All manuals and user guides at all-guides.com CHAPTER 1. GENERAL This manual describes the ER-A310/A330 disassembly procedures Master reset (All memory clear) and the option attachment procedures. For assembly procedures, reverse the disassembly procedures. For attachment of options which There are two possible methods to perform a master reset.
5) Remove transformer cable and drawer cable from the main CHAPTER 3. REMOVING THE TOP PWB. CABINET (For ER-A310 & ER-A330) 1. ER-A310 1) Remove the printer cover 2) Remove the two screws 3) Remove the screw and grounding wire 4) Separate the top cabinet and the drawer unit.
All manuals and user guides at all-guides.com 5) Remove transformer cable and drawer cable from the main 2. ER-A330 PWB. 1) Remove the printer cover 2) Remove the three screws 3) Remove the screw and grounding wire CHAPTER 4. REMOVING THE BOTTOM CABINET (Only for ER-A330) 1.
4) Remove the screw and grounding wire 5) Remove the printer unit from the top cabinet. CHAPTER 6. REMOVING THE MAIN PWB (For ER-A310 & ER-A330) 1. ER-A310/A330 1) Remove the top cabinet. 2) Remove the printer unit. 3) Remove the following connector cables from the main PWB.
The drawer unit should be securely fitted to the supporting platform to avoid instability when the drawer is open. 1. Outline The ER-A310/A330 allows connection of one remote drawer ER- 04DW. 2. Installation procedure for ER-A310 5) Fix ground wire of the ER-04DW on the standard drawer with 1) Remove the top cabinet.
(Only for ER-A330) bracket-B to the platform. * For the ER-A310, standard provision. The drawer fixing kit is used for securing the cash drawer when installing separately from the ECR main unit. By using two of brackets, the drawer box can be protected from drifting especially when it is filled with coins.
CHAPTER 9. SHIELD PLATE KIT: CHAPTER 10. ONE HOLE CASHIER DKIT-8666BHZZ (Only KEY KIT: for ER-A330) DKIT-8669BHZZ (For ER-A310 & 330) * Standard provision for the TQ, TR, and TS versions of the ER- 1. Component list A330. PRICE PARTS CODE DESCRIPTION Q’TY...
Page 9
No. NC9 on the main PWB. CHAPTER 11. KEY TOP KIT 1. Outline The ER-A310/A330 employs the following key top (option) to allow additional installation of the key top and change in the key layout. MODEL NAME DESCRIPTION 1 ×...
Page 10
All manuals and user guides at all-guides.com ER-12KT7, ER-22KT7 Note: There are black spacers and white spacers. Refer to the figure before for attaching them. • Attach the black spacer to the left lower side, and the white spacer to the right lower side. ER-11DK7, ER-51DK7 –...
