1.

Safety precautions

The following contents are stated on the product and the operation manual, including usage, precautions against injury and property loss, and the methods of using
the product correctly and safely. After fully understanding the following contents (identifiers and icons), read the text body and observe the following rules.
■
Identifier description
Identifier
Warning
Caution
■
Icon description
lcon Meaning
Forbidden
It indicates compulsory implementation. The compulsory subject-matter is indicated in the icon or by images or characters aside.
Warning
Delegate installation
Warning
Forbid
Usage
Forbid
Warning
2.

Overview

2.1. Instruction
WAN
Fig.2.1
WAN terminal Connect to the switch by 5 kinds of network cables to ensure that PC can access to the web page of it.
A1B1E terminal Connect to the indoor/outdoor unit
A2B2E terminal Connect to the terminal serial port.
CLIMATE 5000 VRF
Meaning
Means improper handling may lead to personal injury.
Means improper handling may lead to personal injury or property damage.
Ensure qualified personnel install and maintain the equipment.
Improper installation performed by the user without permission may cause fire, electric, shock, personal injury
or water leakage.
Do not spray flammable aerosol to it directly.
Otherwise, fire may occur.
Do not operate with wet hands or let water enter it.
Otherwise, electric shock may occur.
A1 B1 E
A2 B2 E
POWER RESET
