDs. There are also extra features on the DVD disc that are different for each DVD disc, so they are not explained in this owner’s manual. - Page 14 DVD disc. If the Region number described on the DVD disc does not correspond to the Region number of this DVD player, this DVD player cannot play that disc. You may not be able to play back some DVD video discs on this player if they were purchased from outside your geographic area or made for business purposes.
-
Page 15: Setup Menu
The setup menu lets you customize the DVD player by allowing you to select various language preferences, set up a parental level, turn captions and screen saver on and off, adjust what type of television screen you have and more. -
Page 16: General Setup Menu
PAL: Select when using a PAL TV. IMPORTANT: In the USA, the standard is NTSC. When the DVD player is turned on, it will be set to NTSC. ANGLE MARK The Angle mark setting will only work if this feature is included on the DVD. -
Page 17: Speaker Setup Menu
CAPTIONS Dolby - - General Setup Page - - TV Display TV Type NTSC Video Out Angle Mark OSD Lang Captions Screen Saver Closed Caption When this option is set to ON, captions will appear on the screen for the hearing impaired. When this option is set to OFF, captions will NOT appear on the screen. -
Page 18: Dolby Digital Setup Menu
DOLBY DIGITAL SETUP MENU: Select DOLBY DIGITAL SETUP ( on page 14. DYNAMIC MODE Dolby - - Dolby Setup Page - - Dynamic Dynamic Range Compression Use to slider to set the Dynamic Range. Set to OFF to turn Dynamic Range Off. PREFERENCE SETUP MENU (this menu cannot be accessed if a disc is inserted): Select PREFERENCES SETUP ( Dolby... -
Page 19: Disc Menu
DISC MENU Dolby - - Preference Page - - Audio Subtitle Disc Menu English French Parental Password Spanish German Default Japanese Preferred Menu Language Select the language the DISC MENU will be in (ENGLISH, FRENCH, SPANISH, GERMAN, JAPANESE). The DVD’s DISC MENU must be made in the selected language, otherwise the default language of the DVD will be shown. - Page 20 PASSWORD Select this option to change the password. You must know the old password in order to change it. If you have forgotten the password, call customer service at the number listed in the Warranty. - - Preference Page - - Audio Subtitle Disc Menu...
-
Page 21: Basic Operation
When “ ” appears while pressing a button, this means that the corresponding function cannot be performed either on the disc inserted, or in the selected 3D SOUND 3D audio post-processing will give a multichannel effect when using only 2 speakers. This only works with discs encoded with Dolby Pro Logic, Dolby Digital and DTS multi- channel audio tracks. -
Page 22: Dvd Basic Operation
IMPORTANT NOTES: • After plugging in, the unit will be in the Standby mode (the Standby indicator will be lit). Press the STANDBY button on the main unit or the remote to turn on the unit. As long as you do not press the STANDBY button to turn the unit off, it will return to Standby mode and the STANDBY indicator will light. -
Page 23: Skip
DVD BASIC OPERATION (CONTINUED) SKIP Press the Skip ( ) button to advance the DVD to the beginning of the next chapter. Press the Skip ( ) button beginning of the previous chapters. SLOW/R AND SLOW/F Use this feature to move the DVD in slow motion. During playback, press either the SLOW/R or SLOW/F button to move the DVD forward or backward in slow motion speeds of 1/2, 1/4, 1/8, 1/16 and resume normal playback. -
Page 24: Title/Chapter Search
DVD BASIC OPERATION (CONTINUED) TITLE/CHAPTER SEARCH Use this feature to directly go to a specific title and/or chapter. Press the SEARCH button once. Press the Navigation ( , ) buttons to select the TITLE, then use the Number buttons to select the desired title number (i.e. for number 5, press “0”, “5”). -
