3.
Product description
3.1
Intended use
This accessory kit contains clamping accessory and
connection accessories for the testing of common rail
pumps CB 28 (hereinafter referred to as CB 28) in con-
junction with the EPS 815, with lubricating oil supply
and tester set CRS 845H.
3.2
Scope of delivery
Designation
Fixing flange (for flange 85 mm) with
4 blind holes for hexagon bolt (4 x M10 x 30
ISO 4017-8.8)
Hexagon bolt (4 x M10 x 30 ISO 4017-8.8)
Washer (4 x DIN 125-A10.5-ST)
Coupling half (D=24.8, M18 x 1.5)
Mounting sleeve for coupling half
Mounting wrench for coupling half
Exhaust gas sampling hose (suction line
with flow restrictor D = 2.4 mm)
Exhaust gas sampling hose (supply)
Union nut (2 x A2L15 DIN 3870)
Cutting ring (2 x 15 DIN 3861)
Inlet union (2 x M14X1.5/ AD15/ 24°)
Test adapter (M14 x 1.5 / plug-in hose nip-
ple)
Inlet union screw (2 x 10(3-4) DIN
7643-9SMNPB2)
Flat sealing ring (8 x A14X18 DIN 7603-CU)
Threaded piece (M16x1.5 / M14x1.5)
Flat sealing ring (2 x A16X20 DIN 7603-CU
Threaded socket (M10x1, ISO 8434-1-L10)
Hose line (return)
Flat sealing ring (3 x DIN 7603 A 10 X 13.5
-Cu
Screw clamp (10 - 16 mm)
Hydraulic hose (2 x G 1/8 - coupling)
CD-Testdata Vers. 2014/C or higher
i
The order numbers in the 'Scope of delivery' chapter
are only for information.
Robert Bosch GmbH
Product description | 1 687 010 496 | 15
3.3
Designation
Pressure gauge 0–1600 kPa (0 – 16 bar)
Pressure gauge -100–500 kPa (-1 – 5 bar)
Parts set for drain valve (2 x)
3.4
R
EPS 815
R
Test set CRS 845H (1 687 002 845).
R
Software EPS 945, Version 4.35 or higher
Part number
R
Operating knowledge on the EPS 815 with lubricat-
ing-oil supply and on tester set CRS 845H.
1 685 720 356
R
Good knowledge of the mode of operation of com-
mon rail pumps.
2 911 061 761
2 916 011 018
3.5
1 686 430 059
1 680 506 040
1. Insert the "EP software" CD in the DVD/CD drive.
1 687 951 030
Installation of the software then starts automat-
1 680 712 367
ically.
1 680 712 202
The dialog box, "Select Setup Language", is dis-
2 915 101 009
played.
2 916 673 008
2. Comply with the instructions and install the soft-
1 683 385 056
ware.
0 986 613 091
2 911 201 703
2 916 710 609
2 413 359 003
2 916 710 611
1 683 356 133
1 680 712 373
2 916 710 605
1 681 314 078
1 680 712 327
1 687 370 318
Special accessories
Prerequisites
Installing the EPS 945 software
1 689 989 212
en
Part number
0 986 613 102
0 986 613 103
0 986 615 075
|
2014-10-31
