Installation Accessories The use of any accessories except for those provided might result in damage to the unit. Make sure only to use the accessories shipped with the unit, as shown above. Installation the TV Tuner Unit ■ Securing to audio board (Accessory F) (Accessory G) (Accessory E)
Page 3
Installing the Antenna Units Incar antennas have a lower reception sensitivity than antennas intended for outside mounting. The picture may not appear or may be disturbed if the signal in your area is weak. • Attach the antenna to the inner glass surface of the rear window using double-sided tape.
Page 4
Installation Connection • Make sure to ground the unit to a negative 12V DC power supply. • If your car's ignition does not come with an ACC position, connect the ignition wires to a power source that can be turned on and off with the ignition key. If you connect the ignition wire to a power source that receives a constant voltage supply, as with battery wires, the battery may die.
Specifications Specifications subject to change without notice. TV Tuner Section Color system ....................PAL Television system & Channel converge Television system PAL-B/G PAL-I PAL-D Channel converge 2 - 12ch 1A - 11ch 0 - 12ch 1-12ch UHF 21-69ch 21-69ch 28-69ch 21-69ch 13-57ch Channel selection system........PLL frequency synthesizer system Demoduration system ............Split carrier system...
