Page 1 D-Link ™ DGS-3312SR 12-Port Gigabit Layer 3 Stackable Switch Release II Manual Second Edition (June 2004) Version 0.2 Printed In Taiwan RECYCLABLE...
Page 2 Microsoft Corporation. Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. D-Link Computer Corporation disclaims any proprietary interest in trademarks and trade names other than its own.
Page 3: Table Of Contents
DGS-3312SR Gigabit Layer 3 Switch Table of Contents About This Manual ................................viii Intended Readers ................................viii Typographical Conventions............................. viii Notes, Notices, and Cautions............................viii Safety Instructions................................ix Safety Cautions...................................ix General Precautions for Rack-Mountable Products......................x Protecting Against Electrostatic Discharge ........................xi Introduction....................................1 Switch Description ................................1...
Page 4 DGS-3312SR Gigabit Layer 3 Switch Before You Start................................19 General Deployment Strategy............................19 VLAN Setup .................................20 Defining Static Routes..............................20 Web-based User Interface ..............................20 Areas of the User Interface ............................20 Login to Web Manager..............................21 Web Pages and Folders..............................22 Basic Setup..................................22 Switch Information ...............................22 Switch IP Settings.................................23...
Page 5 DGS-3312SR Gigabit Layer 3 Switch Forwarding & Filtering ..............................59 Unicast Forwarding ..............................60 Multicast Forwarding ..............................60 VLANs ....................................61 802.1Q Static VLANs..............................65 802.1Q Port Settings..............................68 QoS....................................69 802.1p Default Priority ..............................69 802.1p User Priority ..............................70 QoS Output Scheduling Configuration.........................71 Traffic Segmentation ..............................71 Bandwidth Control ...............................72 MAC Notification................................73...
Page 6 DGS-3312SR Gigabit Layer 3 Switch DHCP/Bootp Relay Settings............................122 DNS Relay..................................122 DNS Relay Information..............................123 DNS Relay Static Settings ............................123 VRRP ....................................124 VRRP Configuration ..............................124 VRRP Interface Settings.............................124 IP Multicast ..................................129 IGMP Interface Settings .............................129 DVMRP..................................131 PIM.....................................132 Security ....................................134 Trusted Host ..................................134 Secure Socket Layer (SSL) .............................135...
Page 7 DGS-3312SR Gigabit Layer 3 Switch Port Utilization ................................166 CPU Utilization ................................168 Packets.....................................168 Received Packets ................................169 Received Unicast/Multicast/Broadcast Packets ......................171 Transmitted Packets..............................173 Errors....................................175 Received Errors ................................175 Transmitted Errors..............................177 Size ....................................179 Packet Size..................................179 MAC Address..................................181 Switch History.................................183 IGMP Snooping Table..............................184 Browser Router Port................................184 VLAN Status ...................................185...
Page 8 DGS-3312SR Gigabit Layer 3 Switch Save Changes ..................................197 Factory Reset...................................197 Restart System.................................198 Logout .....................................199 Single IP Management .................................200 SIM Settings..................................201 Topology ..................................202 Tool Tips ..................................205 Right-click ..................................206 Group Icon..................................206 Commander Switch Icon ............................207 Member Switch Icon ..............................208 Candidate Switch Icon..............................209 Menu Bar ..................................210...
Page 9: About This Manual
Management—have separate chapters. Configuration is divided into two chapters, Basic Configuration and Advanced Configuration. Intended Readers The DGS-3312SR Manual contains information useful for setup and management and of the DGS-3312SR Switch. This manual is intended for network managers familiar with network management concepts and terminology. Typographical Conventions...
Page 10: Safety Instructions
DGS-3312SR Gigabit Layer 3 Switch A NOTICE indicates either potential damage to hardware or loss of data and tells you how to avoid the problem. A CAUTION indicates a potential for property damage, personal injury, or death. Safety Instructions Use the following safety guidelines to ensure your own personal safety and to help protect your system from potential damage.
Page 11: General Precautions For Rack-Mountable Products
DGS-3312SR Gigabit Layer 3 Switch 100 V/50 Hz in eastern Japan and 100 V/60 Hz in western Japan • 230 V/50 Hz in most of Europe, the Middle East, and the Far East • • Also be sure that attached devices are electrically rated to operate with the power available in your location.
Page 12: Protecting Against Electrostatic Discharge
DGS-3312SR Gigabit Layer 3 Switch • Always load the rack from the bottom up, and load the heaviest item in the rack first. • Make sure that the rack is level and stable before extending a component from the rack.
Page 13 DGS-3312SR Gigabit Layer 3 Switch...
Page 14: Introduction
Management Options Switch Description The DGS-3312SR is a modular Gigabit Ethernet backbone Switch designed for adaptability and scalability. The Switch provides a management platform and uplink to backbone for a stacked group of up to twelve DES-3226S Switches in a star topology arrangement.
Page 15: Front-Panel Components
DGS-3312SR Gigabit Layer 3 Switch • Supports CLI management. • Supports BOOTP/DHCP/DNS Relay • Supports TFTP upgrade • Supports System Log • Fully configurable either in-band or out-of-band control via RS-232 console serial connection. • Telnet remote control console •...
Page 16: Stacking Led Indicators
NOTICE: The four build-in combination ports on the front panel of the DGS-3312SR can be configured as stacking ports using the CLI. Each stacking module has a single Link/Act LED indicator on its front panel for each IEEE 1394 IN/OUT pair.
Page 17: Rear Panel Description
The Switch supports the D-Link RPS-200 or RPS-500 redundant power supply units. Plug-in Modules The DGS-3312SR Switch is able to accommodate optional plug-in modules in order to increase functionality and performance. Two modules may be installed and used in combination with any of the three available modules. Plug-in modules must be purchased separately.
Page 18: Dem-340Mg Sfp (Mini Gbic) Module
3312SR. Two stacking modules may be used to form a nine-Switch stack consisting of one Master and eight Slaves, managed through the DGS-3312SR Master Switch. The stacked group has a single IP address and is managed as a single device. The entire Switch stack is managed and monitored through the network or alternatively, through the serial port on the DGS-3312SR.
Page 19: Management Options
Switch to an OUT port on the next Switch in the stack. Restrictions and Cautions for Stacking The DGS-3312SR may serve as the Master of up to twelve additional Switches. The slave Switch units must meet the following criteria: •...
Page 20 DGS-3312SR Gigabit Layer 3 Switch • RFC 1850 OSPF MIB • RFC 1907 SNMPv2 MIB • RFC 2021 RMON II MIB • RFC 2096 IP-FORWARD MIB • RFC 2233 IF-MIB • RFC 2358 Ethernet-Link MIB • RFC 2573 SNMP Notification and Target MIB •...
Page 21: Installation
DGS-3312SR Gigabit Layer 3 Switch SECTION 2 Installation Package Contents Before You Connect to the Network Installing the Switch without a Rack Installing the Switch in a Rack Connecting Stacked Switch Groups Configuring a Switch Group for Stacking External Redundant Power System...
Page 22: Installing The Switch In A Rack
DGS-3312SR Gigabit Layer 3 Switch 2. Set the Switch on a flat surface and check for proper ventilation. Allow at least 5 cm (2 inches) on each side of the Switch and 15 cm (6 inches) at the back for the power cable.
Page 23: Mounting The Switch In A Standard 19" Rack
Restrictions for Stacking on page 6). A stacked group of DES-3226S Switches are connected using a star topology. The instructions below, Configuring a Switch Group for Stacking, tell you how to configure the DGS-3312SR to function as a Master, as well as how to configure the DES-3226S to function as a slave Switch units using the CLI interface.
Page 24 DGS-3312SR Gigabit Layer 3 Switch Stacking Connections with IEEE 1394 and Ethernet Cabling Figure 2-4. Star Topology Stacked Switch Group The stacking ports are marked IN and OUT. The IEEE 1394 compliant cable must be connected from an IN port on one...
Page 25: Configuring A Switch Group For Stacking
DGS-3312SR Gigabit Layer 3 Switch Configuring a Switch Group for Stacking Follow the instructions below to first configure the slave units, and then to configure the DGS-3312SR as the designated Master. NOTICE: The DGS-3312SR can be used to manage a Switch stack consisting of only DES-3226S Switches.
Page 26: External Redundant Power System
Unit ID Display for Switches in a Switch Stack The Stack ID 7-segment LED (as shown below) on the front panel of the DGS-3312SR will always display F (15 in hex). An F will also be displayed in the Stack ID LED even if the DGS-3312SR is in standalone mode.
Page 27: Connecting The Console Port
DGS-3312SR Gigabit Layer 3 Switch Figure 2-8. DPS-200 with DGS-3312SR NOTE: See the DPS-200 documentation for more information. CAUTION: Do not use the Switch with any redundant power system other than the DPS-200 or DPS-500. Connecting the Console Port The Switch provides an RS-232 serial port that enables a connection to a computer or terminal for monitoring and configuring the Switch.
Page 28: Password Protection
Password Protection The DGS-3312SR does not have a default user name and password. One of the first tasks when settings up the Switch is to create user accounts. If you log in using a predefined administrator-level user name you have privileged access to the Switch’s management software.
Page 29: Snmp Settings
The DGS-3312SR supports the SNMP versions 1, 2c, and 3. You can specify which version of the SNMP you want to use to monitor and control the Switch. The three versions of SNMP vary in the level of security provided between the management station and the network device.
