Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully. Before connecting, operating or adjusting this product, please read the instructions completely. Please keep this manual for future reference. Region number supported by this unit Region numbers are allocated to DVD players and DVD-Video according to where they are sold.
Declaration of Conformity Trade Name: Panasonic Model No.: DMR-EA18 Responsible Party: Panasonic Corporation of North America One Panasonic Way Secaucus, NJ 07094 Support Contact: Panasonic Consumer Electronics Company Telephone No.: 1-800-211-7262...
IMPORTANT SAFETY INSTRUCTIONS Read these operating instructions carefully before using the unit. Follow the safety instructions on the unit and the applicable safety instructions listed below. Keep these operating instructions handy for future reference. Read these instructions. Keep these instructions. Heed all warnings.
Table of Contents, Accessories Getting Started Precautions ...2 IMPORTANT SAFETY INSTRUCTIONS ...3 Unit Care ...3 Accessories ...5 Remote Control Information ...5 Control Reference Guide ...6 Main Unit ...6 Remote Control ...6 Rear Panel ...7 The Unit’s Display ...7 Media Handling ...7 Inserting Discs ...7 Inserting an SD Card ...7 Inserting USB memory ...7...
For use with this unit only. Do not use it with other equipment. Also, do not use cords for other equipment with this unit. Product Registration Card Please complete and return the included product registration card, or register via the Internet at: http://www.prodreg.com/panasonic/ Remote Control Information About batteries •...
Control Reference Guide Main Unit Disc tray POWER on/off button (POWER ^ /I) ... (➔ 10) • Press to switch the unit from on to standby mode or vice versa. In the standby mode, the unit is still consuming a small amount of power.
Rear Panel AC IN COMPONENT VIDEO OUT R-AUDIO-L AC IN~ = Power supply Cooling fan AUDIO/VIDEO input terminal ... (➔ 8) S VIDEO input terminal Set Top Box Control terminal ... (➔ 8) Digital audio output terminal ... (➔ 53) HDMI AV OUT terminal ...
Basic Connection Connecting to a Television and a Set Top Box • Consult your set top box provider about the appropriate Set Top Box to use. • Additional coaxial cable and audio/video (AV) cable are required. Note: The terminals on the rear of your TV and Set Top Box may not appear as shown below. Please read terminal labels carefully to ensure correct connections.
HDTV (High Definition Television), the output can be switched to 1080p, 1080i or 720p HD video. Regarding “HDAVI Control” function When connecting with a Panasonic TV (VIERA) or a receiver equipped with “HDAVI Control” function, linked operations are possible. [➔ 30, Linked Operations with the TV (VIERA Link™ “HDAVI Control™”)] Please use HIGH SPEED HDMI cables that have the HDMI logo (as shown on the cover).
You don’t need to make these settings again. to turn the unit on. • When this unit is connected to a Panasonic TV (VIERA) supporting HDAVI Control 3 via an HDMI cable (➔ 9), it acquires the setting information from the TV. When the Quick Start Setting screen appears (➔...
Page 11
Start Set Top Box Control testing. Please input the channel number for testing. Use either numbered buttons or UP/DOWN Cursors. Channel : STB Type: Cable Box/DVR Brand Name: Panasonic Max. CH digits: 3 Digit OK Key Operation: On ○○ IR Code: Number STB (Set Top Box) IR Settings Completed testing the / IR codes.
RQT9048 Acquiring the setting information from the TV (VIERA) If this unit is connected to a Panasonic TV (VIERA) supporting HDAVI Control 3 via an HDMI cable, then Set Clock Manually the setting information on the TV is acquired by this unit when the unit is turned on for the first time.
Playback Preparation: • Turn on the television and select the appropriate video input to suit the connections to this unit (Example: AV input). Playing Discs Refer to “Advanced Playback” ( 23, 24) for detailed information on playback. ➔ RAM -R -R DL -RW(V) +R +R DL +RW DVD-V -RW(VR) CD to turn the unit on.
Recording Set Top Box Programs Refer to “Important Notes for Recording” ( recording. RAM -R -R DL -RW(V) +R +R DL +RW Preparation: • Turn on the television and select the appropriate video input to suit the connections to this unit (Example: AV input). •...
