3 | Getting Started
Step B – Identifying your IP
Address Type
Start with a computer that is
currently running on your existing
network. To determine if your
computer network is using Static
or Dynamic IP's:
1.
Click: The Windows
Start Button
2.
Click: Run
1.
2.
3. Enter: "cmd" into the Run
window (without quotes)
4.
Click: OK
3.
4.
Important: Before proceeding
with this step, be sure your PC
is connected to your network or
to your modem. If you are using
a wireless or stand alone PC,
connect the new NETGEAR Router
to your PC LAN port with the
provided Ethernet cable.
Robert Bosch LLC
M-VCI – NETGEAR® Router Installation Guide Index | Version 1.0 | June 2009
Step C – At the MS-DOS
Prompt – Check DHCP
1.
Type: "ipconfig/all" (without
quotes) into the command
window
2.
Compare output to the
examples below
3.
Output must include the line
"DHCP Enabled... Yes"
4.
Also verify that "DHCP Server"
is present
The actual numbers for the IP
addresses are irrelevant
If your output matches the output
above then you may continue this
guide.
If DHCP Enabled = No, then
additional steps must be taken
to configure the M-VCI. (See
Appendix A – Static Network
Reference Guide)
Step D – Choosing your
Setup type and Special
Instructions
Type I (Current setup w/router.
Existing router as DHCP server)
Type II (Current setup w/DSL or
cable modem and no router. The
ISP is the DHCP server)
Type III (No internet connection)
If your setup looks most like Type
I - Follow Instructions & "Special
Instructions for Type I"
If your setup looks most like Type
II - Follow Instructions & "Special
Instructions for Type II"
If your setup looks most like Type
III - Follow Instructions & "Special
Instructions for Type III"
The M-VCI – NETGEAR Router
install procedure is similar
for all types. When a "Special
Instruction" is called out, please
M-VCI – NETGEAR® Router Installation Guide Index | Version 1.0 | June 2009
Getting Started | 4
follow the one pertaining to your
setup type.
The Type III has no internet
connection but uses the
NETGEAR Router to enhance
M-VCI to PC wireless
communication.
Example – Final Setup
Configuration for Type I
This shows the new NETGEAR
pre-configured router installed
into a network (Setup Type I) with
a pre-existing wireless router. No
network changes need to be made
to existing routers or computers.
Do not perform this final set up
until directed to do so. You need
to configure your new NETGEAR
Router first.
Example – Final Setup
Configurations for Types II
& III
Robert Bosch LLC