Page 30: Ip Address Assignment
DGS-3312SR Gigabit Layer 3 Switch Identifier (OID) associated with a specific MIB. An additional layer of security is available for SNMP v.3 in that SNMP messages may be encrypted. To read more about how to configure SNMP v.3 settings for the Switch read the next section, Management.
Page 31: Connecting Devices To The Switch
DGS-3312SR Gigabit Layer 3 Switch 2. Alternatively, you can enter config ipif System ipaddress xxx.xxx.xxx.xxx/z. Where the x’s represent the IP address to be assigned to the IP interface named System and the z represents the corresponding number of subnets in CIDR notation.
Page 32: Basic Switch Management
This flexibility and rich feature set requires a bit of thought to arrive at a deployment strategy that will maximize the potential of the DGS-3312SR Layer 3 Switch. Please read the portions of this manual pertaining to the functions you wish to perform with the Switch.
Page 33: Vlan Setup
7. Develop a redundancy scheme. Planning redundant links and routes to network critical resources can save valuable time in case of a link or device failure. The DGS-3312SR Spanning Tree function can be used to block the redundant link until it is needed.
Page 34: Login To Web Manager
DGS-3312SR Gigabit Layer 3 Switch Area 1 Area 2 Area 3 Figure 3-1. Main Web-Manager window Area Function Presents a graphical near real-time image of the front panel of the Switch. This area displays the Switch’s ports and expansion modules. When the Switch is stacked a virtual representation of the Switch stack appears in the right hand portion.
Page 35: Web Pages And Folders
DGS-3312SR Gigabit Layer 3 Switch In the Welcome page, click on the Login hyperlink; this opens a login dialog box. Enter a user name and password to access the Switch’s management main page (pictured above). There is no user name or password configured for the Switch in the default settings, so if this is the first time logging in it is not necessary to enter these.
Page 36: Switch Ip Settings
DGS-3312SR Gigabit Layer 3 Switch Figure 3-2. Switch Information (Basic Settings) window This window displays general information about the Switch including its MAC Address, Hardware Boot PROM and Firmware versions, and installed module information. Switch IP Settings Switch IP settings may initially be set using the console interface prior to connecting to it through the Ethernet. If the...
Page 37 DGS-3312SR Gigabit Layer 3 Switch NOTE: The Switch’s factory default IP address is 10.90.90.90 with a subnet mask of 255.0.0.0 and a default gateway of 0.0.0.0. To manually assign the Switch’s IP address, subnet mask, and default gateway address: •...
Page 38: Security Ip Management Stations Configuration
DGS-3312SR Gigabit Layer 3 Switch Management stations that are on VLANs other than the one entered in the VID field will not be able to manage the Switch in-band unless their IP addresses are entered in the Security IP Management menu. If VLANs have not yet been configured for the Switch, the default VID (1) contains all of the Switch’s ports.
Page 39: User Account Management
DGS-3312SR Gigabit Layer 3 Switch User Account Management Use the User Account Management to control user privileges. To view existing User Accounts, open the Management folder and click on the User Accounts link. This will open the User Account Management window, as shown below.
Page 40: Save Changes
DGS-3312SR Gigabit Layer 3 Switch Management Admin User Configuration Read Only Network Monitoring Read Only Community Strings and Trap Stations Read Only Update Firmware and Configuration Files System Utilities PING Only Factory Reset User Account Management Add/Update/Delete User Accounts View User Accounts Table 3- 1.
Page 41: Restart System
DGS-3312SR Gigabit Layer 3 Switch Figure 3- 9. Factory Reset to Default Value window The following options are available to perform a factory reset: • Reset − Returns all configuration settings to the factory default settings except the Switch’s stacking mode, IP address, subnet mask, and default gateway settings.
Page 42: Advanced Settings
DGS-3312SR Gigabit Layer 3 Switch Figure 3- 10. Restart System window NOTE: Clicking Yes is equivalent to executing Save Changes and then restarting the Switch. Advanced Settings Figure 3- 11. Switch Information (Advanced Settings) window The Advanced Settings options are summarized in the table below:...
Page 43: Switch Stack Management
Syslog state Switch Stack Management The DGS-3312SR Switch can be used as a standalone high-capacity Switch or be used in a stacked arrangement. There are two hardware requirements to use the Switch in a stacked group: 1. The proper module(s) must be installed. One or two DEM-540 Stacking modules must be installed in order to use the Switch in a stacked configuration.
Page 44: Configure Stacking
The current order in the Switch stack is also displayed on the front panel of each slave Switch, under the STACK NO. heading. The Stack ID LED display on the front panel of the DGS-3312SR will always display an F (15 in hex), regardless of whether the DGS-3312SR is the master Switch in a Switch stack or in standalone mode.
Page 45 DGS-3312SR Gigabit Layer 3 Switch Figure 3- 13. Stack Mode Setup (stacking enabled) window Variables in this window are described below: Parameter Description Displays the Switch’s order in the stack. The Switch with a unit id of 1 is the master Switch.
Page 46 DGS-3312SR Gigabit Layer 3 Switch Figure 3- 14. Stack Information web page...
Page 47: Basic Configuration
DGS-3312SR Gigabit Layer 3 Switch Section 4 Basic Configuration Switch Information IP Address Advanced Settings Port Configuration Port Description Port Mirroring Traffic Control Link Aggregation LACP Port Settings Port Access Entity 802.1X Authenticator Settings PAE System Control 802.1X Capability Settings...
Page 48: Switch Information
Time Zone and DST Access Profile Table The DGS-3312SR’s Web interface is divided into six main folders: Configuration, Security, Management, Monitoring, Maintenance, and Single IP Management. This chapter describes all of the Configuration sub-folders and windows except those found in the Layer 3 IP Networking sub-folder, which are explained in the next chapter, “Advanced Configuration.”...
Page 49 DGS-3312SR Gigabit Layer 3 Switch Open the Configuration folder and click the IP Address button. The web manager will display the Switch IP Settings window below. Figure 4- 2. Switch IP Settings window NOTE: The Switch’s factory default IP address is 10.90.90.90 with a subnet mask of 255.0.0.0 and a default gateway of 0.0.0.0.
Page 50 DGS-3312SR Gigabit Layer 3 Switch number (represented in decimal form) between 0 and 255. This address should be a unique address on the network assigned for use by the network administrator. The fields which require entries under this option are as follows: Subnet Mask A Bitmask that determines the extent of the subnet that the Switch is on.
Page 51: Advanced Settings
DGS-3312SR Gigabit Layer 3 Switch Advanced Settings Figure 4- 3. Switch Information (Advanced Settings) window The Advanced Settings options are summarized in the table below: Parameter Description Serial Port Auto Select the logout time used for the console interface. This automatically logs the user out after an idle period of time as defined.
Page 52: Port Configuration
DGS-3312SR Gigabit Layer 3 Switch all multicast traffic to any IP router. Telnet Status Telnet configuration is Enabled by default. If you do not want to allow configuration of the system through Telnet choose Disabled. Telnet TCP Port The Telnet TCP port number. TCP ports are numbered between 1 and 65535. The "well-known"...
Page 53 DGS-3312SR Gigabit Layer 3 Switch...
Page 54 DGS-3312SR Gigabit Layer 3 Switch Figure 4- 4. Port Configuration window To configure Switch ports: Choose the Unit from the pull-down menu. Choose the port or sequential range of ports using the From…To… port pull-down menus. Use the remaining pull-down menus to configure the parameters described in the table below.
Page 55: Port Description
DGS-3312SR Gigabit Layer 3 Switch Port Description The Switch supports a port description feature where the user may name various ports on the Switch. To assign names to various ports, click Port Description on the Configuration folder: Figure 4- 5. Port Description Setting window...
Page 56: Traffic Control
DGS-3312SR Gigabit Layer 3 Switch Figure 4- 6. Setup Port Mirroring window To configure a mirror port: • Select the Source Unit containing the port that is being mirrored. • Configure how the port is to be mirrored by selecting the direction that will be mirrored. Choose Ingress, Egress, or Both for the mirrored port by clicking the appropriate radio button for the port.
Page 57: Link Aggregation
DGS-3312SR Gigabit Layer 3 Switch Figure 4- 7. Traffic Control Setting window Traffic or storm control is used to stop broadcast, multicast or ARP request storms that may result when a loop is created. The Destination Look Up Failure control is a method of shutting down a loop when a storm is formed because a MAC address cannot be located in the Switch’s forwarding database and it must send a packet to all ports or all ports on a...
Page 58 DGS-3312SR Gigabit Layer 3 Switch The Spanning Tree Protocol will treat a link aggregation group as a single link, on the Switch level. On the port level, the STP will use the port parameters of the Master Port in the calculation of port cost and in determining the state of the link aggregation group.
Page 59: Lacp Port Settings
DGS-3312SR Gigabit Layer 3 Switch Type This pull-down menu allows you to select between Static and LACP (Link Aggregation Control Protocol.) LACP allows for the automatic detection of links in a Port Trunking Group. Master Port Choose the Master port for the trunk group.
Page 60: Port Access Entity
DGS-3312SR Gigabit Layer 3 Switch Parameter Description Unit This is the Unit ID of a Switch in a Switch stack. The number 15 indicates a DGS- 3312SR Switch in standalone mode. A consecutive group of ports may be configured starting with the selected port.
Page 61 DGS-3312SR Gigabit Layer 3 Switch Figure 4- 12. Typical 802.1X Configuration with User Authentication The user’s information, including account number, password, and configuration details such as IP address and billing information, is stored in a centralized RADIUS server. Figure 4- 13. Typical Configuration with 802.1X Fully Implemented...
