Please do not return product to retailer.
Por favor, no devuelva el producto al lugar de compra.
Veuillez ne pas retourner le produit au détaillant.
1- -800- -554- -6723
Register your product online at:
Registre su producto en línea en:
Enregistrez votre produit en ligne à l'adresse :
www.mccullochpower.com
Manual de Instrucciones
For Occasional Use Only
WARNING:
Read and follow all Safety Rules and Operating Instructions before
using this product. Failure to do so can result in serious injury.
ADVERTENCIA:
Lea el manual de instrucciones y siga todas las advertencias
e instrucciones de seguridad. El no hacerlo puede resultar en
lesiones graves.
AVERTISSEMENT:
Lire le manuel d'instructions et bien respecter tous les avertisse-
ments et toutes les instructions de sécurité. Tout défaut de le faire
pourrait entraîner des blessures graves.
McCulloch
9335 Harris Corners
Charlotte, NC 28269
Instruction Manual
Manuel d'Instructions
850 Matheson Blvd. West
Mississauga, Ontario L5V 0B4
115376727 Rev. 1
McCulloch
5/1/10 BRW
Advertisement
Table of Contents
Related Manuals for McCulloch 115376727
Summary of Contents for McCulloch 115376727
- Page 1 Lire le manuel d’instructions et bien respecter tous les avertisse- ments et toutes les instructions de sécurité. Tout défaut de le faire pourrait entraîner des blessures graves. McCulloch 9335 Harris Corners Charlotte, NC 28269 115376727 Rev. 1 McCulloch 850 Matheson Blvd. West Mississauga, Ontario L5V 0B4 5/1/10 BRW...
-
Page 2: Identification Of Safety Symbols
0.080 inch (2 mm) recommended trimmer line. Never use blades, flailing devices, wire, rope, string, etc. This attachment is designed for line trimmer use only. Failure to follow these instructions may result in serious injury. WARNING: This unit can be dangerous! Careless or improper use can cause serious injury. - Page 3 IDENTIFICATION OF SAFETY SYMBOLS Never allow children to operate this unit. Store unit indoors in a high, dry place out of the reach of children. When servicing unit, use only identical replacement parts. Always stop unit and disconnect spark plug before clean- ing or servicing.
-
Page 4: Optional Attachments
Never use flailing de- vices with any attachment. This unit (when used with supplied line trimmer attachment) is designed for line trimmer use only. Use of any other accessories with line trimmer attach- ment will increase the risk of injury. - Page 5 S Keep others away when making carburetor adjustments. S Use only recommended McCulloch acces- sories and replacement parts. S Have all maintenance and service not ex- plained in this manual performed by an au- thorized service dealer.
- Page 6 Blade can thrust violently away from material it does not cut. Blade thrust can cause amputation of arms or legs. WARNING: Do not use trimmer head as a fastening device for the blade. WARNING: The blade continues to spin after the trigger is released or engine is turned off.
- Page 7 bent, warped, cracked, broken or damaged in any other way. S Install required shield properly before using the unit. Use the metal shield for all metal blade use. WARNING: Only use brushcutter at- tachments that provide a metal shield with proboscis nose.
- Page 8 WARNING: Falling objects can cause severe head injury. Wear head protec- tion when operating this unit with a pole prun- er attachment. WARNING: To prevent serious inju- ry, do not use more than one boom extension with a pole pruner attachment. WARNING: Keep the pruner away from power lines or electrical wires.
- Page 9 LOOSEN Knob TIGHTEN 2. Remove shipping protector from coupler. 3. Remove the shaft cap from the trimmer attachment (if present). 4. Position locking/release button of attach- ment into guide recess of coupler. 5. Push the attachment into the coupler until the locking/release button snaps into the primary hole.
-
Page 10: Operation
OPERATION KNOW YOUR TRIMMER READ THIS INSTRUCTION MANUAL AND SAFETY RULES BEFORE OPERATING YOUR UNIT. Compare the illustrations with your unit to familiarize yourself with the location of the various controls and adjustments. Save this manual for future reference. Shaft... - Page 11 WARNING: Alternative fuels (not gas- oline) such as E- -15 (15% alcohol), E- -20 (20% alcohol), E- -85 (85% alcohol) are NOT classified as gasoline and are NOT approved for use in 2- -stroke gasoline engines. Use of alternative fuels will cause problems such as: improper clutch engagements, overheating, vapor lock, power loss, lubrication deficiency, deterioration of fuel lines, gaskets and internal carburetor...
-
Page 12: Operating Instructions
S Operate the engine at full throttle. S Hold the trimmer head parallel to and above the grassy area. S Tap the bottom of the trimmer head lightly on the ground one time. Approximately 2 inches (5 cm) of line will be advanced with each tap. - Page 13 S For mowing or sweeping, use full throttle for a good clean job. TRIMMING - - Hold the bottom of the trimmer head about 3 inches (8 cm) above the ground and at an angle. Allow only the tip of the line to make contact.
-
Page 14: Maintenance
MAINTENANCE WARNING: Disconnect the spark plug before performing maintenance except for carburetor adjustments. HELPFUL TIP IMPORTANT: Have all repairs other than the rec- ommended maintenance described in the instruction manual performed by an authorized service dealer. If any dealer other than an authorized service dealer performs work on the product, we may not pay for repairs un- der warranty. -
Page 15: Service And Adjustments
SERVICE AND ADJUSTMENTS REPLACING THE LINE 1. Press the tabs on the side of the trimmer head and remove cover and spool. Cover Spool 2. Remove any remaining line. 3. Clean dirt and debris from all parts. Re- place spool if it is worn or damaged. - Page 16 To adjust idle speed: Allow engine to idle. Adjust speed until engine runs without trimmer head or any optional at- tachment moving or spinning (idle too fast) or engine stalling (idle speed too slow).
- Page 17 Idle Speed Screw Air Filter Cover STORAGE WARNING: Perform the following steps after each use: S Allow engine to cool before storing or trans- porting. S Store unit and fuel in a well ventilated area where fuel vapors cannot reach sparks or open flames from water heaters, electric motors or switches, furnaces, etc.
- Page 18 WARNING: Always stop unit and disconnect spark plug before performing all of the recommended remedies below except remedies that require operation of the unit. TROUBLE CAUSE Engine will not 1. Engine flooded. start. 2. Fuel tank empty. 3. Spark plug not firing. 4.
-
Page 19: Limited Warranty
McCulloch, a division of Husqvarna Consumer Outdoor Products N.A., Inc., warrants to the original consumer purchaser that each new McCulloch brand gasoline tool or attachment is free from defects in material and workmanship and agrees to repair or replace under this war-... - Page 20 HOW TO FILE A CLAIM: If you have any questions regarding your warranty rights and responsibilities, you should contact your nearest authorized service center, call McCulloch at 1- -800- -554- -6723, or send e-mail correspondence to emission. warranty@HCOP- -emission.com. WHERE...
