User Manual
RCU1010RF_US_QS_revA
9/12/03
Congratulations on your purchase of the RCU1010RF Universal Learning Remote with Touchscreen and
Built-in Transmitter with additional Remote Sender Cone. Your RCU1010RF controls up to nine components,
including the most popular brands of TV, VCR, DVD, SAT, PVR/DVR, CBL/AUX, CD and AUDIO equipment.
This unit has the ability to learn commands from your existing remotes, and the SmartMacro
multiple commands to be executed in sequence with a single keypress. The RCU1010RF is easy to use, easy to
program and gives you total control—at the touch of your fingertips!
Getting Started
Before You Begin
This handy Quick Start Guide provides step-by-step instructions regarding some of the most popular features
of this remote control. Use it as a supplement to the User's Guide, to which you may refer for further details.
The RCU1010RF LCD touchscreen remains blank when the remote is not in use. The touchscreen turns
on automatically when you press and release the SETUP key, the BACKLIGHT key, or any LCD touchscreen
key. The remaining rubber keys do not activate the LCD touchscreen.
SETUP key
For the purposes of this guide, "component" refers to your electronic equipment—TV, VCR, DVD, PVR/DVR,
satellite receiver, auxiliary or audio components—all of which can be operated using the RCU1010RF remote
control unit. When you press and release a component key, you put the remote in that component mode (e.g.,
pressing the TV key puts the remote in the TV Mode). The remote remains in that mode until you press and
release another mode key. When you put the remote in a specific component mode, the control screen that is
shown on the touchscreen is the control screen for that mode.
What's So Great About RF Technology?
Your RCU1010RF transmits signals in infrared (IR) and radio frequency (RF). Most remote controls transmit
only in IR and must be pointed in a direct line of sight with the IR sensor on your electronic component in
order to function properly. Because the RCU1010RF has radio frequency capabilities, the remote control does
not have to be pointed at the receiver; in fact, it doesn't even have to be in the same room! The RF signals
go through your whole house and enable you to control all of your components wherever you are!
What advantages does that bring to you and your home electronic equipment? Plenty!
First, you can place your component (such as a VCR, DVD, etc) in a closed cabinet, and the RCU1010RF
will transmit the proper signals to it. That gives you great flexibility in setting up your home
entertainment system.
Secondly, if your satellite receiver is upstairs, the RCU1010RF allows you to change the channel while
downstairs. (Additional wiring needed).
Thirdly, the RCU1010RF transmits through walls, floors, ceilings—even to your deck outdoors so you can
control your component(s) wherever you are. For example, if you are outside on your deck enjoying music on
your wireless speakers, you can use the RCU1010RF to adjust the volume without going back into the house!
The RCU1010RF is packed with features you want—and its RF capabilities make it the perfect remote to give
you added control and flexibility.
16:01
Page 1
Universal Learning Remote with
TOUCHSCREEN
and Built-In RF Transmitter
Remote Sender Cone included
Quick Start Guide
Touchscreen keys
BACKLIGHT key
feature allows
SM
RCU1010RF
Advertisement
Table of Contents
Related Manuals for RCA RCU1010RF
Summary of Contents for RCA RCU1010RF
-
Page 1: Quick Start Guide
This unit has the ability to learn commands from your existing remotes, and the SmartMacro feature allows multiple commands to be executed in sequence with a single keypress. The RCU1010RF is easy to use, easy to program and gives you total control—at the touch of your fingertips! -
Page 2: Install The Batteries
Perform Setup Routine and Procedures The SETUP key is located towards the lower right-hand side of the RCU1010RF remote. The SETUP key is used to walk you through the steps in setting up the remote. To enter the Setup Mode, press and hold the SETUP key on the rubber keypad for 2-3 seconds until the LED indicator light remains on. -
Page 3: Programming The Remote
(TV, VCR, PVR/DVR, DVD, etc.), you must program it with the corresponding code entry from the Code Lists. If your TV, VCR, DVD, or satellite receiver is an RCA, PROSCAN or GE brand, the RCU1010RF may not need any programming to control it. - Page 4 See User’s Guide for more information. Program the Remote Using Code Autosearch Your RCU1010RF has the ability to automatically scroll through the entire Code Lists by using the Autosearch feature. Remember: Code Autosearch may take some time to cycle through all available codes.
- Page 5 Codes from the Code Lists include basic functionality for each component they control. Once you have programmed in the list code for your specific component, you can customize the RCU1010RF touchscreen to include certain functions from your original remote(s) that were not embedded in the preset code. This allows you to transfer the best features from existing remotes to the RCU1010RF remote .
-
Page 6: Clear All Stored Learned Commands Under A Mode
RCU1010RF_US_QS_revA 9/12/03 16:01 Page 6 Learn a Command (continued) 11. The Learning process is now complete. To exit the Setup Mode, press and release the EXIT key, followed by the LCD OK key on the Exit Setup Screen. Note: If the EXIT key does not respond, press and release the SETUP key repeatedly until the Exit Setup Screen appears. -
Page 7: Program A Smartmacro
Page 7 SmartMacros SmartMacros allow you to program your RCU1010RF remote to perform a series of sequential commands with one keypress. For example, you can program a SmartMacro to turn on your TV, tune it to a specific channel, turn on your VCR, and record. A total of 20 Learned commands can be programmed under each of the nine available LCD Macro keys. -
Page 8: Restoring Original Settings
Restoring Original Settings Master Reset A Master Reset returns all the RCU1010RF remote defaults to the original factory settings. The Master Reset clears all customer-programmed codes, Learned commands and SmartMacros, and resets all key labels. To perform a Master Reset, follow these steps: 1.