Page 62: 802.1X Authenticator Settings
DGS-3312SR Gigabit Layer 3 Switch State Machine Name Port Timers state machine Authenticator PAE state machine The Authenticator Key Transmit state machine Reauthentication Timer state machine Backend Authentication state machine Controlled Directions state machine The Key Receive state machine Table 4- 1. Conformance to IEEE 802.1X Standards 802.1X Authenticator Settings...
Page 63 DGS-3312SR Gigabit Layer 3 Switch Figure 4- 15. 2 802.1X Authenticator Settings window The following Authenticator Settings parameters can be set: Parameter Description Allows you to specify a Switch in a Switch stack using that Switch’s Unit ID. The Unit number 15 indicates a Switch in standalone mode.
Page 64: Pae System Control
DGS-3312SR Gigabit Layer 3 Switch Select the time interval between authentication failure and the start of a new QuietPeriod authentication attempt. Select the time to wait for a response from a supplicant (user) for all EAP packets, SuppTimeout except for the Request/Identity packets.
Page 65: Igmp
DGS-3312SR Gigabit Layer 3 Switch RADIUS Server Click the Radius Server link in the Radius Server folder under Port Access Entity. Figure 4- 17. Authentic Radius Server Setting window The following parameters can be set: Parameter Description Succession RADIUS server settings index.
Page 66: Igmp Snooping
DGS-3312SR Gigabit Layer 3 Switch IGMP host or vice versa. The Switch monitors IGMP messages and discontinues forwarding multicast packets when there are no longer hosts requesting that they continue. IGMP Snooping Use this window to view IGMP Snooping status. To modify settings, click the Modify button for the VLAN ID you want to change.
Page 67: Static Router Ports
DGS-3312SR Gigabit Layer 3 Switch value is 125. Max Response Time This determines the maximum amount of time in seconds allowed before sending an IGMP response report. The Max Response Time field allows an entry between 1 and 25 (seconds). The default value is 10.
Page 68: Spanning Tree
The Switch supports 802.1d Spanning Tree Protocol (STP) and 802.1w Rapid Spanning Tree Protocol (RSTP). 802.1d STP will be familiar to most networking professionals. However since 802.1w RSTP has been recently introduced to D-Link managed Ethernet Switches, a brief introduction to the technology is provided below followed by a description of how to set up 802.1 d STP and 802.1w RSTP.
Page 69: Stp Switch Settings
DGS-3312SR Gigabit Layer 3 Switch Port Transition States An essential difference between the two protocols is in the way ports transition to a forwarding state and the in the way this transition relates to the role of the port (forwarding or not forwarding) in the topology. RSTP combines the transition states disabled, blocking and listening used in 802.1d and creates a single state Discarding.
Page 70 DGS-3312SR Gigabit Layer 3 Switch Figure 4- 22. Switch Spanning Tree Settings window Configure the following system-wide STP parameters and click the Apply button to implement them: Parameter Description Spanning Tree This field can be toggled between Enabled and Disabled using the pull-down menu.
Page 71: Stp Port Settings
DGS-3312SR Gigabit Layer 3 Switch Bridge Forward The Forward Delay can be from 4 to 30 seconds. This is the time any port on the Delay (4 - 30 sec) Switch spends in the listening state while moving from the blocking state to the <15 >...
Page 72: Forwarding & Filtering
DGS-3312SR Gigabit Layer 3 Switch In addition to setting Spanning Tree parameters for use on the Switch level, the Switch allows for the configuration of groups of ports, each port-group of which will have its own spanning tree, and will require some of its own configuration settings.
Page 73: Unicast Forwarding
DGS-3312SR Gigabit Layer 3 Switch Unicast Forwarding Open the Forwarding & Filtering folder and click on the Unicast Forwarding link. This will open the Setup Static Unicast Forwarding Table window, as shown below. Figure 4- 24. Setup Static Unicast Forwarding Table window...
Page 74: Vlans
VLANs are based on layer 3 information, however this does not constitute a ‘routing’ function. The DGS-3312SR and associated DGS-3312SR series Switches allow an IP subnet to be configured for each 802.1Q VLAN that exists on the Switch. That is, a VLAN can be associated or attached to an IP subnet. This represents an improvement in performance since it bypasses any routing functions, packets transferred between subnets are reduced to a “hardware”...
Page 75: Assigning Ip Network Addresses And Subnet Masks To Vlans
VLANs must be configured on the Switch before they can be assigned IP subnets. Furthermore, the static VLAN configuration is specified on a per port basis. On the DGS-3312SR, a VLAN can consist of end-nodes – just like a traditional layer 2 Switch, but a VLAN can also consist of one or more Switches – each of which is connected to multiple end-nodes or network resources.
Page 76: Q Vlan Tags
DGS-3312SR Gigabit Layer 3 Switch Figure 4- 27. 802.1Q Packet Forwarding 802.1Q VLAN Tags The figure below shows the 802.1Q VLAN tag. There are four additional octets inserted after the source MAC address. Their presence is indicated by a value of 0x8100 in the EtherType field. When a packet’s EtherType field is equal to 0x8100, the packet carries the IEEE 802.1Q/802.1p tag.
Page 77: Port Vlan Id
DGS-3312SR Gigabit Layer 3 Switch Figure 4- 29. Adding an IEEE 802.1Q Tag Port VLAN ID Packets that are tagged (are carrying the 802.1Q VID information) can be transmitted from one 802.1Q compliant network device to another with the VLAN information intact. This allows 802.1Q VLANs to span network devices (and indeed, the entire network –...
Page 78: 802.1Q Static Vlans
DGS-3312SR Gigabit Layer 3 Switch Ingress Filtering A port on a Switch where packets are flowing into the Switch and VLAN decisions must be made is referred to as an ingress port. If ingress filtering is enabled for a port, the Switch will examine the VLAN information in the packet header (if present) and decide whether or not to forward the packet.
Page 79 DGS-3312SR Gigabit Layer 3 Switch Figure 4- 31. 2 802.1Q Static VLANs window To configure the newly created VLAN, select the Switch being configured from the Unit drop-down menu and provide a unique VLAN identifier and name. Configure the port settings for VLAN membership by selecting the appropriate options for each port.
Page 80 DGS-3312SR Gigabit Layer 3 Switch Figure 4- 32. Add New Static VLAN Example window Click the Show All Static VLAN Entries link to return to the first 802.1Q Static VLANs window, the new VLAN entry appears listed in the current entries table.
Page 81: 802.1Q Port Settings
DGS-3312SR Gigabit Layer 3 Switch 802.1Q Port Settings Open the 802.1Q Port Settings window and select the Unit and range of ports to configure. For the selected port or group of ports, choose to enable or disable Ingress checking and establish an acceptable packet rule. Ingress Checking is used to limit traffic by filtering incoming packets that have a PVID does not match the PVID of the port.
Page 82: Qos
DGS-3312SR Gigabit Layer 3 Switch A Port VLAN Identifier is a classification mechanism that associates a port with a specific VLAN and is used to make forwarding decisions for untagged packets received by the port. For example, if port 2 is assigned a PVID of 3, then all PVID untagged packets received on port 2 will be assigned to VLAN 3.
Page 83: 802.1P User Priority
0 − the lowest priority − to 7 − the highest priority. 802.1p User Priority The DGS-3312SR allows the assignment of a User Priority to each of the 802.1p priorities. Figure 4- 37. User Priority Configuration window Once you have assigned a priority to the port groups on the Switch, you can then assign this Class to each of the eight...
Page 84: Qos Output Scheduling Configuration
DGS-3312SR Gigabit Layer 3 Switch QoS Output Scheduling Configuration QoS can be customized by changing the output scheduling used for the hardware queues in the Switch. As with any changes to QoS implementation, careful consideration should be given to how network traffic in lower priority queues are affected.
Page 85: Bandwidth Control
DGS-3312SR Gigabit Layer 3 Switch Figure 4- 39. Traffic Segmentation Setting window The Unit drop-down menu at the top of the page allows you to select a Switch from a Switch stack using that Switch’s Unit ID. The Port drop-down menu allows you to select a port from that Switch. This is the port that will be transmitting packets.
Page 86: Mac Notification
DGS-3312SR Gigabit Layer 3 Switch Figure 4- 40. Bandwidth Settings window The following parameters can be set or are displayed: Parameter Description Unit Allows you to specify a Switch in a Switch stack using that Switch’s Unit ID. The number 15 indicates a Switch in standalone mode.
Page 87: Mac Notification Global Settings
DGS-3312SR Gigabit Layer 3 Switch MAC Notification Global Settings Figure 4- 41. MAC Notification Global Settings window The following parameters can be set: Parameter Description State This drop-down menu is used to enable or disable MAC notification on the selected Switch.
Page 88: Mac Notification Port Settings
DGS-3312SR Gigabit Layer 3 Switch MAC Notification Port Settings Enable or disable MAC notification for ports with the window below. Figure 4- 42. MAC Notification Port Settings window The following parameters can be set: Parameter Description Unit Allows you to specify a Switch in a Switch stack using that Switch’s Unit ID. Number 15 indicates a Switch in standalone mode.
Page 89 DGS-3312SR Gigabit Layer 3 Switch Figure 4- 43. System Log Servers window Click the Add button to bring up the window pictured below. The parameters configured for adding System Log are described in the table below. To eliminate a System Log Server configuration, click the X in the Delete column for the configuration being removed.
