- Page 1 Form No. 3358-271 Rev A Grapple Rake For Compact Utility Loaders Model No. 22521—Serial No. 270000001 and Up Register your product at www.Toro.com Original Instructions (EN)
-
Page 2: Table Of Contents
Whenever you need service, genuine Toro parts, or Maintenance ............7 additional information, contact an Authorized Service Recommended Maintenance Dealer or Toro Customer Service and have the model Schedule(s) ........7 and serial numbers of your product ready. The model Greasing the Pivot Joints ......... 7 and serial numbers are located on a plate on the Storage .............. -
Page 3: Safety
Safety When the engine is off, attachments in Improper use or maintenance by the operator the raised position can gradually lower. or owner can result in injury. To reduce the Someone nearby may be pinned or injured potential for injury, comply with these safety by the attachment as it lowers. -
Page 4: Stability Ratings
Stability Ratings Stability Without a Load Orientation Stability Rating To determine the degree of slope you can traverse Front Uphill with the attachment installed on a traction unit, find the stability rating for the hill position you want to travel in the appropriate table below, then find the degree of slope for the same rating and hill position in the Stability Data section of the Rear Uphill... -
Page 5: Product Overview
Product Overview Specications Note: Specifications and design are subject to change without notice. Width 34.5 inches (87.6 cm) Length 18 inches (46 cm) Height 30 inches (76 cm) Weight 265 lb (120 Kg) Figure 2 1. Upper jaw 3. Tooth 2. -
Page 6: Operation
Operation Note: Always use the traction unit to lift and move the attachment. Refer to your traction unit Operator’s Manual for procedures to install an attachment, connect hydraulic hoses, and remove an attachment. Lifting Objects Use the attachment to grab and lift heavy objects such as logs and rocks. -
Page 7: Maintenance
Maintenance Recommended Maintenance Schedule(s) Maintenance Service Maintenance Procedure Interval • Grease the pivot joints. Before each use or daily • Paint chipped surfaces. Before storage If you leave the key in the ignition switch, someone could start the engine. Accidental starting of the engine could seriously injure you or other bystanders. -
Page 8: Storage
Storage 1. Before long term storage, wash the attachment with mild detergent and water to remove dirt and grime. 2. Paint all scratched or bare metal surfaces. Paint is available from your Authorized Service Dealer. 3. Store the attachment in a clean, dry garage or storage area. - Page 12 (Dealer) to obtain guarantee policies for your country, province, or state. If for any reason you are dissatised with your Distributor’s service or have difculty obtaining guarantee information, contact the Toro importer. If all other remedies fail, you may contact us at Toro Warranty Company.