Scheduled Recording Refer to “Advanced Scheduled Recording” (➔ 20) for detailed information on scheduled recording. RAM -R -R DL -RW(V) +R +R DL +RW Preparation: • Turn on the television and select the appropriate video input to suit the connections to this unit (Example: AV input). •...
Deleting Recordings Important: Once deleted, contents cannot be recovered. Preparation: • Turn on the television and select the appropriate video input to suit the connections to this unit (Example: AV input). • If the disc is protected, release protection (➔ 40). •...
We recommend you create the menu before playing a +RW disc on other equipment (➔ 41). DVD-RAM can be played back on Panasonic DVD recorders and DVD-RAM compatible DVD players. DVD-R DL and +R DL discs have two layers of recording surface on one side.
Advanced Recording Recording Modes and Estimated Disc Recording Time Recording Mode Single-sided (4.7 GB) XP (High quality) SP (Standard play) LP (Long play) EP (Extra long play) 8 (6* FR (Flexible Recording) 8 hours maximum *1 It is not possible to record or play continuously from one side of a double sided disc to the other.
Specifying the Recording Time RAM -R -R DL -RW(V) +R +R DL +RW This function allows specifying the length of recording time up to 4 hours. During recording repeatedly until the desired time is reached. – The recording time and the unit’s display change as follows: Counter (Cancel) OFF 0:30...
Advanced Scheduled Recording To cancel a scheduled recording in progress to select the DVD drive. – Confirmation screen appears. w to select “Stop recording”, then Notes Recording stops and ‘one-time’ programs are deleted from the Schedule List. Programs scheduled to record ‘Daily’ and ‘Weekly’ remain on the Schedule List and are set to begin at the next scheduled time.
Recording from an External Device Recording from a VCR or a Set top box equipped with a Hard Drive, etc. Connect cables while the power to both the unit and the external device is off. Front of the unit You can get a sharper, clearer picture by connecting with...
Recording from an External Device Recording from a DV Camcorder Connect the cable while the power to both the unit and the external device is off. Front of the unit DV IN RAM -R -R DL -RW(V) +R +R DL +RW Preparation: •...
Advanced Playback Zoom in on video During playback To zoom in: e , r to select “Zoom In”, then Tips To return the picture to its original size Press [ e , r ] to select “Zoom out” in step 2, then press [OK]. Menu Screens on the TV DVD-V Generally, menu screens that appear on the TV may be...
Advanced Playback Quick View (Play x1.3) Allows you to increase the play speed slightly without distorting the audio. During playback (Press and hold.) – Press again to return to normal speed. Slow-motion Play RAM -R -R DL -RW(V) +R +R DL +RW DVD-V -RW(VR) While paused –...
Playing MP3s -R -R DL CD USB The screen shown below may be displayed when you insert a USB memory (➔ 7). USB Media Device Operations USB Media Device inserted. Select an action or press RETURN to Exit. Play MP3 Go to Album View Copy pictures Press [ e , r ] to select “Play MP3”, then press [OK].
Playing Still Pictures (JPEG) RAM -R -R DL CD SD USB Still pictures (JPEG) recorded on DVD-RAM, DVD-R, DVD-R DL, CD- R/RW, SD Memory Cards or USB memory can be played on this unit. The screen shown below may be displayed when SD USB you insert an SD card or USB memory (➔...
Page 27
Slideshow with soundtrack It is possible to play MP3 music recorded on a USB memory during a Slideshow. Preparation: • Insert a USB memory containing MP3 files. From the Album View screen: e , r , w , q to select an album, then e , r to select “Slideshow w/ SNDTRK”,...
Playing Playlists RAM -RW(VR) You cannot create or edit playlists on this unit. However, you can play a playlist that has been created or edited on other equipment. to select the DVD drive. With the unit stopped e , r to select “Other Functions”, then e , r to select “Playlists”, then e , r , w , q to select the playlist...
Entering Text When viewing the Name screen. Recording Name Delete " Space e , r , w , q to select characters, then – Repeat this step to enter other characters. when you’ve fi nished entering text. Tips Using the numbered buttons to enter characters e.g.: entering the letter “R”...