Page 90: Port Security
DGS-3312SR Gigabit Layer 3 Switch UUCP subsystem clock daemon security/authorization messages FTP daemon NTP subsystem log audit log alert clock daemon local use 0 (local0) local use 1 (local1) local use 2 (local2) local use 3 (local3) local use 4 (local4)
Page 91: Sntp Setting
DGS-3312SR Gigabit Layer 3 Switch Parameter Description Unit Allows you to specify a Switch in a Switch stack using that Switch’s Unit ID. The number 15 indicates a Switch in standalone mode. From/To A consecutive group of ports may be configured starting with the selected port.
Page 92: Time Zone And Dst Settings
DGS-3312SR Gigabit Layer 3 Switch Time Source Displays the time source for the system. SNTP State Use this pull-down menu to enable or disable SNTP. SNTP Secondary This is the primary server the SNTP information will be taken from Server SNTP Poll Interval in This is the interval between requests for updated SNTP information.
Page 93: Access Profile Table
DGS-3312SR Gigabit Layer 3 Switch Parameter Description Daylight Saving Use this pull-down menu to enable or disable the DST Settings. Time State Daylight Saving Use this pull-down menu to specify the amount of time that will constitute your local Time Offset in DST offset −...
Page 94 DGS-3312SR Gigabit Layer 3 Switch Creating an access profile is divided into two basic parts. The first is to specify which part or parts of a frame the Switch will examine, such as the MAC source address or the IP destination address. The second part is entering the criteria the Switch will use to determine what to do with the frame.
Page 95 DGS-3312SR Gigabit Layer 3 Switch Vlan Selecting this option instructs the Switch to examine the VLAN part of each packet header and use this as the, or part of the criterion for forwarding. Source Mac Source MAC Mask - Enter a MAC address mask for the source MAC address.
Page 96 DGS-3312SR Gigabit Layer 3 Switch Parameter Description Type in a unique identifier number for this profile set or allow an ID to be Profile ID(1-255) automatically assigned by checking the Auto Assign option. This value can be set from 1 to 255.
Page 97 DGS-3312SR Gigabit Layer 3 Switch The user may set the Access Profile Table window on a per-port basis by entering a Port port number in this field. Entering “all” will denote all ports on the Switch. The window shown below is the Access Profile Configuration window for Packet Content Mask.
Page 98 DGS-3312SR Gigabit Layer 3 Switch from 1 to 255. Select profile based on Ethernet (MAC Address), IP address or packet content mask. This will change the menu according to the requirements for the type of profile. Select Ethernet to instruct the Switch to examine the layer 2 part of each •...
Page 99 DGS-3312SR Gigabit Layer 3 Switch Figure 4- 53. Access Rule Configuration (Ethernet) window Configure the Access Rule Configuration settings on the window above. The following parameters can be set: Parameter Description Profile ID This is the identifier number for this profile set.
Page 100 DGS-3312SR Gigabit Layer 3 Switch user priority re-written to its original value before being transmitted from the switch. Select this option to instruct the Switch to replace the DSCP value (in a packet that Replace Dscp(0-63) meets the selected criteria) with the value entered in the adjacent field.
Page 101 DGS-3312SR Gigabit Layer 3 Switch Mode Select Permit to specify that the packets that match the access profile are forwarded by the Switch, according to any additional rule added (see below). Select Deny to specify that packets that do not match the access profile are not forwarded by the Switch and will be filtered.
Page 102 DGS-3312SR Gigabit Layer 3 Switch Figure 4- 55. Access Rule Configuration (Package Content Mask) window Configure the Access Rule Configuration settings on the window above. The following parameters can be set: Parameter Description Profile ID This is the identifier number for this profile set.
Page 103 DGS-3312SR Gigabit Layer 3 Switch Mode Select Permit to specify that the packets that match the access profile are forwarded by the Switch, according to any additional rule added (see below). Select Deny to specify that packets that do not match the access profile are not forwarded by the Switch and will be filtered.
Page 104: Advanced Configuration
DGS-3312SR Gigabit Layer 3 Switch Section 5 Advanced Configuration L3 Global Advanced Settings IP Interface Settings MD5 Key Settings Route Redistribution Settings Static/Default Route Settings Static ARP Settings RIP Global Setting RIP Interface Settings OSPF OSPF General Setting OSPF Area ID Settings...
Page 105: L3 Global Advanced Settings
DGS-3312SR Gigabit Layer 3 Switch L3 Global Advanced Settings In order to use DVMRP, PIM-DM, RIP, or OSPF, the Switch must first be globally enabled. To enable or disable these Layer 3 protocols as well as configure ARP Aging Time, access the L3 Global Advanced Settings window.
Page 106 DGS-3312SR Gigabit Layer 3 Switch Figure 5- 3. 2 IP Interface Settings window Enter the desired IP interface settings and click the Apply button. A message should appear informing you if the settings have been successfully applied. For convenience, you may want to use the same name for the IP interface and the VLAN.
Page 107: Introduction To Ospf
DGS-3312SR Gigabit Layer 3 Switch must match the existing Admin. State Select Enabled or Disabled to activate or deactivate the interface. Port/Member Specify which of the ports on the Switch will be a member of this VLAN. Introduction to OSPF The Open Shortest Path First (OSPF) routing protocol that uses a link-state algorithm to determine routes to network destinations.
Page 108 DGS-3312SR Gigabit Layer 3 Switch As an example, the cost of a 10 Mbps Ethernet line will be 10 and the cost to cross a 1.544 Mbps T1 line will be 64. Shortest Path Tree To build Router A’s shortest path tree for the network diagramed below, Router A is put at the root of the tree and the smallest cost link to each destination network is calculated.
Page 109 DGS-3312SR Gigabit Layer 3 Switch through Router C. This higher-cost route will not be included in the Router A’s shortest path tree. The resulting tree will look like this: Router A 128.213.0.0 Router B Router C 192.213.11.0 222.211.10.0 Figure 5- 7. Constructing a Shortest Path Tree - Completed Note that this shortest path tree is only from the viewpoint of Router A.
Page 110: Ospf Authentication
DGS-3312SR Gigabit Layer 3 Switch The format of these link-state updates is described in more detail below. Router link-state updates are flooded to all routers in the current area. These updates describe the destinations reachable through all of the router’s interfaces.
Page 111: Designated Router Election
DGS-3312SR Gigabit Layer 3 Switch redundancy to protect against a router failure. A virtual link is configured between two border routers that both have a connection to their respective area 0s. Neighbors Routers that are connected to the same area or segment become neighbors in that area. Neighbors are elected via the Hello protocol.
Page 112: Ospf Packet Formats
DGS-3312SR Gigabit Layer 3 Switch • Exchange − Routers will describe their entire link-state database by sending database description packets. • Loading − The routers are finalizing the information exchange. Routers have link-state request list and a link-state retransmission list. Any information that looks incomplete or outdated will be put on the request list.
Page 113 DGS-3312SR Gigabit Layer 3 Switch Hello Database Description Link-State Request Link-State Update Link-State Acknowledgment Packet Length The length of the packet in bytes. This length includes the 24-byte header. Router ID The Router ID of the packet’s source. A 32-bit number identifying the area that this packet belongs to. All Area ID OSPF packets are associated with a single area.
Page 114 DGS-3312SR Gigabit Layer 3 Switch Figure 5- 9. Hello Packet Field Description Network Mask The network mask associated with this interface. Options The optional capabilities supported by the router. Hello Interval The number of seconds between this router’s Hello packets.
Page 115 DGS-3312SR Gigabit Layer 3 Switch Field Description Options The optional capabilities supported by the router. I – bit The Initial bit. When set to 1, this packet is the first in the sequence of Database Description packets. M – bit The More bit.
Page 116 DGS-3312SR Gigabit Layer 3 Switch Link-State Update Packet Link-State Update packets are OSPF packet type 4. These packets implement the flooding of link-state advertisements. Each Link-State Update packet carries a collection of link-state advertisements one hop further from its origin. Several link-state advertisements may be included in a single packet.
Page 117 DGS-3312SR Gigabit Layer 3 Switch Link-State Acknowledgment Packet Packet Length Version No. Router ID Area ID Checksum Authentication Type Authentication Authentication Link-State Advertisement Header ... Figure 5- 13. Link-State Acknowledgment Packet Each acknowledged link-state advertisement is described by its link-state advertisement header. It contains all the information required to uniquely identify both the advertisement and the advertisement’s current instance.
Page 118 DGS-3312SR Gigabit Layer 3 Switch Link-State Advertisement Header Link-State Age Options Link-State Type Link-State ID Advertising Router Link-State Sequence Number Link-State Checksum Length Figure 5- 14. Link-State Advertisement Header Field Description The time is seconds since the link state advertisement was Link State Age originated.
Page 119 DGS-3312SR Gigabit Layer 3 Switch Router Links Advertisements Router links advertisements are type 1 link state advertisements. Each router in an area originates a routers links advertisement. The advertisement describes the state and cost of the router’s links to the area. All of the router’s links to the area must be described in a single router links advertisement.
Page 120 DGS-3312SR Gigabit Layer 3 Switch Field Description A quick classification of the router link. One of the following: Type Description Point-to-point connection to another router. Type Connection to a transit network. Connection to a stub network. Virtual link. Identifies the object that this router link connects to. Value depends on the link’s Type.
Page 121 DGS-3312SR Gigabit Layer 3 Switch The distance form the network to all attached routers is zero, for all TOS. This is why the TOS and metric fields need not be specified in the network links advertisement. The format of the Network Links Advertisement is shown below:...
