HVAC Solution 1.1 Solution Overview Integrated Controller Central Controller Central Controller Power Distribution Indicator Individual Controller (Large size) (Small size ) / IO Module Wired R/C ACP 5 AC Ez Touch Ethernet(LGAP) Internet Internet PACP5A000 PDI Premium PREMTA000 PQNUD1S40 (8 Port) (BACnet IP / Modbus TCP) PACEZA000 PDI Standard...
Page 5
HVAC Solution 1.2 Control System List Dimensions Controller Compatible Category Model name Feature name Product (W x H x D, mm) • 5 inch color Display PREMTA000(A/B) • Touch Screen All IDU • Group control (Max 16 indoor unit) 137 x 121 x 16.5 Premium •...
Page 6
HVAC Solution 1.2 Control System List Outline of system 1. Installation Method 12 V Please check if connector is normally connected. Signal Yellow Indoor Unit side Black Connecting cable ※ : AWG#24 ⇒ The total cable length must not exceed 50m. (It can cause communication error.) 2.
Page 7
HVAC Solution 1.2 Control System List Outline of system 4. 2 Remote Controller Control Signal Signal DC 12 V DC 12 V BK YL RD BK YL RD Master Slave ⇒ When installing more than 2 units of wired remote controller to one air conditioner, set one wired remote con- troller as master the others all as slaves.
Page 8
HVAC Solution 1.3 Nomenclature ■ Wired remote controller Model Name REMT Signification Air-con Control System and Accessory type P : Part(ACS) C : Part(ACS) for Brazil only Product type REMT : Wired remote controller Grade type A : Premium B : Standard C : Simple Tool version Serial number...
Page 9
HVAC Solution 2. Wired remote controller 2.1. Product Feature 2.1.1 Feature List 2.1.2 List of function 2.1.3 Compatibility List 2.2 Example of installing 2.3 Product Description 2.3.1 Premium 2.3.2 Standard 2.3.3 Simple...
HVAC Solution 2.1 Product Feature 2.1.1 Feature list Controller Name Premium Standard Simple Product Image PREMTA000 PREMTB100 PREMTB001 PQRCVCL0Q PQRCHCA0Q Model Name PREMTA000A PREMTBB10 PREMTBB01 PQRCVCL0QW PQRCHCA0QW PREMTA000B On / Off Fan Speed Control Temperature Setting Mode Change Auto Swing Basic Vane Control (Louver Angle) E.S.P...
HVAC Solution 2.1 Product Feature 2.1.2 List of function Category Level1 Level2 Level3 DESCRIPTION Temp setting Single set(1 set) cooling Cool the room to the desired temperature. Dehumidification It removes the moisture with cooling. Monsoon dehumidification It is a special function only for India *Only for India Heating heats the room the desired temperature.
Page 12
HVAC Solution 2.1 Product Feature Category Level1 Level2 Level3 DESCRIPTION Vane angle Adjust vane angle. Elevation grill control Up/Down/Stop Control the elevation grill installed on the product. When the product is off after cooling operation, it is the function to dry the inside of the Auto drying indoor unit to remove mold and moisture.
Page 13
HVAC Solution 2.1 Product Feature Category Level1 Level2 Level3 DESCRIPTION All lock (Child lock) It locks all button operation of the remote controller. On/Off lock It locks the On/Off button operation of the remote controller. Lock function Individual lock Mode lock This function makes it impossible to change the operation mode from the wired remote control.
Page 14
HVAC Solution 2.1 Product Feature Category Level1 Level2 (Code) Level3 (Code) DESCRIPTION You can control external devices such as lights, fans, and heaters by using the signals emitted by the remote controller. - Output specification : DC 11~12 V , Max 30 mA Mode setting On/Off/Auto On : When it is set to “On”, it always performs the contact point output...
Page 15
HVAC Solution 2.1 Product Feature Category Level1 Level2 (Code) Level3 (Code) DESCRIPTION Instantaneous power It is a function that can check the current instantaneous power consumption. Power consumption The usage amount of the connected indoor unit is compared with the power consumption or Year on year (monthly) operation time of the selected month of the previous year.
Page 16
HVAC Solution 2.1 Product Feature Category Level1 Level2 (Code) Level3 (Code) DESCRIPTION Cooling (01:01) Test run code : 01 After installing the product, it is a pilot operation to check the installation status. Heating (01:02) Central control address code : 02 It is function to set the central control address of the indoor unit when central controller is connected.
Page 17
HVAC Solution 2.1 Product Feature Category Level1 Level2 (Code) Level3 (Code) DESCRIPTION IDU address verification The result of auto addressing of the outdoor unit can be confirmed with the remote controller. code : 26 (26:xx) (Auto addressing) *xx means the address of IDU. SW version information code : 30 Check the SW version...
Page 18
HVAC Solution 2.1 Product Feature Category Level1 Level2 (Code) Level3 (Code) DESCRIPTION Advanced fanspeed Not use(51:00) It is the function to automatically change the fan speed according to the difference between code : 51 "auto" Use (51:01) the indoor temperature and the desired temperature. Trough the CN_EXT port in the IDU’s PCBA, We can control it as Digital input without Dry contact module.