Depending on discs, the TV may not automatically turn on. Notes • When this unit is connected to a Panasonic TV (VIERA) supporting HDAVI Control 3 and initially set up, it automatically acquires the TV setting information (➔ 12). •...
Easy Control only with VIERA Remote Control If you connect this unit via HDMI cable to a TV with “HDAVI Control 2 or 3” function with, you can operate both units more conveniently. You can operate this unit using the following buttons on the TV remote control. [ e , r , w , q ], [OK], [RETURN], [SUB MENU].
Recordings-Editing Tips • Recording/Chapter Normally, programs are recorded as a single item consisting of one chapter. Recording Chapter Start You can divide a recording into multiple chapters. Recording Chapter Chapter Chapter After finalizing, recordings are divided into chapters of the following lengths.
Setup Protection / Cancel Protection Perform steps 1−4 of “Accessing the Recording View” (➔ 32). Use to prevent accidental erasure of recordings. e , r to select “Setup Protection” or “Cancel Protection”, then w to select “Yes”, then The lock symbol DIRECT NAVIGATOR Recordings appears when the recording is protected.
Still Pictures-Editing Accessing the Album/Picture View RAM SD USB to select the drive (DVD, SD or USB). When the Recordings screen is displayed, press Album View screen. When MP3 Menu is displayed, perform steps 1–4 in “To select file type” on the upper Tips on page 25 selecting “Pictures”...
Only when you select “Create Album” w , q to select “Yes” or “No”, then • If “Yes” is selected: You can give a name for the album (➔ 29). • If “No” is selected: The recording date of the first picture in the album becomes the album name.
Copying Still Pictures Copying Still Pictures via the Album View Screen When you insert an SD card or USB memory, the menu may be displayed (➔ 7). Press [RETURN] to exit the screen. e.g., SD Card Operations SD Card inserted. Select an action or press RETURN.
Chapters-Creating, Editing Accessing the Chapter View Allows individual viewing and editing of chapters. to select the DVD drive. When the Album View screen is displayed, press Recordings screen. e , r , w , q to select a recording. to display the menu list. Delete Recording Properties Edit Recording...
Setting On-Screen Menus Accessing the On-Screen Menus When playing discs, disc settings can be displayed and changed. Menu options will differ based on disc type and contents. to select the DVD drive. Disc Soundtrack Play Subtitle Video Audio channel Audio Other Menu Item...
Video Menu RAM -R -R DL -RW(V) +R +R DL +RW DVD-V -RW(VR) Picture Set picture mode. Normal: Default setting Cinema: Mellows movies, enhances detail in dark scenes. DNR (Digital Noise Reduction) “On” reduces noise and picture degradation. Progressive*¹ (Progressive/24p*²) Select the method of conversion for progressive output to suit the type of material being played.
Page 40
DVD and Card Management Naming Discs RAM -R -R DL -RW(V) +R +R DL +RW Perform preparation steps 1−4 of “Accessing the Management Menus” (➔ 39). e , r select “Disc Name”, then – You can give a name for the disc (➔ 29). Tips •...
Page 41
Selecting Whether to Show the Top Menu -R -R DL -RW(V) +R +R DL +RW Before finalizing a disc, select whether the top menu shows after finalizing. Perform preparation steps 1−4 of “Accessing the Management Menus” (➔ 39). e , r to select “Playback will start with:”, then e , r to select desired item, then •...
Setup Menus “Accessing the Setup Menu” You will have to perform the following step 1 for all other operations on pages 42-49. With the unit stopped Notes Changed settings remain intact even when switching the unit to standby. Tips To return to the previous screen Press [RETURN].
Off Timer Select how long the unit remains on when it is not being used. Perform step 1 of “Accessing the Setup Menu” (➔ 42). e , r to select “Setup”, then q e , r to select “Off Timer”, then e , r to select “2 Hours”, “6 Hours”...
Setup Menus Settings for Playback Perform step 1 of “Accessing the Setup Menu” (➔ 42). e , r to select “Disc”, then q e , r to select “Settings for Playback”, then Ratings Set a ratings level to limit DVD-Video play. Follow the on-screen instructions.
e , r to select “Settings for Recording”, then e , r to select “EP-Extended Play (6H)” or “EP-Extended Play (8H)”, then [EP-Extended Play (6H)] You can record for 6 hours on an unused 4.7 GB disc. [EP-Extended Play (8H)] You can record for 8 hours on an unused 4.7 GB disc.