Page 122 DGS-3312SR Gigabit Layer 3 Switch Separate costs may be advertised for each IP Type of Service. Note that the cost for TOS 0 must be included, and is always listed first. If the T-bit is reset in the advertisement’s Option field, only a route for TOS 0 is described by the advertisement.
Page 123: Md5 Key Settings
DGS-3312SR Gigabit Layer 3 Switch be forwarded instead to the advertisement’s originator. The Type of Service that the following cost is relevant to. Metric The cost of this route. The interpretation of this metric depends on the external type indication (the E – bit above).
Page 124: Route Redistribution Settings
This information is then exchanged among the various routers according to the individual routers current routing protocol. The DGS-3312SR can redistribute routing information between the OSPF and RIP routing protocols to all routers on the network that are running OSPF or RIP. Routing information entered into the Static Routing Table on the local DGS-3312SRs Switch is also redistributed.
Page 125: Static/Default Route Settings
DGS-3312SR Gigabit Layer 3 Switch and the new redistribution setting appears listed in the table. To eliminate an existing redistribution configuration, click the X in the Delete column for the configuration being removed. Refer to the table below for descriptions of the Router Redistribution Settings window settings:...
Page 126: Static Arp Settings
DGS-3312SR Gigabit Layer 3 Switch Parameter Description IP Address <0.0.0.0> Allows the entry of an IP address that will be a static entry into the Switch’s Routing Table. Subnet Mask <0.0.0.0> Allows the entry of a subnet mask corresponding to the IP address above.
Page 127: Rip Interface Settings
DGS-3312SR Gigabit Layer 3 Switch Figure 5- 26. RIP Global Setting window RIP Interface Settings RIP settings are configured for each IP interface on the Switch. Click the RIP Interface Settings link in the RIP sub- folder. The window appears in table form listing settings for IP interfaces currently on the Switch. To configure RIP settings for an individual interface, click on the hyperlinked name of the interface.
Page 128: Ospf
DGS-3312SR Gigabit Layer 3 Switch Toggle among Disabled, V1 Only, V2 Only, and V1 and V2. This entry specifies RX Mode <Disabled> which version of the RIP protocol will be used to interpret received RIP packets. Disabled prevents the reception of RIP packets.
Page 129 DGS-3312SR Gigabit Layer 3 Switch stub areas do not allow the LSDB advertisement of external routes. Stub areas use a default summary external route (0.0.0.0 or Area 0) to reach external destinations. To set up an OSPF Area configuration click the OSPF Area Settings link to open the following window: Figure 5- 30.
Page 130: Ospf Interface Settings
DGS-3312SR Gigabit Layer 3 Switch Default Cost Displays the default cost for the route to the stub of between 0 and 65,535. The default is 0. OSPF Interface Settings To set up OSPF interfaces, click the OSPF Interface Settings link to view OSPF settings for existing IP interfaces. If there are no IP interfaces configured (besides the default System interface), only the System interface settings will appear listed.
Page 131: Ospf Virtual Interface Settings
DGS-3312SR Gigabit Layer 3 Switch Some OSPF interface settings require previously configured OSPF settings. Read the descriptions below for details. Parameter Description Interface Name Displays the of an IP interface previously configured on the Switch. Area ID Allows the entry of an OSPF Area ID configured above.
Page 132 DGS-3312SR Gigabit Layer 3 Switch The status of the virtual interface appears (Up or Down) in the Status column. Figure 5- 35. OSPF Virtual Interface Settings – Add window Configure the following parameters if you are adding or changing an OSPF Virtual Interface:...
Page 133: Ospf Area Aggregation Settings
DGS-3312SR Gigabit Layer 3 Switch OSPF Area Aggregation Settings Area Aggregation allows all of the routing information that may be contained within an area to be aggregated into a summary LSDB advertisement of just the network address and subnet mask. This allows for a reduction in the volume of LSDB advertisement traffic as well as a reduction in the memory overhead in the Switch used to maintain routing tables.
Page 134: Ospf Host Route Settings
DGS-3312SR Gigabit Layer 3 Switch OSPF Host Route Settings OSPF host routes work in a way analogous to RIP, only this is used to share OSPF information with other OSPF routers. This is used to work around problems that might prevent OSPF information sharing between routers.
Page 135: Dhcp/Bootp Relay Information
DGS-3312SR Gigabit Layer 3 Switch DHCP/Bootp Relay Information Figure 5- 40. DHCP/Bootp Relay Information window This window is used to enable BOOTP Relay and configure hops and time limit. Set the relay configuration as desired and click on the Apply button. These settings will be applied to all BOOTP/DHCP relays regardless of the destination or source.
Page 136: Dns Relay Information
DGS-3312SR Gigabit Layer 3 Switch DNS Relay Information Figure 5- 42. DNS Relay Information window The DNS Relay Information window is used to enable DNS Relay and configure IP addresses for available DNS servers. Set the relay configuration as desired and click on the Apply button.
Page 137: Vrrp
DGS-3312SR Gigabit Layer 3 Switch Parameter Description Domain Name The domain name used for the static entry. IP Address The IP address associated with the domain name. VRRP Virtual Routing Redundancy Protocol (VRRP) is a function on the Switch that dynamically assigns responsibility for a virtual router to one of the VRRP routers on a LAN.
Page 138 DGS-3312SR Gigabit Layer 3 Switch Figure 5- 45. VRRP Interface Table window This window displays VRRP entries currently set on the Switch and holds the following information: Parameter Description Interface Name An IP interface name that has been enabled for VRRP. This entry must have been previously set in the IP Interface Settings window.
Page 139 DGS-3312SR Gigabit Layer 3 Switch VRRP Interface Settings Figure 5- 46. VRRP Interface Settings window The following parameters may be set to configure an existing or new VRRP interface. Parameter Description Interface Name Enter the name of a previously configured IP interface to create a VRRP entry for.
Page 140 DGS-3312SR Gigabit Layer 3 Switch router. A True entry, along with having the backup router’s priority set higher than the masters priority, will set the backup router as the Master router. A False entry will disable the backup router from becoming the Master router. This setting must be consistent with all routers participating within the same VRRP group.
Page 141 DGS-3312SR Gigabit Layer 3 Switch Figure 5- 47. VRRP Interface Entry Display window This window displays the following information: Parameter Description Interface Name An IP interface name that has been enabled for VRRP. This entry must have been previously set in the IP Interface Settings window.
Page 142: Ip Multicast
DGS-3312SR Gigabit Layer 3 Switch enabled and Down if the virtual router is disabled. Priority Displays the priority of the virtual router. A higher priority will increase the probability that this router will become the Master router of the group. A lower priority will increase the probability that this router will become the backup router.
Page 143: Igmp Interface Configuration
DGS-3312SR Gigabit Layer 3 Switch IGMP Interface Configuration Figure 5- 49. IGMP Interface Configuration window Configure IGMP settings for each IP interface and click on the Apply button to apply the new or changed settings. The new values will appear in the IGMP Interface Table. To view the table click Show All IGMP Interface Entries.
Page 144: Dvmrp
DGS-3312SR Gigabit Layer 3 Switch DVMRP For a description of how Distance Vector Multicast Routing Protocol (DVMRP) works, please read Appendix C. The DVMRP settings links are located in the DVMRP subfolder located in the Layer 3 IP Networking configuration folder.
Page 145: Pim
DGS-3312SR Gigabit Layer 3 Switch Parameter Description Interface Name<System> Displays the name of the IP interface for which DVMRP is to be configured. This must be a previously defined IP interface. IP Address Displays the IP address corresponding to the IP Interface name entered above.
Page 146 DGS-3312SR Gigabit Layer 3 Switch Figure 5- 55. 2 PIM-DM Interface Settings window Configure PIM-DM settings for each IP interface and click on the Apply button to apply the new or changed settings. The new values will appear in the 1 PIM-DM Interface Settings window.
Page 147: Security
DGS-3312SR Gigabit Layer 3 Switch Section 6 Security Trusted Host Secure Socket Layer (SSL) Download Certificate Configuration Secure Shell (SSH) SSH Configuration SSH Algorithm SSH User Authentication Access Authentication Control Policy and Parameters Application Authentication Settings Authentication Server Group Authentication Server Host...
Page 148: Secure Socket Layer (Ssl)
DGS-3312SR Gigabit Layer 3 Switch Parameter Description Enter the IP address of a management station that will be used to manage the IP1 Access to Switch Switch. This IP address must be on the same subnet as the Switch. Enter the IP address of a management station that will be used to manage the IP2 Access to Switch Switch.
Page 149: Configuration
DGS-3312SR Gigabit Layer 3 Switch Figure 6- 2. Download Certificate window To download certificates, set the following parameters and click Apply. Parameter Description Server IP Enter the IP address of the TFTP server where the certificate files are located. Certificate File Name Enter the path and the filename of the certificate file to download.
Page 150: Secure Shell (Ssh)
Switch and need to be configured using the command line interface. For more information on SSL and its functions, see the DGS-3312SR Command Line Reference Manual, located on the documentation CD of this product. NOTE: Enabling the SSL command will disable the web-based switch management.
Page 151: Ssh Configuration
DGS-3312SR Gigabit Layer 3 Switch choices as to the method SSH will use to authorize the user, and they are Host Based, Password, Public Key, and None. 3. Configure the encryption algorithm that SSH will use to encrypt and decrypt messages sent between the SSH Client and the SSH Server, using the SSH Algorithm window.
