Driving Your Mazda

Instrument Cluster and Indicators

(Black-out meter)
When the ignition switch is in the ON position, the dashboard gauges illuminate.
Speedometer ...................................................................................................... page 5-33
Odometer, Trip Meter and Trip Meter Selector .................................................. page 5-33
Tachometer ........................................................................................................ page 5-34
Engine Coolant Temperature Gauge .................................................................. page 5-34
Fuel Gauge ........................................................................................................ page 5-35
Instrument Cluster Dimmer Select Button (Black-out meter) ............................ page 5-35
5-32

Meters and Gauges