Setup Menus PCM Down Conversion Select how to output audio with a sampling frequency of 96 kHz or 88.2 kHz. Signals are converted to 48 kHz or 44.1 kHz despite the settings if the signals have a sampling frequency of over 96 kHz or 88.2 kHz, or the disc has copy protection.
Front Display Changes the brightness of the unit’s display. Perform step 1 of “Accessing the Setup Menu” (➔ 42). e , r to select “Display”, then q e , r to select “Front Display”, then e , r to select “Bright”, “Dim” or “Automatic”, then [Automatic] The display turns dark during playback.
, r to select “HDMI Resolution”, then e , r to select the item, then Automatically selects the output resolution best suited to the connected television (1080p, 1080i, 720p or 480p). recommend using a Panasonic HIGH SPEED HDMI cable to prevent video distortion.
Page 49
24p Output for DVD-Video* When this unit is connected to a TV supporting 1080/24p output via an HDMI cable, this unit displays each frame at 1/24 second intervals - the same interval originally shot with the film camera. After selecting “Functions of HDMI” (➔ 48, step 3). e , r to select “24p Output for DVD- Video”, then e , r to select “On”...
Some TVs and Set Top Boxes may not be compatible with the unit’s remote control. RQT9048 Remote Control Codes for the TV Manufacturer Panasonic 0051 / 0055 / 0250 / 0650 Advent 0761 / 0783 / 0815 / 0817 / 0842 Akai...
Adding a Video Cassette Recorder (VCR) • Additional coaxial cable and audio/video (AV) cable are required. Connecting to a Television, a Set Top Box and a VCR AUDIO IN VIDEO step Perform step Coaxial cable from the “RF OUT” on the Set Top Box to the “RF IN” on the VCR. Coaxial cable from the “RF OUT”...
Connection Options for Improved Playback Quality You can enjoy a high-quality picture by using the following terminals for connection. Standard Quality Picture VIDEO IN S VIDEO IN COMPONENT terminal terminal VIDEO IN terminal Using an S Video Cable for Better Video (S Video Cable not included) The S VIDEO OUT terminal achieves a more vivid picture than the VIDEO OUT terminal.
Regarding “HDAVI Control” function (➔ 30) • Please use HIGH SPEED HDMI cables that have the HDMI logo (as shown on the cover). It is recommended that you use Panasonic’s HDMI cable. Recommended part number: RP-CDHG10 (1.0 m/3.3 ft.), RP-CDHG15 (1.5 m/4.9 ft.), RP-CDHG20 (2.0 m/6.6 ft.),...
DVD-RW — +R DL — Finalization needed for playback on other equipment (➔ 41). can be played back on Panasonic DVD recorders and DVD- RAM compatible DVD players. can be played back only on equipment compatible -R DL +R DL with these discs.
• Please confirm the latest information on the following website. http://panasonic.co.jp/pavc/global/cs (This site is in English only.) • If the SD Card is formatted on other equipment, the time necessary for recording may be longer. Also, if the SD Card is formatted on a PC, you may not be able to use it on this unit.
USB memories you can use with this unit Standard Type File format symbol USB memory Still pictures (JPEG) ■ Compatible USB memories • USB memories which are defined as USB mass storage class, and digital cameras that use PTP protocol: –...
IN terminals ➔ HDMI IN terminal. The unit will take longer to start up when connected with the HDMI IN terminal. • All Panasonic TVs that have 480p input terminals are compatible. Consult the manufacturer if you have another brand of TV. •...
Recording Can I record from a • Most commercially sold video cassettes and DVDs are copy commercially purchased video protected; therefore, recording is usually not possible. cassette or DVD? Can DVD-R, DVD-R DL, • You can play these discs on compatible equipment such as DVD DVD-RW (DVD-Video format), players after finalizing the disc on this unit.