Page 152: Ssh Algorithm
DGS-3312SR Gigabit Layer 3 Switch Auth. Fail(2-20) Allows the administrator to set the maximum number of attempts that a user may try to log on to the SSH Server utilizing SSH authentication. After the maximum number of attempts is exceeded, the Switch will be disconnected and the user must reconnect to the Switch to attempt another login.
Page 153 DGS-3312SR Gigabit Layer 3 Switch The user may set the following parameters: Parameter Description Encryption Algorithm 3DES-CBC Use the pull-down menu to enable or disable the Triple_Data Encryption Standard encryption algorithm with Cipher Block Chaining. The default is Enabled. Blow-fish CBC Use the pull-down menu to enable or disable the Blowfish encryption algorithm with Cipher Block Chaining.
Page 154: Ssh User Authentication
DGS-3312SR Gigabit Layer 3 Switch Password This parameter may be enabled if the administrator wishes to use a locally configured password for authentication on the switch. The default is Enabled. This parameter may be enabled if the administrator wishes to use a publickey Public Key configuration set on a SSH server, for authentication.
Page 155: Access Authentication Control
DGS-3312SR Gigabit Layer 3 Switch switch will prompt the user for a password, and then to retype the password for confirmation. Public Key – This parameter should be chosen if the user wishes to use the public key on a SSH server for authentication.
Page 156: Policy & Parameters
DGS-3312SR Gigabit Layer 3 Switch authentication is made, the second server host in the list will be queried, and so on. The built-in Authentication Server Groups can only have hosts that are running the specified protocol. For example, the TACACS Authentication Server Groups can only have TACACS Authentication Server Hosts.
Page 157: Application Authentication Settings
DGS-3312SR Gigabit Layer 3 Switch Application Authentication Settings This window is used to configure switch configuration applications (console, Telnet, SSH, and web) for login at the user level and at the administration level (Enable Admin) utilizing a previously configured method list.
Page 158: Authentication Server Host
DGS-3312SR Gigabit Layer 3 Switch Figure 6- 10. Authentication Server Group Settings window This window displays the Authentication Server Groups on the Switch. The Switch has four built-in Authentication Server Groups that cannot be removed but can be modified. To modify a particular group, click its hyperlinked Group Name, which will then display the following window.
Page 159 DGS-3312SR Gigabit Layer 3 Switch that RADIUS/TACACS/TACACS+/XTACACS are separate entities and are not compatible with each other. The maximum supported number of server hosts is 16. To view the following window, click Security > Access Authentication Control > Authentication Server Host: Figure 6- 12.
Page 160: Login Method Lists
DGS-3312SR Gigabit Layer 3 Switch authentication request. The default value is 5 seconds. Retransmit(1-255) Enter the value in the retransmit field to change how many times the device will resend an authentication request when the TACACS/RADIUS server does not respond.
Page 161 DGS-3312SR Gigabit Layer 3 Switch Figure 6- 15. Login Method List – Add window Figure 6- 16. Login Method List – Edit window To define a Login Method List, set the following parameters and click Apply: Parameter Description Method List Name Enter a method list name defined by the user of up to 15 characters.
Page 162: Enable Method Lists
DGS-3312SR Gigabit Layer 3 Switch Enable Method Lists This window is used to set up Method Lists to promote users with normal level privileges to Administrator level privileges using authentication methods on the Switch. Once a user acquires normal user level privileges on the Switch, he or she must be authenticated by a method on the Switch to gain administrator privileges on the Switch, which is defined by the Administrator.
Page 163: Local Enable Password
DGS-3312SR Gigabit Layer 3 Switch Figure 6- 19. Enable Method List – Edit window To define an Enable Login Method List, set the following parameters and click Apply: Parameter Description Enter a method list name defined by the user of up to 15 characters.
Page 164: Enable Admin
DGS-3312SR Gigabit Layer 3 Switch To set the Local Enable Password, set the following parameters and click Apply. Parameter Description Old Local Enable If a password was previously configured for this entry, enter it here in order to change it to a new password...
Page 165 DGS-3312SR Gigabit Layer 3 Switch Figure 6- 22. Enter Network Password dialog box...
Page 166: Management
DGS-3312SR Gigabit Layer 3 Switch Section 7 Management User Accounts SNMPV3 SNMP User Table SNMP View Table SNMP Group Table SNMP Community Table SNMP Host Table SNMP Engine ID User Accounts Use the User Account Management to control user privileges. To view existing User Accounts, open the Management folder and click on the User Accounts link.
Page 167: Snmpv3
SNMP version used for specific tasks. The DGS-3312SR supports the Simple Network Management Protocol (SNMP) versions 1, 2c, and 3. The SNMP version used to monitor and control the Switch can be specified by the administrator. The three versions of SNMP vary in the level...
Page 168: Snmp User Table
DGS-3312SR Gigabit Layer 3 Switch SNMP settings are configured using the windows located on the SNMP V3 folder of the web manager. Workstations on the network that are allowed SNMP privileged access to the Switch can be restricted with the Security IP Management window (located in the Security folder under Trusted Host).
Page 169 DGS-3312SR Gigabit Layer 3 Switch MD5 − Indicates that the HMAC-MD5-96 authentication level will be used. SHA − Indicates that the HMAC-SHA authentication protocol will be used None − Indicates that no authorization protocol is in use. Priv-Protocol DES − Indicates that DES 56-bit encryption is in use based on the CBC-DES (DES- 56) standard.
Page 170: Snmp View Table
DGS-3312SR Gigabit Layer 3 Switch SNMP View Table The SNMP View Table is used to assign views to community strings that define which MIB objects can be accessed by a remote SNMP manager. Figure 7- 7. SNMP View Table window To delete an existing SNMP View Table entry, click the X button listed under Delete on the far left that corresponds to View Name.
Page 171: Snmp Group Table
DGS-3312SR Gigabit Layer 3 Switch View Type Select Included to include this object in the list of objects that an SNMP manager can access. Select Excluded to exclude this object from the list of objects that an SNMP manager can access.
Page 172: Snmp Community Table
DGS-3312SR Gigabit Layer 3 Switch SNMP Group Table Configuration Figure 7- 11. SNMP Group Table Configuration window The following parameters can be set: Parameter Description Group Name Type an alphanumeric string of up to 32 characters. This is used to identify the new SNMP group of SNMP users.
Page 173: Snmp Host Table
DGS-3312SR Gigabit Layer 3 Switch An Access List of IP addresses of SNMP managers that are permitted to use the community string to gain access to the Switch’s SNMP agent. An MIB view that defines the subset of all MIB objects that will be accessible to the SNMP community.
Page 174: Snmp Engine Id
DGS-3312SR Gigabit Layer 3 Switch To display the current settings for an existing SNMP Group Table entry, click the blue link for the entry under the Host IP Address heading. Figure 7- 13. SNMP Host Table window To add a new entry to the Switch’s SNMP Group Table, click the Add button in the upper left-hand corner of the SNMP Host Table window.
Page 175 DGS-3312SR Gigabit Layer 3 Switch To display the Switch’s SNMP Engine ID, open the Management folder, and then the SNMPV3 folder. Finally, click on the SNMP Engine ID link. This will open the SNMP Engine ID Configuration window, as shown below.
Page 176: Monitoring
DGS-3312SR Gigabit Layer 3 Switch Section 8 Monitoring Stack Information Port Utilization CPU Utilization Packets Received (RX) UMB_cast (RX) Transmitted (TX) Errors Received (RX) Transmitted (TX) Size Packet Size MAC Address Switch History IGMP Snooping Browse Router Port VLAN Status...
Page 177: Stack Information
Stack Information The DGS-3312SR Switch can be used as a standalone high-capacity Switch or be used in a stacked arrangement. There are two hardware requirements to use the Switch in a stacked group: 1. The proper module(s) must be installed. One or two DEM-540 Stacking modules must be installed in order to use the Switch in a stacked configuration.
Page 178 The current order in the Switch stack is also displayed on the front panel of each slave Switch, under the STACK NO. heading. The Stack ID LED display on the front panel of the DGS-3312SR will always display an F (15 in hex), regardless of whether the DGS-3312SR is the master Switch in a Switch stack or in standalone mode.
Page 179: Port Utilization
DGS-3312SR Gigabit Layer 3 Switch Figure 8- 3. Stack Information web page Port Utilization The Port Utilization window displays the percentage of the total available bandwidth being used on the port. To view the port utilization, click on the Monitoring folder and then the Port Utilization link:...
Page 180 DGS-3312SR Gigabit Layer 3 Switch Figure 8- 4. Utilization window The following field can be set: Parameter Description Allows you to specify a Switch in a Switch stack using that Switch’s Unit ID. The Unit number 15 indicates a Switch in standalone mode.
Page 181: Cpu Utilization
DGS-3312SR Gigabit Layer 3 Switch CPU Utilization This CPU Utilization window displays the moving average of the CPU. To view the CPU utilization, click on the Monitoring folder and then the CPU Utilization link: Figure 8- 5. CPU Utilization window...
Page 182: Received Packets
DGS-3312SR Gigabit Layer 3 Switch Received Packets Figure 8- 6. Rx Packets Analysis (line graph for Bytes & Packets) window...
Page 183 DGS-3312SR Gigabit Layer 3 Switch Figure 8- 7. Rx Packets Analysis (table for Bytes & Packets) window Select the desired Switch using the Unit drop-down menu and the desired port using the Port drop-down menu. The Time Interval field sets the interval at which the error statistics are updated.
