Preface You have purchased the XG2000CR, a compact, 20 port 10 Gigabit Ethernet layer 2 switch that achieves unsurpassed standards of high throughput and low-latency performance. This manual explains the procedures required to install your XG2000CR and should be read and understood before you start using your XG2000CR.
Page 4
Do not install the XG2000CR where it will be exposed to direct sunlight, close to a heating device, or in an environment with much dust and high humidity, as there is a risk of electric shock and fire.
Page 5
Category Warning Danger of If the XG2000CR is to be left unused for any significant period, remove the power plug from the outlet for electric shock safety reasons. Failure to do so may cause a fire or damage. or fire Do not damage or remodel the power cords, as this may cause electric shock or fire.
Page 6
Check that all units installed in the rack are correctly connected to a grounded power source. Set the XG2000CR nearby the AC outlet, and keep it within the reach of the power cord for pulling it eas- ily. The XG2000CR is shut off by pulling the power cord off the AC outlet.
Page 7
XG2000CR includes both high voltage and high temperature components. If maintenance is required, contact the vendor's service department. Warning label The following warning label may be found on the top of XG2000CR. Do not attempt to remove this warning label. Safety precautions •...
Page 8
For security A default login password is set before the XG2000CR is shipped. For security reasons, a new password should be chosen before the XG2000CR is used. Safety CAN/CSA C22.2 No.60950-01,UL60950-1 and EN60950-1 Static electricity Under certain conditions, twisted pair cables can become charged with static electricity. Con- necting a statically charged twisted pair cable to a device can cause the device or its LAN port to operate falsely or to become damaged.
Page 9
Laser safety The XG2000CR can be installed with a class 1 laser module (XFP module), and can emit invisible laser light. Do not look into the 10 Gigabit Ethernet port openings. The following warning applies to the XG2000CR’s laser: • The XG2000CR can be installed with XFP modules, which are laser devices.
Page 10
Connect the power cords to the XG2000CR. Insert the power plugs into the power inlets at the rear of the XG2000CR. For Safe Use of the XG2000CR...
Page 11
No instale el XG2000CR en lugares expuestos a la luz solar directa, cerca de un aparato que emita calor, o en un ambiente con mucho polvo y humedad, ya que existen riesgos de descarga eléctrica e incendio.
Page 12
Si el XG2000CR no se utiliza por un período considerable, retire el enchufe de la toma por razones de seg- uridad. Si no lo hace, puede ocurrir un incendio o daños.
Page 13
Cuando realice tareas de mantenimiento en el XG2000CR, asegúrese de retirar primero el enchufe de la toma de alimentación. Peligro Utilice el XG2000CR únicamente si la temperatura en el interior del rack es de 40 °C o menos. Ignorar esta durante el recomendación puede dañar la unidad.
Page 14
• La vida útil prevista del XG2000CR es de aproximadamente cinco años, suponiendo el uso a una temperatura ambiente de 25 °C. • El uso de esta guía de hardware, del XG2000CR, su firmware y el software de adminis- tración es responsabilidad del usuario.
Page 15
No utilice el XG2000CR en casos que requieran alta seguridad sin garantizar de otra manera el nivel de seguridad exigido. Fujitsu y sus empresas asociadas no asumen responsabilidad alguna por daños y perjuicios derivados del uso de esta unidad por el usuario en aplica-...
Page 16
Seguridad del láser El XG2000CR puede tener instalado un módulo láser de Clase 1 (módulo XFP) que emite luz láser invisible. No dirija su vista al interior de las aperturas de los puertos Ethernet de 10 Gbps. La siguiente advertencia se aplica al módulo láser de esta unidad: •...
Page 17
Conexión de los cables de alimentación al XG2000CR. Inserte los conectores en las entradas de alimentación que se encuentran en la parte trasera de la unidad. Uso seguro del XG2000CR...
Page 37
EMC Class A Notices and Warnings This section includes the EMC Class A warnings for the XG2000CR. Electromagnetic compatibility (USA) FCC PART 15B Class A FCC WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Page 38
VCCI Class A Warning for JAPAN VCCI - A JIS C 61000-3-2 Class A Warning for Korea WARNING This is a Class A Device and is registered for EMC requirements for industrial use. The seller or buyer should be aware of this. If this type was sold or purchased by mis- take, it should be replaced with a residential-use type.