Error Messages On the Unit’s Display (“ ” stands for a service number.) (“ ” stands for a number.) HARD ERR (“HArd” and “Err” are alternately displayed.) NO READ (“NO” and “REAd” are alternately displayed.) FULL UNSUPPORT (“UNSUP” and “POrt” are alternately displayed.) UNFORMAT (“UNFOr”...
On the TV Cannot finish recording • completely. • • Cannot play. • Cannot record on the disc. • Unable to format. Please check the disc. Cannot record. Disc is full. • Cannot record. The number of recordings has exceeded the maximum limit.
Periodic interruptions to the reception due to satellite broadcasting breaks. • Operations not working due to a poor-quality disc. (Try again using a Panasonic disc.) • The unit freezing due to the activation of one of its safety devices (➔ above, To restore the unit if it freezes).
Operation General Issues Cannot operate the TV or Set • Make necessary settings for the Set Top Box Control. Top Box with the unit’s remote • Change the manufacturer code on the remote control. control. • Select TV or Set Top Box mode on the remote control. Cannot operate the DVD.
Troubleshooting Guide General Issues The contents of the USB memory cannot be read. Displays General Issues The display is dim. “12:00A” is flashing on the unit’s display. The recording time display, and the displayed recording times of MP3s are different from the actual time.
Picture Playback Issues TV reception worsens after • This can occur because the signals are being divided between the connecting the unit. unit and other equipment. It can be solved by using a signal booster, available from electronics retailers. The images from the unit do •...
Troubleshooting Guide Sound Playback Issues No sound. Low volume. Distorted sound. Cannot hear the desired audio type. Cannot switch audio. Operation Playback Issues Play fails to start even when [ q PLAY] is pressed. Play starts but then stops immediately. Audio and video momentarily pause.
• A DVD-R, DVD-R DL, DVD-RW (DVD-Video format), +R, +R DL, or +RW disc recorded on the unit may not be recordable on other Panasonic DVD recorders. • The broadcast you are trying to record is copy-protected. Recording does not stop even •...
Troubleshooting Guide Recording / Scheduled Recording / External Input (Continued) Recording Issues Cannot record video or sound from the external device. The DV Camcorder recording function does not work. DVD & SD Editing Issues Cannot format. Cannot create chapters. Cannot delete chapters. The available recording time doesn’t increase even after deleting recordings on the disc.
Glossary Bitstream This is a signal compressed and converted into digital form. It is converted back to a multi-channel audio signal, e.g., 5.1-channel, by a decoder. CPRM (Content Protection for Recordable Media) CPRM is technology used to protect broadcasts that are allowed to be recorded only once.
1-800-211-PANA (7262), Monday-Friday 9 am-9 pm; Saturday-Sunday 10 am-7 pm, EST. For hearing or speech impaired TTY users, TTY: 1-877-833-8855 Accessory Purchases Purchase Parts, Accessories and Instruction Books online for all Panasonic Products by visiting our Web Site at: http://www.pstc.panasonic.com or, send your request by E-mail to: npcparts@us.panasonic.com...
Referencia rápida en espanõl (Spanish Quick Reference) Conexión básica Nota: Puede que los terminales en el panel trasero de su TV y en el aparato integrando el convertidor y el descodificador no sean similares a como se ilustran a continuación. Por favor consulte las etiquetas de los terminales con atención para asegurar conexiones correctas.
Page 73
– esté correctamente configurado, Cuando esta unidad esté conectada a un televisor Panasonic (VIERA) que admita señales HDAVI Control 3 y esté correctamente configurado, esté automáticamente recopilará la información de configuración del televisor. Siga los mensajes que le aparecerán en pantalla.
Page 74
Referencia rápida en espanõl (Spanish Quick Reference) Ajuste manual del reloj: w , q para seleccionar el elemento que desea cambiar. e , r para cambiar el ajuste. – Repita los pasos 10-11 para cambiar los demás elementos. para confirmar una nueva fecha y hora.
Page 75
Grabación programada RAM -R -R DL -RW(V) +R +R DL +RW Preparación: • Si el disco está protegido, libere la protección. • Inserte un disco con suficiente espacio disponible. • Confirme que el reloj en el visualizador de la unidad está ajustado con la hora correcta. e , r para seleccionar “Nueva grabación programada”, y luego w , q para desplazarse a través de los...