Page 184: Received Unicast/Multicast/Broadcast Packets
DGS-3312SR Gigabit Layer 3 Switch Received Unicast/Multicast/Broadcast Packets Figure 8- 8. Rx Packets Analysis (line graph for Unicast, Multicast, & Broadcast) window...
Page 185 DGS-3312SR Gigabit Layer 3 Switch Figure 8- 9. Rx Packets Analysis (table for Unicast, Multicast, & Broadcast) window Select the desired Switch using the Unit drop-down menu and the desired port using the Port drop-down menu. The Time Interval field sets the interval at which the error statistics are updated.
Page 186: Transmitted Packets
DGS-3312SR Gigabit Layer 3 Switch Show/Hide Check whether or not to display Multicast, Broadcast, and Unicast Packets. Transmitted Packets Figure 8- 10. Tx Packets Analysis (line graph for Bytes & Packets) window...
Page 187 DGS-3312SR Gigabit Layer 3 Switch Figure 8- 11. Tx Packets Analysis (table for Bytes & Packets) window Select the desired Switch using the Unit drop-down menu and the desired port using the Port drop-down menu. The Time Interval field sets the interval at which the error statistics are updated.
Page 188: Errors
DGS-3312SR Gigabit Layer 3 Switch Errors Various statistics can be viewed as either a line graph or a table: • Received Errors • Transmitted Errors Received Errors Figure 8- 12. Rx Error Analysis (line graph) window...
Page 189 DGS-3312SR Gigabit Layer 3 Switch Figure 8- 13. Rx Error Analysis (table) window Select the desired Switch using the Unit drop-down menu and the desired port using the Port drop-down menu. The Time Interval field sets the interval at which the error statistics are updated.
Page 190: Transmitted Errors
DGS-3312SR Gigabit Layer 3 Switch MAX_PKT_LEN is equal to 1522. Drop The number of frames that are dropped by this port since the last Switch reboot. Time Interval <1s> The time between updates received from the Switch, in seconds. The default is 1s.
Page 191 DGS-3312SR Gigabit Layer 3 Switch Figure 8- 15. Tx Error Analysis (table) window Select the desired Switch using the Unit drop-down menu and the desired port using the Port drop-down menu. The Time Interval field sets the interval at which the error statistics are updated.
Page 192: Size
DGS-3312SR Gigabit Layer 3 Switch Record Number Select number of times the Switch will be polled between 20 and 200. The default <200> value is 200. Show/Hide Check whether to display ExDefer, LateColl, ExColl, SingColl, and Coll errors. Size Various statistics can be viewed as either a line graph or a table: •...
Page 193 DGS-3312SR Gigabit Layer 3 Switch Figure 8- 17. Packet Size Analysis (table) window Select the desired Switch using the Unit drop-down menu and the desired port using the Port drop-down menu. The Time Interval field sets the interval at which the error statistics are updated.
Page 194: Mac Address
DGS-3312SR Gigabit Layer 3 Switch 1024-1518 The total number of packets (including bad packets) received that were between 1024 and 1518 octets in length inclusive (excluding framing bits but including FCS octets). Time Interval <1s> The time between updates received from the Switch, in seconds. The default is 1s.
Page 195 DGS-3312SR Gigabit Layer 3 Switch Figure 8- 18. MAC Address Table window The following fields can be set: Parameter Description VLAN ID Allows you to enter a VLAN ID. MAC Address Allows you to specify a MAC Address. Enter the desired switch unit and port number.
Page 196: Switch History
DGS-3312SR Gigabit Layer 3 Switch Switch History The Switch History window displays the Switch’s history log, as compiled by the Switch’s management agent. Figure 8- 19. Switch History window The Switch can record event information in its own logs, to designated SNMP trap receiving stations, and to the PC connected to the console manager.
Page 197: Igmp Snooping Table
DGS-3312SR Gigabit Layer 3 Switch IGMP Snooping Table This allows the Switch’s IGMP Snooping table to be viewed. IGMP Snooping allows the Switch to read the Multicast Group IP address and the corresponding MAC address from IGMP packets that pass through the Switch. The number of IGMP reports that were snooped is also displayed in the Reports field.
Page 198: Vlan Status
DGS-3312SR Gigabit Layer 3 Switch Figure 8- 21. Browse Router Port window VLAN Status This window displays the status of VLANs on any Switch in a Switch stack managed by a DGS-3312SR.
Page 199: Session Table
DGS-3312SR Gigabit Layer 3 Switch Figure 8- 22. VLAN Status window Session Table This window displays the management sessions since the Switch was last rebooted. Figure 8- 23. Current Session Table window...
Page 200: Layer 3 Feature
DGS-3312SR Gigabit Layer 3 Switch Layer 3 Feature The Switch’s Layer 3 monitoring windows are described below. Browse IP Address The IP Address Table window may be found in the Monitoring folder in the Layer 3 Feature sub-folder. This window allows the user to view IP addresses discovered by the Switch.
Page 201: Browse Arp Table
DGS-3312SR Gigabit Layer 3 Switch Figure 8- 25. Routing Table window Browse ARP Table The ARP Table window may be found in the Monitoring folder in the Layer 3 Feature sub-folder. This window will show current ARP entries on the Switch. To search a specific ARP entry, enter an interface name into the Interface Name...
Page 202: Browse Ip Multicast Forwarding Table
DGS-3312SR Gigabit Layer 3 Switch Figure 8- 26. ARP Table window Browse IP Multicast Forwarding Table The Browse IP Multicast Forwarding Table window may be found in the Monitoring folder in the Layer 3 Feature sub-folder. This window will show current IP multicasting information on the Switch. To search a specific entry, enter an...
Page 203: Browse Igmp Group Table
DGS-3312SR Gigabit Layer 3 Switch Figure 8- 27. IP Multicast Forwarding Table window Browse IGMP Group Table The IGMP Group Table window may be found in the Monitoring folder in the Layer 3 Feature sub-folder. This window will show current IGMP group entries on the Switch. To search a specific IGMP group entry, enter an interface name into the Interface Name field or a Multicast Group IP address and click Find.
Page 204: Browse Ospf Neighbor Table
DGS-3312SR Gigabit Layer 3 Switch To browse the OSPF LSDB Table, you first must select which browse method you want to use. The choices are Area ID, Advertise Router ID, LSDB, Area ID & Advertise Router ID, Area ID & LSDB, Advertise Router ID & LSDB, and ALL.
Page 205: Browse Ospf Virtual Neighbor Table
DGS-3312SR Gigabit Layer 3 Switch themselves listed in a Hello packet sent by another router on the same segment. In this way, two-way communication is guaranteed to be possible between any two neighbor routers. This table displays OSPF neighbors of the Switch.
Page 206: Browse Dvmrp Neighbor Address Table
DGS-3312SR Gigabit Layer 3 Switch Figure 8- 32. DVMRP Routing Table window Browse DVMRP Neighbor Address Table This table, found in the Monitoring folder, in the Layer 3 Feature sub-folder, under DVMRP Monitor contains information about DVMRP neighbors of the Switch. You may define your search by entering an Interface Name and Neighbor Address in the fields at the top of the window and clicking Find.
Page 207: Browse Pim Neighbor Address Table
DGS-3312SR Gigabit Layer 3 Switch Browse PIM Neighbor Address Table This window contains information regarding each of a router’s PIM neighbors. This window may be found in the Monitoring folder, in the Layer 3 Feature sub-folder, under the heading PIM Monitor. You may define your search by entering an Interface Name and Neighbor Address in the fields at the top of the window and clicking Find.
Page 208: Maintenance
DGS-3312SR Gigabit Layer 3 Switch Section 9 Maintenance TFTP Services Download Firmware Download Configuration File Save Settings Save History Log PING Test Save Changes Factory Reset Restart System Logout TFTP Services Trivial File Transfer Protocol (TFTP) services allow the Switch firmware to be upgraded by transferring a new firmware file from a TFTP server to the Switch.
Page 209: Download Configuration File
DGS-3312SR Gigabit Layer 3 Switch Download Configuration File To download a configuration file from a TFTP server, click on the Maintenance folder and then the TFTP Service folder and then the Download Configuration File link: Figure 9- 2. Use Configuration File on Server window Enter the IP address of the TFTP server and specify the location of the Switch configuration file on the TFTP server.
Page 210: Save Changes
Save Changes The DGS-3312SR has two levels of memory; normal RAM and non-volatile or NV-RAM. Configuration changes are made effective clicking the Apply button. When this is done, the settings will be immediately applied to the Switching software in RAM, and will immediately take effect.
Page 211: Restart System
DGS-3312SR Gigabit Layer 3 Switch Reset gives the option of retaining the Switch’s User Accounts and History Log while resetting all other configuration parameters to their factory defaults. If the Switch is reset with this option enabled, and Save Changes is not executed, the Switch will return to the last saved configuration when rebooted.
Page 212: Logout
DGS-3312SR Gigabit Layer 3 Switch Figure 9- 8. Restart System window Logout Use this window to logout of the Switch’s Web-based management agent by clicking on the Log Out button. Figure 9- 9. Logout Web Setups window...
Page 213: Single Ip Management
SIM allows intermediate devices that do not support SIM. This enables the user to manage a switch that is more than one hop away from the CS. The SIM group is a group of switches that are managed as a single entity. The DGS-3312SR may take on three different roles: →...
Page 214: Sim Settings
→ The CaS can be configured through the CS to become a MS. After configuring one switch to operate as the CS of a SIM group, additional DGS-3312SR switches may join the group either by an automatic method or by manually configuring the switch to be a MS. The CS will then serve as the in band entry point for access to the MS.
