DIVAR IP 6000 1U
2

System overview

DIVAR IP 6000 is an affordable, simple and reliable all-in-one recording management solution
for network surveillance systems of up to 64 cameras. Powered by VRM (Video Recording
Manager) software, the system is an intelligent IP storage device that eliminates the need for
separate NVR (Network Video Recorder) server and storage hardware.
The 1U rack mount unit combines advanced recording management and state-of-the-art iSCSI
storage into a single cost-effective, plug and play IP recording appliance for IT-minded
customers seeking for a state-of-the-art "second generation" NVR recording solution.
The DIVAR IP 6000 1U chassis features a unique and highly-optimized design. The chassis is
equipped with high efficiency power supply.
High performance fans provide ample optimized cooling for memory modules. Hot-swap drive
bays offer maximum storage capacity in a 1U form factor.
DIVAR IP 6000 features:
–
–
For information on supported hardware, see the datasheet for DIVAR IP 6000 in the Bosch
Online Product Catalog.
2.1

Chassis features

The DIVAR IP 6000 1U high performance chassis includes the following features:
–
–
–
2.2

Chassis components

This chapter describes the most common components included with your chassis. For more
information, see the installation instructions detailed later in this manual.
2.2.1

Chassis

The chassis includes 1 slim CD-ROM bay and 4 hard drive bays. The chassis accepts a 1U
backplane, 4 fans and 2 power supplies.
Bosch Sicherheitssysteme GmbH
Instant real time access to video
View high quality HD video despite low or limited bandwidth connections. Dynamic
Transcoding technology ensures that you can view your video immediately — anytime,
anywhere.
Remote viewing
DIVAR IP 6000 comes with our advanced Video Client for remote viewing. Video Client is a
Windows PC application for live viewing and playback including Configuration Manager.
Configuration Manager allows the settings of the DIVAR IP 6000 be configured. A stand-
alone archive player will allow archive playback and authentication without any other
workstation software.
CPU
The chassis supports a Dual-core Xeon processor.
Hard Drives
The chassis features 4 slots for SATA drives. These drives are hot swappable. Once setup
correctly, these drives can be removed without turning off the unit. In addition, these
drives support SES2 (SAS/SATA).
Other Features
Other onboard features are included to promote system health. These include various
4 cooling fans, a convenient power switch, reset button, and 5 LED indicators.
