About This User Guide ENGLISH Thank you for choosing LG. Please carefully read this user guide before using the device for the first time to ensure safe and proper use. Visit the LG website at www.lg.com to obtain the latest version of this manual.
Page 3
instructional Notices Situations that could cause injury to yourself and others, or WARNING damage to the device or other property. Notices or additional information. NOTE...
Table of Contents Safety Information......5 Call Notifications ........38 Change When Notifications Arrive..39 Basic ..........16 See Remaining Battery or Date ....39 Accessories ..........17 Access the Sound Settings ......40 Watch Layout ...........18 Turn Your Screen Off Temporarily with Charging the Watch .........20 Theater Mode ...........40 If the Screen Freezes .......22 Boost Screen Brightness Temporarily ..41...
Page 5
Downloading Other Apps......54 Phone............54 Open Source Software Notice Information Call Forwarding ........56 Trademarks ..........68 Messenger ..........58 LG Health ..........59 Use the Google Fit App ......60 Settings ........61 Launching the Settings Menu ....62 Adjusting Display Brightness ....62 Change Your Watch Face ......62 Change the Font Size .......62...
Page 7
Before turning on your product, review the basic safety information provided here. General safety & Handling While using your product, be aware of the following common-sense guidelines. Your environment Safe operating temperatures. Use and store your product in • temperatures between 0°C/32°F and 40°C/104°F. Exposing your product to extremely low or high temperatures may result in damage, malfunction, or even explosion.
Page 8
Do not attempt to repair or modify or re-manufacture the product. • It is equipped with an internal rechargeable battery which should be replaced only by LG or an authorized LG repair center. Do not open, disassemble, crush, bend or deform, puncture, or shred •...
Page 9
Use care when handling your product during or immediately after operation. If a problem arises using this product, stop using it and consult with • an authorized LG Electronics customer service center. Do not immerse or expose the product to water or other liquids. • Heart rate Precautions Pedometer, sleep, exercise, and heart rate are not intended to treat or •...
Page 10
Battery Warnings Do not disassemble, open, crush, bend or deform, puncture or shred • the device. Do not modify or re-manufacture the device, attempt to insert foreign • objects into the battery, immerse or expose to water or other liquids, or expose to fire, explosion or other hazard.
Page 11
For your safety, do not remove the battery inside the product. If you need to • replace the battery, take it to the nearest authorized LG Electronics service point or dealer for assistance. The Li-Ion Battery is a hazardous component which can cause injury.
Page 12
This product is not resistant to shock. Do not drop the product or • subject it to shock. Doing so might damage or deform the main unit, causing water leakage. Pacemakers and Other Medical devices Persons with pacemakers should: ALWAYS keep the product more than six (6) inches from their •...
Page 13
Tips for the display screen Do not display non-moving images for an extended period. This may • cause image burn-in or stains on the screen. Applications that display the same screen for more than 10 minutes • are not recommended, since the potential screen damage is not covered by warranty.
Page 14
specific Absorption rate (sAr) Values This product transmits and receives radio signals. It is designed and manufactured not to exceed the emission limits for exposure to Radio Frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. These standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health.
Page 15
Additional information on Specific Absorption Rates (SAR) can be found on the Cellular Telecommunications Industry Association (CTIA) website at http://www.ctia.org/. * Product meets current FCC Radio Frequency Exposure Guidelines FCC ID : ZNFW200A Part 15.19 statement General requirement This device complies with part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including...
Page 16
Connect the equipment to an outlet on a circuit different from that • to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. • Safety Information...
SIM Cap opener • NOTE Always use genuine LG accessories. The supplied items are designed only for • this device and may not be compatible with other devices. The items supplied with the device and any available accessories may vary •...
If it doesn't turn on, press and hold for a few seconds until the LG logo appears. If the screen freezes: Press and hold for over 10 seconds until the LG • logo appears to restart the watch. Power Key When the device is idle: Press once quickly to wake the screen.
Page 20
When the device is idle: Press the Top Key to launch Contacts. • Top / Bottom Press the Bottom Key to launch LG Health. • During a call: Control the volume. • Charging terminals Heart rate SIM cap sensor Microphone...
Charging the Watch Before using your watch for the first time, you should charge the battery. Use the charging cable included with the watch to charge the device's battery. You can also charge the device's battery using a computer. Simply connect the computer to the charging cable using the USB cable included with the watch.
Page 22
Place the watch on the charging cable and make sure that the charging terminals are aligned with each other. Connect the charging cable to a power outlet and place the watch on it. If your watch is turned off, it will turn on automatically. NOTE Make sure the watch is firmly connected to the charging cable before •...
If the Screen Freezes If the device freezes up and stops working, press and hold the Power Key for over 10 seconds until the device reboots and the LG logo is displayed. Basic...