Page 25: Audio Menu
DVD BASIC OPERATION (CONTINUED) AUDIO MENU Press the AUDIO MENU button repeatedly to change the audio language. This feature is not available on all discs. DVD MENU Press the DVD MENU button , and the Main Menu of the disc will appear. Use the Navigation ( , , , ) buttons to select the desired option, and then press the ENTER button This is not available on all discs. -
Page 26: Mp3 Basic Operation
PLAYBACK OF AN MP3 CD Press the STANDBY button on the main unit/remote to turn on the unit; the STANDBY indicator will go out. Press the OPEN/CLOSE button “CLOSE” will appear on the screen and the display. After loading, the FOLDER/TRACK menu will appear on the TV screen. -
Page 27: Selecting Folders/Tracks Using The Skip
MP3 BASIC OPERATION (CONTINUED) SELECTING FOLDERS/TRACKS USING THE SKIP ( ) OR ( ) BUTTON During playback, simply press the ( select a track to be played. FORWARD /REVERSE Each press of the SEARCH increase the search as follows: 1st press: 2nd press: 3rd press: 4th press:... -
Page 28: Cd/Vcd Basic Operation
PLAYBACK OF A CD/VCD Press the STANDBY button on the main unit/remote to turn on the unit; the STANDBY indicator will go out. Press the OPEN/CLOSE button to close the disc tray. “CLOSE” will appear on the screen and in the display. After loading, playback will start automatically. -
Page 29: Forward/Reverse
CD/VCD BASIC OPERATION (CONTINUED) FORWARD /REVERSE Each press of the SEARCH increase the search as follows: 1st press: 2nd press: 3rd press: 4th press: x 16 5th press: Resume Normal Playback Press the PLAY ( ) button to resume normal playback. IMPORTANT NOTE ON VCD REPEAT PLAYBACK: PBC must be Off to use repeat playback with VCDs. -
Page 30: Programmed Playback
CD/VCD BASIC OPERATION (CONTINUED) PROGRAMMED PLAYBACK The CD player in this unit has a 20 track programmable memory that allows you to program up to 20 tracks on any disc for playback in any desired order. You may program 20 different tracks or you may also program certain tracks to play more than once. -
Page 31: Picture Cd Basic Operation
Press the STANDBY button on the main unit/remote to turn on the unit; the STANDBY indicator will go out. Press the OPEN/CLOSE button “CLOSE” will appear on the TV screen. After loading, the picture will automatically show on the TV screen. Press the or ( button to select a picture. -
Page 32: Troubleshooting Guide
Check the following before requesting service: SYMPTOM GENERAL No power. Power on, but unit not functioning properly. No picture. No sound. Playback picture rolls. The playback picture is poor. The Search feature is not working. The picture is not fitting properly. The remote control is not working. - Page 33 WWW.MEMOREXELECTRONICS.COM OR CONTACT CUSTOMER SERVICE AT PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90 DAYS IN CASE YOU NEED TO RETURN THIS PRODUCT TO YOUR PLACE OF PURCHASE OR MEMOREX. FOR PARTS AND ACCESSORIES, CONTACT FOX INTERNATIONAL AT 1-800-321-6993.
-
Page 34: Care And Maintenance
Caring for Discs • Treat the disc carefully. Handle the disc only by its edges. Never allow your fingers to come in contact with the shiny, unprinted side of the disc. • Do not attach adhesive tape, stickers, etc. to the disc label. •... -
Page 35: Specifications
Power Requirements...AC120V, 60Hz Power Consumption...15W (approx. 8W when set to Standby mode by remote) Weight...5.5 Lbs Dimensions ...16.75(L) x 9.25 (W) x 1.75 (H) inches Weight and dimensions are approximate. Signal System ...NTSC/PAL Operating Temperature ...+5° to +35°C Operating Humidity Range...5% to 90% (no condensation) Discs Played: DVD-VIDEO Disc 12cm single-sided, single layer... - Page 36 Memcorp, Inc. Weston, FL Printed in Hong Kong Visit our website at www.memorexelectronics.com...
