CPU_FAN: FAN Power Connector
Pin Signal Name
1
GND
2
+12V
3 Sense
4 Control
Users please note that the fan connector supports the CPU cooling fan of
1.1A ~ 2.2A (26.4W max) at +12V.
SYS_FAN: System Cooling FAN Power Connector
Pin Signal Name
1
GND
2
+12V
3 Sense
PWR1: ATX 24-pin Power Connector
Pin Signal Name
1
+3.3V
2
+3.3V
3
Ground
4
+5V
5
Ground
6
+5V
7
Ground
8
PWRGD
9
+5VSB
10
+12V
11
+12V
12
+3.3V
PWR2: ATX 12V Power Connector
Pin Signal Name
1
Ground
2
Ground
3
+12V
4
+12V
Function
System Ground
Power +12V
Sensor
CPU FAN control
Function
System Ground
Power +12V
Sensor
Pin Signal Name
13
+3.3V
14
-12V
15
Ground
16
PS_ON
17
Ground
18
Ground
19
Ground
20
-5V
21
+5V
22
+5V
23
+5V
24
Ground