Installing the SIM Card NOTE Please power off the device before you insert or remove a SIM card. • Don't use excessive force when you turn the SIM cap using the SIM cap opener. • Open the SIM cap using SIM cap opener as shown in the figure below. Align the SIM cap opener to the hole located at the bottom of the device and then turn counter-clockwise until the SIM cap direction indicator reaches the "UNLOCK"...
Page 25
Slide the Nano SIM card into the SIM card slot as shown in the figure. Make sure the gold contact area on the card is facing downward. Close the SIM cap using the SIM cap opener as shown in the figure below.
Page 26
NOTE Foreign materials on the SIM cap sealing pad or SIM cap may compromise the • water resistant function. Make sure to clean or remove any foreign material. SIM cap SIM cap sealing pad Unlock the siM Card If you insert the SIM card with a PIN lock, you have to enter the unlock code.
Turning on the Watch Turn the watch on by pressing and holding the Power Key (on the right- hand side of the device) for a few seconds. The screen lights up and the LG logo is displayed. Power Key Turning off the Watch Press and hold the Power Key until the app list appears.
Connecting to Another Mobile Device If you want to connect your watch to another device, you must reset your device. reset Your Watch This setting unpairs the watch from your phone, resets your watch’s settings to their factory default values, and deletes all of your data. Press and hold the Power Key until the app list appears.
Wearing the Watch Cautions for Water-resistance Your watch has undergone testing in a controlled environment and is proven to be water and dust-resistant in certain circumstances (meets the requirements of classification IP67 as described by the international standard IEC 60529 - Degrees of Protection provided by Enclosures [IP Code];...
Caution on Product Overheating Overheating the product to certain temperature will trigger a warning in order to prevent product breakage, skin irritation or damage, battery leakage, etc. Further rise in product temperature will turn off the power. Stop using the device if you feel discomfort due to overheating during use.
Page 31
ensuring Accurate Measurements Heart rate readings may be inaccurate depending on conditions and surroundings. Follow these steps for more accurate heart rate readings: Never measure your heart rate after smoking or drinking alcohol. • Smoking and/or alcohol can affect your heart rate. Never take heart rate measurements at low temperatures.
Before Pairing Before pairing, please do the following on the phone. Make sure that the Android operation system on your phone is version 4.3 or higher and supports Bluetooth. To find out whether your phone supports Android Wear, visit • http://g.co/WearCheck from your phone.
How to Pair Your Watch Turn on the watch and swipe the welcome screen left to begin. Tap a language. Connect your watch to a power source and swipe left to continue. NOTE If the battery is at less than 20%, charge your watch first before proceeding •...
Start on Your Watch Face (Where You See the Time) Start by waking up your watch. If your watch’s screen is dimmed, you can wake up the watch by doing any of the following: Touch the screen. • Turn your wrist so your watch face is upright. •...
Notification Cards Most notifications you see on your phone will also show up on your watch. These include notifications for missed calls, texts, event reminders, and more. Notifications are displayed in the form of cards at the bottom of the watch face.
To see More details To see more details, swipe the card from right to left. Some cards provide more details or have actions you can take. To Bring a Card Back After the card has been dismissed, swipe down from the top of your watch’s screen and tap the Undo button .
Call Notifications You can get an instant alert when your phone receives an incoming call. The notification displays the caller's number or contact on your phone and lets you accept or decline the call. NOTE The 'Play phone audio on watch' option is set as Off by default. •...
Change When Notifications Arrive You can change what notifications show up on your watch and when. To change the interruption settings, swipe down from the top of your watch’s screen. You'll see a set of interruption options. Tap to select None, Priority only, or Show all.
Access the Sound Settings Allows you to set the sound for notifications. You can also change to silent. Press the Sound icon • Turn Your Screen Off Temporarily with Theater Mode You can turn off your watch’s screen so the display doesn’t light up and notifications don’t appear.
Boost Screen Brightness Temporarily You can turn up the brightness temporarily if you’re outdoors in a sunny spot. The extra brightness will last for a few seconds and turn off automatically. Press the Power Key three times quickly. • If your screen is dim, touch the screen to wake up the watch. Swipe down from the top of the screen.
You can see a menu of simple tasks on your watch, and anything in this list can also be said aloud. Just say “OK Google” or swipe the home screen to the left until you see the Speak now option, then say your command or question.
Change the Apps You Use for Voice Actions You can set which apps to use for different voice actions. For example, you can change the app you use for setting alarms or sending messages. On your phone, open the Android Wear app.
Take or View a Note You can speak to your watch to create a note or view existing notes using QuickMemo+ or Android apps like Google Keep. If your screen is dimmed, tap the screen to wake up the watch. From the watch face, say “OK Google”...