Page 39
Organization This manual is organized as follows. Chapter 1 Installation This chapter lists the items that should be in the XG2000CR package, describes the names and functions of the various components of the XG2000CR. Chapter 2 Installation and Operation This chapter explains how to install, connect, and start the XG2000CR.
Page 40
Symbols used in this manual This manual uses the following symbols. This symbol indicates a point that operator should pay attention to. Attention Attention This symbol indicates a section which describes related information. Refer Refer This symbol means "Danger! You are in a situation that could result in bodily injury". WARNING Before continuing, make yourself aware of the hazards involved and become familiar with common ways of preventing accidents.
Installation This chapter lists the items that should be in the XG2000CR package, describes the names and functions of the various components of the XG2000CR. 1-1 Parts List....................42 1-2 XG2000CR Components ................44 1-3 Labels .....................47...
Parts List Before proceeding, check that all of the following parts were included in your XG2000CR package. Contact the vendor's service department if any parts are missing and/or the manual has any miss- ing or wrongly collated pages. Keep the hardware guide (this manual) and the CD-ROM in a safe place.
Page 45
• Power cord must meet the requirements of the country where you use this product. • Serial cross cable : A cable to connect the XG2000CR to a PC when the settings need to be adjusted. • Hardware Guide : A manual describing the XG2000CR hardware and related matters (this manual).
XG2000CR Components This section explains the names and functions of the various XG2000CR components, including the various indicator LEDs. XG2000CR front The following explains the names and functions of the components at the front of the XG2000CR. XFP/Port 1 - 4...
Page 47
Refer to "XG2000 series User's Guide" "6.1 Verifying the Device Operations" for "show Refer Refer system status" command details. Attention Attention In order to avoid a negative effect on the cooling of the XG2000CR, the Rear Fan Unit screws should be kept tight at all times. XG2000CR Components...
Page 48
Display LEDs There are three main indicator LEDs on the front of the XG2000CR: Power LED, Alarm LED, and Status LED. The following explains the LED display under various conditions. XG2000CR Condition Power Alarm Status Starting up Power just turned on...
Labels Caution Label, Safety Label, product nameplate, product ID label, and MAC label are to be found in various places on the XG2000CR. MAC Label Product ID Label Safety Label Caution Label Product Nameplate [Top view of XG2000CR] Product ID Label...
Page 50
Caution Label Obey the following Caution: Safety Label Obey the following Safety label: Installation...
Page 51
Serial Number MAC Label This indicates the MAC address: MAC addresses are allocated as displayed on the MAC label: Address on the MAC label Location xx:xx:xx:xx:xx:xx Mng-LAN xx:xx:xx:xx:xx:xx+1 XG2000CR xx:xx:xx:xx:xx:xx+2 Port 1 xx:xx:xx:xx:xx:xx+3 Port 2 xx:xx:xx:xx:xx:xx+4 Port3 xx:xx:xx:xx:xx:xx+5 Port 4...
Page 52
Address on the MAC label Location xx:xx:xx:xx:xx:xx+15 Port 14 xx:xx:xx:xx:xx:xx+16 Port 15 xx:xx:xx:xx:xx:xx+17 Port 16 xx:xx:xx:xx:xx:xx+18 Port 17 xx:xx:xx:xx:xx:xx+19 Port 18 xx:xx:xx:xx:xx:xx+20 Port 19 xx:xx:xx:xx:xx:xx+21 Port 20 (=yy:yy:yy:yy:yy:yy) Installation...
Install the XFP modules in the XG2000CR. "2-3-1 Installing the XFP modules" Connect the cables to the XG2000CR Connect the required fiber optic cables and power cords to the XG2000CR. "2-4 Cable Connection" Check that the everything is secure Check that the XG2000CR doesn't wobble and that no cables are loose.
Installation Procedure This chapter describes the installation requirements and installation procedure. 2-2-1 Installation requirements Before installing the XG2000CR, read "For Safe Use of the XG2000CR (P.2)" and comply with the installation requirements described below. Space requirements When installing the XG2000CR, a certain amount of installation space is necessary.
• Set the XG2000CR nearby the AC outlet, and keep it within the reach of the power cord for pulling it easily. The XG2000CR is shut off by pulling the power cord off the AC outlet.
