Thank you for purchasing this Panasonic appliance. Please read these instructions carefully and use the appliance correctly and safely. ● This appliance is intended for household use only. ● Please read the “Safety Precautions” and “Important Information” carefully before ●...
Do not use the appliance if the power cord or power plug is damaged or ● the power plug is loosely connected to the power socket. If the power cord is damaged, it must be replaced by the manufacturer, its Panasonic ➜ service center or a qualified person in order to avoid hazards.
Page 4
Abnormal noise is generated during operation. • The appliance has other abnormalities or malfunction. ease contact the Panasonic service center for Inspection and repair. ➜ Make sure that the voltage on the label of the appliance is the same as that ●...
Page 5
Safety Precautions You must comply CAUTIONS To avoid risks of electric shock, fire, smoke, burns, scalds, injury or property loss Do not cook on a broken or cracked top plate. If the top plate is broken or ● cracked, switch the appliance off immediately at the main power supply (wall switch) and contact a qualified technician.
Page 6
Safety Precautions You must comply CAUTIONS To avoid risks of electric shock, fire, smoke, burns, scalds, injury or property loss Try not to use an extension cord. If required, please use an extension cable ● with a high current capacity and over-current protector. CAUTION: The cooking process has to be supervised.
Important Information Do not use this appliance outdoors. ● This appliance emits magnetic lines of force. Do not place any objects ● susceptible to magnetic force near this appliance. • Radio, TVs, hearing aids, etc. may be liable to noise interference. •...
Parts Name and Operating Instructions Induction Heating Cooktop Front cooking Rear cooking zone Top plate Power cord zone Air exit Control panel Power plug (See EN9) Bottom Air intake Front Air exit...
Suitable Cookware Compatible Incompatible The pot bottom is made of materials which The pot bottom is made of materials which can be attracted by magnets, such as iron/ cannot be attracted by magnets, such as cast iron, enameled iron and magnetic aluminum/copper, heat-resistant glass, ceramic stainless steel.
Notice Before Use Preparation Place a pot in the center of the cooking ● zone and make sure that the bottom diameter of the pot is larger than 12 cm. Otherwise, the cooking zone will not work ➜ normally. Before cooking, wipe off water from the ●...
Page 12
Notice Before Use Safety features High oil temperature protection ● Small object detection ● No pot detection ● Abnormal voltage protection ● Switch abnormality detection ● Stop heating Crystal temperature sensor failure and overheating ● protection Automatic power-off ● If there is no operation within 2 hours during work, the device display will ➜...
How to Use - Heat Level Adjustment Touch the main power switch. After the appliance is powered on, the buzzer beeps once, all displays show “–” or “– –”, indicating that the appliance has entered the standby mode. Place a suitable cookware on the cooking zone that you wish to use.
Page 14
How to Use - Heat Level Adjustment Please pay attention to the hot surface after operations After use, the display of the corresponding cooking zone will flash “H”, indicating that the surface is very hot. * It will disappear when the surface has cooled down to a safe temperature.
How to Use - Timer You can set it to turn off the cooking zone when the set time is elapsed. ● * The timer setting range is 1 to 99 min. Set the timer Please make sure that the heat level of the Front/Rear cooking zone is set.
How to Clean Spilled food or oil scorched on the appliance may become difficult to clean, please ● clean the appliance frequently. Before cleaning, please stop heating, unplug the power plug and wait for the top ● plate to cool down. After each use, please clean immediately after the top plate cools to avoid clean- ●...
If the problems above cannot be resolved or errors are shown, please turn off the main ● power and unplug the power plug immediately. Contact the authorised dealer or the Panasonic Service Center for details of the last 2 digits ➜ of “ ”. EN17...
No power. be turned on. outage near or in your house. If you’ve checked everything and the problem persists, contact the Panasonic service center. Touch keys do not Unlock the operating keys. See The operating keys are locked. respond. ‘‘Child lock’’ (EN12)
Please note the error code, turn off the The display shows H01, The appliance has main power, unplug the power plug H04, H11 and H26. malfunction. from the wall socket, and contact the Panasonic service center. Specifications KY-C223B Power supply 220 V 50 Hz Power consumption...
Installation (for installers) Precautions for Installation CAUTIONS To avoid risks of electric shock, fire, smoke, burns, scalds, injury or property loss Failure to follow these advice may result in electrical shock or death. ● Disconnect the appliance from the power supply before carrying out any work or maintenance. ●...
Page 21
To avoid any damage, the sandwich layer and adhesive must be heat resistant. ● Cable and socket outlet If the cable is damaged or to be replaced, the repair must be carried out by Panasonic service ● center with dedicated tools to avoid any accidents.
Selection of Installation Equipment Cut out the countertop as the drawing below. 1. For the installation and use, a minimum of 5 cm space shall be preserved around the hole. 2. Make sure the thickness of the countertop is at least 30 mm. Please select heat-resistant countertop material to avoid deformation caused by the heat radiation from the top plate.
Page 23
Selection of Installation Equipment Under any circumstances, make sure the appliance is well ventilated and the air intake and exit are not blocked. Ensure the appliance can run normally. As follows: Note: The safety distance from the top plate to the cupboard should be at least 760 mm.