Set a Reminder You can speak to your watch to set a reminder. Once you set a reminder, you’ll see a card when your reminder goes off. If your screen is dimmed, tap the screen to wake up the watch. From the watch face, say “OK Google”...
Show Me My Heart Rate You can use the Heart Rate app to measure and record your current heart rate. NOTE The device's heart rate measurement feature is not meant for clinical or • medical diagnosis. Follow the guidelines in Wearing the watch and Ensuring accurate measurements to make sure your heart rate measurements are accurate.
Send a Text This feature enables you to dictate text messages on your watch to contacts stored on your mobile device. You can also reply to any received text messages that appear in cards. sending a Message If your screen is dimmed, tap the screen to wake up the watch. From the watch face, say “OK Google”...
Email Your watch can be used to write and read emails from your mobile device. If your screen is dimmed, tap the screen to wake up the watch. From the watch face, say “OK Google” or press and hold the Power Key until the app list appears, then swipe left.
Agenda You can view events scheduled on your mobile device's calendar using your watch. If your screen is dimmed, tap the screen to wake up the watch. From the watch face, say “OK Google” or press and hold the Power Key until the app list appears, then swipe left.
Set a Timer The watch can be used as a countdown timer. Once you set a timer, you’ll have a new card with the countdown. If your screen is dim, tap the screen to wake up the watch. From the watch face, say “Ok Google” or press and hold the Power Key until the apps list appears, thenswipe left.
Set an Alarm Multiple alarms can be set on your watch. Your watch and phone alarms are separate. If your screen is dimmed, tap the screen to wake up the watch. From the watch face, say “OK Google” or press and hold the Power Key until the app list appears, then swipe left.
The app list provides a list of the applications included on the watch. To reach the Apps installed on Your Watch If your screen is dimmed, tap the screen to wake up the watch. Swipe left on the screen to open the apps list. Downloading Other Apps You can see a list of recommended apps in the Play Store Open the Android Wear...
Page 56
Answering and rejecting a Call During an incoming call, you can answer or reject the call. Swipe to the right to answer the call. • Swipe to the left to reject the call. • To View the Favorite contact list You can see the favorite contact list from your watch as easily as on your phone.
Tap to turn it off. NOTE You can also use the LG Call forwarding app to activate the feature while • paired with a GSM device. Using Apps...
Page 58
NOTE Descriptions, screen images and supported languages in this guide may differ • due to app updates. The call forwarding feature for your watch is not supported by all carriers. • Please contact your service provider for supported features. WARNING Depending on your service provider, you may have to register for call •...
Messenger You can send and respond to messages directly for your watch. sending a Message Press and hold the Power Key until the apps list appears, then touch Messenger Tap New message and then select the contact you want to send the message.
The LG Health app helps you manage your health and maintain good exercise habits by tracking logs and letting you complete with others. Press and hold the Power Key until the app list appears, then tap LG Health To start using this app, enter your profile and tap Select the desired item.
Use the Google Fit App The Fit app lets you count steps and view how far you have walked. You can also see your heart rate measurements. Installing the Google Fit app on the phone that your Android Wear watch is paired with lets you sync data between the two devices and enjoy all of Fit's features.
Launching the Settings Menu Press and hold the Power Key until the apps list appears, then touch • Settings Swipe left until the apps list appears, then tap Settings • Adjusting Display Brightness The brightness of the watch display can be altered on the device itself. From the Settings menu, tap Adjust brightness.
Gestures You can use motion gestures to navigate notification cards, lists, and more. From the Settings menu, tap Gestures to turn on or off. • - Flick your wrist out to scroll down a page. - Flick your wrist in to scroll up a page. - Push your arm down to select a card and open a new screen.
Bluetooth Devices Your watch automatically searches for Bluetooth devices within range. You can pair your watch with a headset in the Bluetooth devices menu within Settings. You can also unpair and disconnect headsets. From the Settings menu tap Bluetooth devices. •...
Airplane Mode When Airplane mode is on, you can use still many of the features on your watch (such as Heart Rate) when you are on an airplane or anywhere else where sending or receiving data is prohibited. NOTE When in Airplane Mode, your watch cannot access information stored on your •...
Unpair with Phone This setting unpairs the watch from your phone, resets your watch’s settings to their factory default values, and deletes all of your data. From the Settings menu, tap Unpair with phone. You are prompted to confirm. Your watch connects to one mobile device at a time. •...
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge to cover distribution costs (media, shipping, and handling) upon email request to opensource@lge.com.
Page 70
regulatory information Press and hold the Power Key until the app list appears. Tap Settings > About > Regulatory information. How to Update Your device Access to latest firmware releases, new software functions and improvements. Press and hold the Power Key until the app list appears. Tap Settings >...
