Functional Description and Specifications

Disconnect the plug from the power source before making any assembly,
WARNING
!
adjustments or changing accessories. Such preventive safety measures reduce
the risk of starting the tool accidentally.
SPEED CONTROL DIAL
Models 1617EVS
FIG. 1
& 1618EVS only
ROCKER ON\OFF SWITCH
BASE CLAMP LEVER
ROUND
HANDLE
SUB -BASE
FIG. 2
POWER ON/OFF
SWITCH
BASE TYPE D
REVERSIBLE
HANDLE
BIT ROTATION ARROW
5/20/03 9:06 AM Page 6
Routers
BIT ROTATION ARROW
AIR VENTS
-6-
AIR VENTS
MOTOR HOUSING
MOTOR ALIGNMENT ARROW
BASE TYPE S
CHIP DEFLECTOR
TEMPLET GUIDE
QUICK CHANGE LEVER
TRIGGER
SWITCH
"LOCK-ON"
BUTTON
D-HANDLE