Page 57
Fix the nuts and rails to the rack posts. First, choose nuts, cage nuts or rack nuts, by the type of hole in the rack post. When the rack has square post holes, cage nuts are used. When the rack has round holes, rack nuts are used.
Page 58
[When the rack has round post holes] Rack Post Rack Screws (Large) Rack Post Rack Screws (Large) Rack Nuts Rack Post Rail R Rail L Refer to Detail A Rack Nuts Rack Nuts Clip the rack nuts onto the Rack Post rack post so that the holes are lined up.
Page 59
Each of the four rack mounting brackets (two of front side, two of back side) has two holes that should line up with matching holes on the sides of the XG2000CR, as shown in the dia- gram. Attach each rack mounting bracket using the countersunk bracket screws provided.
2-2-3 Unracking the XG2000CR The following shows how you unrack the XG2000CR. CAUTION Hold XG2000CR tight when unracking or it may fall to cause injury. Pull forward the XG2000CR and take down from the rack. Rack Screws (Small) Air flow...
2-3-1 Installing the XFP modules The following explains how to install XFP modules in a XG2000CR. XFP modules installed in XG2000CR should be selected from the approved vendor list. Please contact your sales representative for the approved XFP module list.
2-3-2 Uninstalling the XFP modules The following explains how to uninstall XFP modules in a XG2000CR. Uninstall a XFP module in a XG2000CR. Uninstall the XFP module in the following manner: (1) Unlock the XFP module by lowering the lever on odd numbered ports.
This section explains how to connect the cables and power cords. 2-4-1 Connecting cables The cables need to be connected to the XG2000CR XFP modules and Port 5 - Port 20 Con- nectors. Connect the fiber optic cables to the XG2000CR.
Connect the CX4 cables to the XG2000CR. Connect the CX4 cables to Connectors (Port 5 - Port 20) on the front of XG2000CR. Attention Attention • It is necessary that the connectors be fixed in the correct position, in order to protect the connector interface against foreign objects such as dust.
• If the XG2000CR is to be left unused for any significant period, remove the power plug from the outlet for safety reasons. Failure to do so may cause a fire or dam- age.
XG2000CR, immediately disconnect the power cord from the AC outlet. To make this easy, set the XG2000CR nearby the AC outlet, and keep it within the reach of the power cord for pulling it easily. After the power is disconnected, contact the vendor's service department immediately.
Troubleshooting This chapter describes what you should do when your XG2000CR fails to operate prop- erly. 3-1 Start-up Problems ...................66 3-2 Hardware Problems................67...
The following explains some general errors that can occur. Check if any of these match your prob- lem. The XG2000CR does not turn on [Symptom] The power cord is inserted in the power outlet, but the XG2000CR does not turn on. [Cause] Possible causes: 1 The power cord is loosened or pulled out.
XG2000CR off and contact the vendor's service department. Voltage error When a voltage problem is detected, the Alarm LED lights orange, and an error is recorded in the event log. In this case, turn the XG2000CR off and contact the vendor's service depart- ment. Power supply error...
Appendix-A Specifications This section details the specifications of XG2000CR. A.1 Product Specifications The product specifications of the XG2000CR are as follows: Items Overview IEEE802.3ae/ak compliant 10 Gigabit Ethernet port × 4 10 Gigabit ports Port1 - Port4 (for XFP modules) Hot swappable IEEE802.3ak compliant 10 Gigabit Ethernet port ×...
Appendix-B China RoHS Declaration for the XG2000CR This document describes China RoHS Declaration for the XG2000CR. China RoHS Declaration for the XG2000CR...
Appendix-C EC Declaration for the XG2000CR The EC Declaration of Conformity and product technical documentation are kept at the following location. address Fujitsu Services Limited 22 Baker Street London W1U 3BW Phone number +44-786-782-3346 Product Type 10GbE L2 Switch Model Number...
Page 75
XG2000CR Hardware Guide P3N1-E192-03EN April,2011 PFU LIMITED Printed in Japan • Contents of this manual are not to be reproduced without permission from PFU. • The contents of this manual may be updated without notice. • PFU assumes no liability for damages to third party copyrights or other rights arising from the use of any information in this manual.