Page 19
HVAC Solution 2.1 Product Feature Category Level1 Level2 (Code) Level3 (Code) DESCRIPTION Offset humidity setting It is the function to apply the offset to the humidity value detected by the remote control. Humidity offset code : 62 (62:xx)' - Set range : 10% ~ +10% (by 1%) Lamp color Auto/RGB/YGG It is a function to classify the display type of the panel.
Page 20
HVAC Solution 2.1 Product Feature 2.1.3 Compatibility list _ Function Functions Wired remote controllers Premium Standard Simple Function list PREMTB100 PREMTB001 PQRCVCL0Q/W Category Level1 Level2 Level3 PREMTA000 PREMTBB10 PREMTBB01 PQRCHCA0Q/W ● ● ● ● Temp setting Single set(1 set) ● ●...
Page 21
HVAC Solution 2.1 Product Feature Functions Wired remote controllers Premium Standard Simple Function list PREMTB100 PREMTB001 PQRCVCL0Q/W Category Level1 Level2 Level3 PREMTA000 PREMTBB10 PREMTBB01 PQRCHCA0Q/W Display remain time to ● ● ● cleaning alarm Filter alarm ● ● ● Filter alarm release ●...
Page 22
HVAC Solution 2.1 Product Feature Functions Wired remote controllers Premium Standard Simple Function list PREMTB100 PREMTB001 PQRCVCL0Q/W Category Level1 Level2 Level3 PREMTA000 PREMTBB10 PREMTBB01 PQRCHCA0Q/W Human detected indirect ● wind Human detected direct ● wind Air flow setting ● Airflow based on activity Airflow for frequently used ●...
Page 23
HVAC Solution 2.1 Product Feature Functions Wired remote controllers Premium Standard Simple Function list PREMTB100 PREMTB001 PQRCVCL0Q/W Category Level1 Level2 Level3 PREMTA000 PREMTBB10 PREMTBB01 PQRCHCA0Q/W ● ● Auto (dual set point) ● ● Override ● ● Mode setting Home Leave(Setback) ●...
Page 24
HVAC Solution 2.1 Product Feature Functions Wired remote controllers Premium Standard Simple Function list PREMTB100 PREMTB001 PQRCVCL0Q/W Category Level1 Level2 (Code) Level3 (Code) PREMTA000 PREMTBB10 PREMTBB01 PQRCHCA0Q/W Cooling (01:01) ● ● ● ● Test run code : 01 Heating (01:02) Central control ●...
Page 26
HVAC Solution 2.1 Product Feature Functions Wired remote controllers Premium Standard Simple Function list PREMTB100 PREMTB001 PQRCVCL0Q/W Category Level1 Level2 (Code) Level3 (Code) PREMTA000 PREMTBB10 PREMTBB01 PQRCHCA0Q/W 1. Mode. - Not use (56:00) - Standby (56:01) - Cool (56:02) 2. Thermal off mainte- nance time for prior- ity cooling mode -Step0 : 45 minutes...
Page 27
HVAC Solution 2.1 Product Feature Functions Wired remote controllers Premium Standard Simple Function list PREMTB100 PREMTB001 PQRCVCL0Q/W Category Level1 Level2 (Code) Level3 (Code) PREMTA000 PREMTBB10 PREMTBB01 PQRCHCA0Q/W Not use (68:00) ● ● Auto (68:01) Manual (68:02:xx) Auto ESP code : 68 Success (68:03) ●...
Page 28
HVAC Solution 2.1 Product Feature 2.1.3 Compatibility list with Multi V ◎ : Compatibility is available but more detailed functions refer to MULTI V 4series IDU features. ▲ : Need to set-up the IR Receiver product ● : Compatibility is available. X : Compatibility is unavailable.
Page 29
HVAC Solution 2.1 Product Feature 2.1.3 Compatibility list with Multi & Single IDU ▲ : Need to set-up the IR Receiver product. ● : Compatibility is available. X : Compatibility is unavailable Premium Standard Simple PREMTA000 PREMTBB10 PREMTB100 PREMTBB01 PREMTB001 PQRCVCL0Q PQRCVCL0QW PQRCHCA0Q...
Page 30
HVAC Solution 2.2 Example of installing 1. Please fix tightly using provided screw after placing remote controller setup board on the place where you like to setup. - Please set it up not to bend because poor setup could take place if setup board bends. Please set up remote controller board fit to the reclamation box if there is a reclamation box.
Page 31
HVAC Solution 2.2 Example of installing 1:N(IDU) Group Control Master Slave Slave Signal Yellow Yellow Black Signal It needs the group control cable. • Group Control cable - Model name : PZCWRCG3 - Length : 0.25m Cable : 1EA Cable : 1EA 1) Max.
