Page 2
Choose Multi-screen or Spot Monitor / or Both *See the DISK DATA REFERENCE CHART at the foot of this page. On the back of the WJ-HD220 you will find two monitor output connectors, one for a Spot Monitor and one for a Multi-screen Monitor. The Multi-...
Page 3
MAJOR OPERATING CONTROLS Front View SPECIFICATIONS General Power Source Required 220 V - 240 V AC, 50 Hz Power Consumption 45 W Ambient Operating Temperature +5°C - +45°C Ambient Operating Humidity Less than 85 % Dimensions 420 mm (W) x 44 mm (H) x 350 mm (D) Weight 5.2 kg Input...
