Basic Operation
AX40
Displaying the color/tone bars
For your convenience, it can be displayed the color/tone bars for each attributes when adjusting them.
1. Confirm the Adjust window is displayed.
2. When "Image/Tone" is displayed, press the ENTER
key.
3. The extracted image is dissapeared and the color/tone bars appear.
At this point, you can also change the value. As you change the value, the sliders are
immediately reflected and move. The current extraction color is also reflected and changed.
Each slider shows the median and its range.To return to the extracted image, press the C key.
5. Editing (Widen. Lumi.) the existing extraction color
Edit the extraction color "A" by adjusting the range of Luminosity.
"Widen Lumi." is to widen the range of Luminosity to adjust the extraction color.
It's easier to adjust the range of Luminosity only comparing to adjust entering the value on
the Adjust window. Just pressing the ENTER key can change the value by 10.
1. Select "A" from the Modify window.
A sub window is displayed and select "Widen Lumi."
2. Press the ENTER key.
Pressing the ENTER key once enables to increase the value by 10.
To return to the previous extraction status, press the C-key and select "Undo".
When having finished extracting, press the C-key to register the color.
The display returns to the checker menu. (Editing the extraction color is completed.)
For more details about checkers, refer to the User's manual (Hardware and Operation).
