Quick Setup Guide
Start Here
Please read the Safety and Legal booklet first before you set up your machine. Then, please read this Quick Setup
Guide for the correct setup and installation.
To view the Quick Setup Guide in other languages, please visit http://solutions.brother.com/.
WARNING
CAUTION
1

Unpack the machine

WARNING
Plastic bags are used in the packaging of your machine. Plastic bags are not toys. To avoid danger of
suffocation, please keep these bags away from babies and children and dispose of them correctly.
CAUTION
CAUTION
When you move the machine, grasp the side handholds that are under the scanner. DO NOT carry the machine
by holding it at the bottom.
Note
• Keep a minimum gap around the machine as shown in the illustration.
• The components included in the box may differ depending on your country.
• Please save the original packaging should you need to ship the machine in future.
• If for any reason you must ship your machine, carefully repack the machine in the original packaging to avoid
any damage during transit. The machine should be adequately insured with the carrier. For how to repack
the machine, see Packing and shipping the machine in the Advanced User's Guide.
• The interface cable is not a standard accessory. Buy the appropriate interface cable for the interface you
want to use (USB or Network).
USB cable
• It is recommended to use a USB 2.0 cable (Type A/B) that is no longer than 2 metres.
• DO NOT connect the interface cable at this time. Connecting the interface cable is done during the MFL-Pro
installation process.
Network cable
Use a straight-through Category5 (or greater) twisted-pair cable for 10BASE-T or 100BASE-TX Fast Ethernet
Network.
WARNING indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injuries.
CAUTION indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injuries.
250 mm
100 mm
100 mm
MFC-7360N
MFC-7460DN
90 mm
CEE-ENG Version 0
1

Advertisement

Table of Contents
loading

Related Manuals for Brother MFC-7360DN

Summary of Contents for Brother MFC-7360DN

  • Page 1: Unpack The Machine

    Please read the Safety and Legal booklet first before you set up your machine. Then, please read this Quick Setup Guide for the correct setup and installation. To view the Quick Setup Guide in other languages, please visit http://solutions.brother.com/. WARNING indicates a potentially hazardous situation which, if not avoided, WARNING could result in death or serious injuries.
  • Page 2 Remove the packing Pull the paper strip to remove the protective material as shown in the illustration. material from the machine IMPORTANT DO NOT connect the AC power cord yet. Remove the packing tape from the outside of the machine and the film covering the scanner glass.

  • Page 3: Load Paper In The Paper Tray

    Put paper in the tray and make sure: Load paper in the paper The paper is below the maximum paper  mark (b b b) a. tray Over filling the paper tray will cause paper jams. Pull the paper tray completely out of the ...

  • Page 4: Connect The Power Cord

    Note Connect the power cord If you are sharing one telephone line with an and telephone line external telephone, connect it as shown below. IMPORTANT DO NOT connect the interface cable yet. Connect the AC power cord to the machine, and then plug it into an electrical socket.

  • Page 5: Set Your Country

    Set your Country Choose a Receive Mode You must set your country so that the machine works There are four possible receive modes: Fax Only, correctly on local telecommunication lines in each Fax/Tel, Manual and External TAD. country Do you want to use the telephone features of your machine (if available) or an external telephone or Check that the power is turned on by plugging external telephone answering device connected on the...

  • Page 6: Enter Personal Information (Station Id)

    Set the LCD contrast Enter personal (if needed) information (station ID) If you are having difficulty reading the LCD, try The machine displays the date and time, and if you changing the contrast setting. set up the station ID, it will add it to each fax you send. Press Menu, 1, 5.

  • Page 7: Set The Telephone Line Type

    Fax Transmission Report Set the telephone line type Your Brother machine is equipped with a If you are connecting the machine to a line that Transmission Verification Report that can be used as features a PABX (PBX) or ISDN to send and receive confirmation that you sent a fax.

  • Page 8: Automatic Daylight Savings Time

    Press Stop/Exit. Automatic Daylight Note Savings Time PBX and TRANSFER The machine is initially set to Normal, which lets the machine connect to a standard PSTN (Public You can set the machine to change automatically for Switched Telephone Network) line. However, daylight savings time.

  • Page 9: Choose Your Connection Type

    , go to page 10 Macintosh, go to page 12 For Wired Network ® Windows , go to page 14 Macintosh, go to page 16 Note You can download the latest drivers and utilities for your machine from the Brother Solutions Center at http://solutions.brother.com/.

  • Page 10: Before You Install

    Note PaperPort™ 12SE. This software supports ® Windows XP (SP3 or greater), XP Professional If the Brother screen does not appear ® x64 Edition (SP2 or greater), Windows Vista automatically, go to My Computer (Computer), ® (SP2 or greater) and Windows 7.
  • Page 11 The XML Paper Specification Printer Driver is ® the most suitable driver for Windows Vista ® Windows 7 when printing from applications that use the XML Paper Specification documents. Please download the latest driver by accessing the Brother Solutions Center at http://solutions.brother.com/.
  • Page 12 It may take a few minutes for installation to drivers and information on the Mac OS X you complete. are using, visit http://solutions.brother.com/.) Follow the on-screen instructions until this Connect the USB cable to the USB connector screen appears. Choose your machine from the list, and then click OK.
  • Page 13 Macintosh Download and install Presto! PageManager When Presto! PageManager is installed OCR capability is added to Brother ControlCenter2. You can easily scan, share and organize photos and documents using Presto! PageManager. On the Brother Support screen, click Presto! PageManager and follow the on-screen instructions.

  • Page 14: Wired Network

    • The installation CD-ROM includes ScanSoft™ Note PaperPort™ 12SE. This software supports ® Windows XP (SP3 or greater), XP If the Brother screen does not appear Professional x64 Edition (SP2 or greater), automatically, go to My Computer (Computer), ® Windows Vista (SP2 or greater) and double-click the CD-ROM icon, and then ®...
  • Page 15 PaperPort™ 12SE or ScanSoft™ PaperPort™ • If an error message appears during the 11SE installed, please purchase the Brother NL-5 software installation, run the pack which is a multiple PC license agreement Installation Diagnostics located in pack for up to 5 additional users.
  • Page 16 It may take a few minutes for installation to drivers and information on the Mac OS X you complete. are using, visit http://solutions.brother.com/.) Follow the on-screen instructions until this Remove the protective cap from the LAN screen appears. Choose your machine from connector marked with a symbol.
  • Page 17 • If this screen appears click OK. Presto! PageManager When Presto! PageManager is installed OCR capability is added to Brother ControlCenter2. You Enter a name for your Macintosh in can easily scan, share and organize photos and Display Name up to 15 characters long and documents using Presto! PageManager.

  • Page 18: Other Information

    Other Information Brother CreativeCenter Get inspired. If you're using Windows, double-click the Brother CreativeCenter icon on your desktop to access our FREE web site with many ideas and resources for personal and professional use. Mac users can access Brother CreativeCenter at this web address: http://www.brother.com/creativecenter/...
  • Page 19 Consumables When the time comes to replace consumable items, an error will be indicated by the LCD on the control panel. For more information about the consumables for your machine, visit us at http://solutions.brother.com/ or contact your local Brother reseller.
  • Page 20 The contents of this manual and the specifications of this product are subject to change without notice. Brother reserves the right to make changes without notice in the specifications and materials contained herein and shall not be responsible for any damages (including consequential) caused by reliance on the materials presented, including but not limited to typographical and other errors relating to the publication.