Page 32
HVAC Solution 2.2 Example of installing 7) Except basic function(On/Off, Operation mode, Set temp., Fan speed) and reservation function, some of other functions may not be possible. < Restriction function when using group control > Setting for extended fuctions on group control (Installer setting code : 19) Function Not use (19:00) Use (19:01)
Page 33
HVAC Solution 2.2 Example of installing Interlocked operation : 1 IDU and 1 Ventilation Master Master Signal DC 12 V B Y R Master 1) It is possible to connect IDU and ventilation with one wired remote controller. Set IDU and Ventilation unit to Master 2) It is possible to use wireless remote controller at the same time.
Page 34
HVAC Solution HVAC Solution 2.2 Example of installing Group control and Interlocked operation : N IDU and N Ventilation Master Slave Master Slave Max. 16 EA units Master 1) It is possible to connect IDUs and ventilations with one wired remote controller. Set one indoor unit to master and others to slave.
HVAC Solution 2.3 Product Description 2.3.1 Premium n PREMTA000/PREMTA000A/PREMTA000B 1. Feature • 5 inch full color TFT LCD • Touch screen • Multi-Language Support • Temp./Humid sensing • Schedule / Timer • Group control • Indoor unit/Ventilator interlocking 120 mm 16.5 mm 2.
Page 36
HVAC Solution 2.3 Product Description 2.3.2 Standard n PREMTB100 / PREMTBB10 1. Feature • 4.3 inch full color TFT LCD • Touch button • Multi-Language Support • Temp./Humid sensing • Schedule / Timer6 • Group control • Indoor unit/Ventilator interlocking 16 mm 120 mm 2.
Page 37
HVAC Solution 2.3 Product Description n PREMTB001/PREMTBB01 1. Feature 16 mm • 4.3 inch mono display • Button • Temp. sensing • Schedule / Timer • Group control • Indoor unit/Ventilator interlocking 120 mm 19.5 mm 2. Specification Power Supply DC 12 V (From Indoor Unit) Rated Current (Max.) 0.085 A...
Page 38
HVAC Solution 2.3 Product Description 2.3.3 Simple n PQRCVCL0QW/PQRCVCL0Q/PQRCHCA0QW/PQRCHCA0Q (For Hotel) 1. Feature • 2.6 inch mono display • Button • Temp. sensing • No mode Change (PQRCHCA0QW/PQRCHCA0Q) • Group control 15 mm 64 mm 2. Specification Power Supply DC 12 V (From Indoor Unit) Rated Current (Max.) 0.085 A Compatible product...
Page 39
HVAC Solution 3. Wireless remote controller 3.1. Product Feature 3.1.1 Feature List 3.1.2 Function Description 3.1.3 Compatibility List 3.2 Product Description 3.1.1 Basic...
HVAC Solution 3.1 Product Feature 3.1.1 Feature list Controller Name Wireless Remote Controller Product Image Model Name PQWRH(C)Q0FDB, PWLSSB21H(C) On / Off Fan Speed Control Temperature Setting Mode Change Auto Swing Basic Vane Control (Louver Angle) E.S.P (External Static Pressure) Electric Failure Compensation Indoor Temperature...
HVAC Solution 3.1 Product Feature 3.1.2 Function Description Category Level1 Level2 Level3 DESCRIPTION Temp setting Cool the room to the desired temperature. Cooling - Setting range : 18~30 ℃ Heats the room the desired temperature. Heating - Setting range : 16~30 ℃ Dehumidification It removes the moisture with cooling.
Page 42
HVAC Solution 3.1 Product Feature Category Level1 Level2 Level3 DESCRIPTION Setting current time You can set current time. You can turn on the air conditioner at certain times of the day. On timer - It is executed only once and is deactivated. Timer Daily timer You can turn off air conditioning at certain times of the day.
Page 44
HVAC Solution 3.1 Product Feature Function list Wireless remote controller Category Level1 Level2 Level3 PWLSSB21H PWLSSB21C PQWRHQ0FDB PQWRCQ0FDB ● ● ● ● Wi-Fi Wi-Fi pairing Set to master (00) ● ● ● ● Mode override code : 0 Set to slave (01) Standard (11) Low (12) ●...
Page 45
HVAC Solution 3.1 Product Feature 3.1.3 Compatibility list with Multi V indoor units ◎ : Compatibility is available but more detailed functions refer to MULTI V 4series IDU features. ▲ : Need to set-up the IR Receiver product ● : Compatibility is available. X : Compatibility is unavailable.
Page 46
HVAC Solution 3.1 Product Feature 3.1.3 Compatibility list with Multi and Single indoor units ▲ : Need to set-up the IR Receiver product. ● : Compatibility is available. X : Compatibility is unavailable Better PQWRH(C)Q0FDB PWLSSB21H(C) ● Cassette Single Split ▲...
Page 47
HVAC Solution 3.2 Product Description 3.1.1 Basic n Model name : PQWRHQ0FDB / PQWRCQ0FDB / PWLSSB21H / PWLSSB21C 1. Feature PQWRH(C)Q0FDB PWLSSB21H(C) • 2 inch mono display • Temperature sensing °C/°F(5 s) TIME(3 s) 51 mm 26 mm 2. Specification Power Supply 1.5 V (AAA Batteries 2EA) Compatible product...