Page 215: Topology
DGS-3312SR Gigabit Layer 3 Switch Figure 10- 2. SIM Settings window (enabled) The following parameters can be set: Parameters Description SIM State Use the pull down menu to either enable or disable the SIM state on the Switch. Dis- abled will render all SIM functions on the Switch inoperable.
Page 216 DGS-3312SR Gigabit Layer 3 Switch Clicking the here link will setup the Java Runtime Environment on your server and lead you to the topology window, as seen below. Figure 10- 4. Single IP Management window-Tree View The Tree View window holds the following information under the Data tab:...
Page 217 DGS-3312SR Gigabit Layer 3 Switch Figure 10- 5. Topology view This screen will display how the devices within the Single IP Management Group are connected to other groups and devices. Possible icons in this screen are as follows: Icon Description...
Page 218: Tool Tips
DGS-3312SR Gigabit Layer 3 Switch Layer 2 candidate switch Layer 3 candidate switch Unknown device Non-SIM devices Tool Tips In the Topology view window, the mouse plays an important role in configuration and in viewing device information. Setting the mouse cursor over a specific device in the topology window (tool tip) will display the same information about a specific device as the Tree view does.
Page 219: Right-Click
DGS-3312SR Gigabit Layer 3 Switch Figure 10- 7. Port Speed Utilizing the Tool Tip Right-click Right clicking on a device will allow the user to perform various functions, depending on the role of the Switch in the SIM group and the icon associated with it.
Page 220: Commander Switch Icon
DGS-3312SR Gigabit Layer 3 Switch Figure 10- 9. Property dialog box Commander Switch Icon Figure 10- 10. Right-clicking a Commander Icon The following options may appear for the user to configure: Collapse - to collapse the group that will be represented by a single icon.
Page 221: Member Switch Icon
DGS-3312SR Gigabit Layer 3 Switch Figure 10- 11. Property dialog box Member Switch Icon Figure 10- 12. Right-clicking a Member icon The following options may appear for the user to configure: Collapse - to collapse the group that will be represented by a single icon.
Page 222: Candidate Switch Icon
DGS-3312SR Gigabit Layer 3 Switch Figure 10- 13. Property window Candidate Switch Icon Figure 10- 14. Right-clicking a Candidate icon The following options may appear for the user to configure: Collapse - to collapse the group that will be represented by a single icon.
Page 223: Menu Bar
DGS-3312SR Gigabit Layer 3 Switch Figure 10- 16. Device Property dialog box This window holds the following information: Parameter Description Device Name This field will display the Device Name of the switches in the SIM group configured by the user. If no Device Name is configured by the name, it will be given the name default and tagged with the last six digits of the MAC Address to identify it.
Page 224: Group
Figure 10- 19. About window NOTE: Upon this firmware release, some functions of the SIM can only be configured through the Command Line Interface. See the DGS-3312SR Command Line Interface Reference Manual for more information on SIM and its configurations.
Page 225: Configuration File Backup/Restore
DGS-3312SR Gigabit Layer 3 Switch Figure 10- 20. Firmware Upgrade window Configuration File Backup/Restore This screen is used to upgrade configuration files from the Commander Switch to the Member Switch. Member Switches will be listed in the table and will be specified by Port (port on the CS where the MS resides), MAC Address, Model Name and Version.
Page 226: Technical Specifications
DGS-3312SR Gigabit Layer 3 Switch Appendix A Technical Specifications General Standard IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3ab 1000BASE-T Gigabit Ethernet IEEE 802.1 P/Q VLAN IEEE 802.3x Full-duplex Flow Control IEEE 802.3 Nway auto-negotiation CSMA/CD Protocols...
Page 227 DGS-3312SR Gigabit Layer 3 Switch Automatic update. MAC Address Learning: Forwarding Table Age Max age: 10 - 1000000 seconds. Time: Default = 300. Physical & Environmental AC inputs: 100 - 240 VAC, 50/60 Hz (internal universal power supply) Power Consumption:...
Page 228 DGS-3312SR Gigabit Layer 3 Switch...
Page 229: Cables And Connectors
DGS-3312SR Gigabit Layer 3 Switch Appendix B Cables and Connectors When connecting the Switch to another switch, a bridge or hub, a normal cable is necessary. Please review these products for matching cable pin assignment. The following diagrams and tables show the standard RJ-45 receptacle/connector and their pin assignments.
Page 230: Cable Lengths
DGS-3312SR Gigabit Layer 3 Switch Appendix C Cable Lengths Use the following table to as a guide for the maximum cable lengths. Standard Media Type Maximum Distance Mini-GBIC 1000BASE-LX, Single-mode fiber module 10km 1000BASE-SX, Multi-mode fiber module 550m 1000BASE-LHX, Single-mode fiber module...
Page 231 DGS-3312SR Gigabit Layer 3 Switch Glossary 1000BASE-LX: A short laser wavelength on multimode fiber optic cable for a maximum length of 550 meters 1000BASE-SX: A long wavelength for a "long haul" fiber optic cable for a maximum length of 10 kilometers 100BASE-FX: 100Mbps Ethernet implementation over fiber.
Page 232 DGS-3312SR Gigabit Layer 3 Switch IP address: Internet Protocol address. A unique identifier for a device attached to a network using TCP/IP. The address is written as four octets separated with full-stops (periods), and is made up of a network section, an optional subnet section and a host section.
Page 233 DGS-3312SR Gigabit Layer 3 Switch UDP - User Datagram Protocol: An Internet standard protocol that allows an application program on one device to send a datagram to an application program on another device. VLAN - Virtual LAN: A group of location- and topology-independent devices that communicate as if they are on a common physical LAN.
Page 234 D-Link Canada 2180 Winston Park Drive, Oakville, Ontario, L6H 5W1 Canada TEL: 1-905-829-5033 FAX: 1-905-829-5223 URL: www.dlink.ca Chile D-Link South America (Sudamérica) Isidora Goyenechea 2934 Oficina 702 Las Condes Fono 2323185, Santiago, Chile TEL: 56-2-232-3185 FAX: 56-2-232-0923 URL: www.dlink.cl China D-Link China Room 507/508, Tower W1, The Towers, Oriental Plaza No.
Page 235 Schwalbacher Strasse 74, D-65760 Eschborn, Germany TEL: 49-6196-77990 FAX: 49-6196-7799300 URL: www.dlink.de India D-Link India D-Link House, Kurla-Bandra Complex Rd., Off Cst Rd., Santacruz (East), Mumbai, 400 098 India TEL: 91-022-652-6696/6578/6623 FAX: 91-022-652-8914/8476 URL: www.dlink.co.in & www.dlink-india.com Israel D-Link Israel 11 Hamanofim Street, Ackerstein Towers, Regus Business Center P.O.B.
Page 236 1 International Business Park, #03-12 The Synergy, Singapore 609917 TEL: 65-6774-6233 FAX: 65-6774-6322 URL: www.dlink-intl.com South Africa D-Link South Africa Einstein Park II, Block B, 102-106 Witch-Hazel Avenue Highveld Technopark, Centurion, Gauteng, Republic of South Africa TEL: 27-12-665-2165 FAX: 27-12-665-2186 URL: www.d-link.co.za...
Page 237 U.K. D-Link Europe (United Kingdom) Floor, Merit House, Edgware Road, Colindale, London NW9 5AB United Kingdom TEL: 44-020-8731-5555 FAX: 44-020-8731-5511 URL: www.dlink.co.uk U.S.A. D-Link Systems, Inc. 17595 Mt. Herrmann, Fountain Valley, CA 92708, USA TEL: 1-714-885-6000 FAX: 1-866-743-4905 URL: www.dlink.com...
Page 238: Limitation Of Liability
This Warranty applies on the condition that the product Registration Card is filled out and returned to a D-Link office within ninety (90) days of purchase. A list of D-Link offices is provided at the back of this manual, together with a copy of the Registration Card.
Page 239 A list of D-Link offices is provided at the back of this manual, together with a copy of the Registration Card. If a Registration Card for the product in question has not been returned to a D-Link office, then a proof of purchase (such as a copy of the dated purchase invoice) must be provided when requesting warranty service.
Page 240 Spare parts and spare kits Ninety (90) days D-Link’s sole obligation shall be to repair or replace the defective Hardware during the Warranty Period at no charge to the original owner or to refund at D-Link’s sole discretion. Such repair or replacement will be rendered by D-Link at an Authorized D-Link Service Office. The replacement Hardware need not be new or have an identical make, model or part.
Page 241 D-Link. The repaired or replaced packages will be shipped to the customer via UPS Ground or any common carrier selected by D-Link, with shipping charges prepaid. Expedited shipping is available if shipping charges are prepaid by the customer and upon request.
Page 242 For detailed warranty outside the United States, please contact corresponding local D-Link office. Register online your D-Link product at http://support.dlink.com/register/...
Page 243: Registration Card
8. What category best describes your company? Aerospace Engineering Education Finance Hospital Legal Insurance/Real Estate Manufacturing Retail/Chainstore/Wholesale Government Transportation/Utilities/Communication System house/company Other________________________________ 9. Would you recommend your D-Link product to a friend? Don't know yet 10.Your comments on this product? _______________________________________________________________________________________...

D-Link DGS-3312SR Product Manual

Quick Links

Related Manuals for D-Link DGS-3312SR

Summary of Contents for D-Link DGS-3312SR
