Read this manual carefully before operating this vehicle.
q
OWNER'S MANUAL
MTN1000
B67-28199-E4

Advertisement

Table of Contents
loading

Related Manuals for Yamaha MT-10 2019

Summary of Contents for Yamaha MT-10 2019

  • Page 1 Read this manual carefully before operating this vehicle. OWNER’S MANUAL MTN1000 B67-28199-E4...
  • Page 2 For Europe Declaration of Conformity: Hereby, YAMAHA MOTOR ELECTRONICS Co., Ltd declares that the radio equipment type, IMMOBILIZER, 1MC-00 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://global.yamaha-motor.com/eu_doc/...
  • Page 3 Welcome to the Yamaha world of motorcycling! As the owner of the MTN1000, you are benefiting from Yamaha’s vast experience and newest technology regarding the de- sign and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.
  • Page 4 Important manual information EAU10134 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
  • Page 5 Important manual information EAU10201 MTN1000 OWNER’S MANUAL ©2020 by Yamaha Motor Co., Ltd. 1st edition, August 2019 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd. is expressly prohibited. Printed in Japan.

  • Page 6: Table Of Contents

    Table of contents Safety information ......1-1 Adjusting the front fork ....4-22 Engine oil ........7-10 Adjusting the shock absorber Why Yamalube ......7-14 Description ........2-1 assembly........4-24 Coolant ........7-14 Left view ......... 2-1 Luggage strap holders ....4-27 Air filter element......
  • Page 7 Table of contents Checking and lubricating the sidestand........7-27 Lubricating the swingarm pivots......... 7-27 Checking the front fork ....7-28 Checking the steering....7-28 Checking the wheel bearings ..7-29 Battery .......... 7-29 Replacing the fuses ...... 7-30 Vehicle lights ........ 7-33 Supporting the motorcycle....

  • Page 8: Safety Information

    Safety information EAU1028C Take a training course. Beginners • Use extra caution when you are should receive training from a cer- approaching passing tified instructor. Contact an autho- through intersections, since in- Be a Responsible Owner rized motorcycle dealer to find out tersections are the most likely As the vehicle’s owner, you are respon- about the training courses nearest...
  • Page 9 Safety information tice riding your motorcycle with both hands and keep both control levers, footrests, or wheels where there is no traffic until you feet on the passenger footrests. and cause injury or an accident.  have become thoroughly famil- Never carry a passenger unless Always wear protective clothing iar with the motorcycle and all of...
  • Page 10 Yamaha accessories, which are avail- to minimize imbalance or instabili- of the motorcycle is changed. To avoid able only from a Yamaha dealer, have the possibility of an accident, use ex- been designed, tested, and approved ...
  • Page 11 Yamaha, even if sold and limit suspension travel, steering not recommended.  installed by a Yamaha dealer.
  • Page 12 Safety information  Check that the fuel cock (if equipped) is in the off position and that there are no fuel leaks.  Shift the transmission into gear (for models with a manual transmis- sion).  Secure motorcycle with tie-downs or suitable straps that are attached to solid parts of the motorcycle, such as the frame or upper front fork triple clamp (and...

  • Page 13: Description

    Description EAU10411 Left view 2, 3, 4 6, 7 1. Headlight (page 7-33) 9. Rebound damping force adjuster (page 4-24) 2. Spring preload adjuster (page 4-22) 10.Shift pedal (page 4-16) 3. Rebound damping force adjuster (page 4-22) 11.Engine oil level check window (page 7-10) 4.

  • Page 14: Right View

    Description EAU10421 Right view 4, 5, 6 1. Fuses (page 7-30) 9. Brake pedal (page 4-17) 2. Tool kit (page 7-2) 10.Rear brake fluid reservoir (page 7-22) 3. Fuel tank cap (page 4-18) 4. Spring preload adjuster (page 4-22) 5. Rebound damping force adjuster (page 4-22) 6.

  • Page 15: Controls And Instruments

    Description EAU10431 Controls and instruments 1. Clutch lever (page 4-16) 9. Brake lever (page 4-16) 2. Left handlebar switches (page 4-3) 3. Auxiliary DC jack (page 4-27) 4. Main switch/steering lock (page 4-2) 5. Multi-function meter unit (page 4-8) 6. Front brake fluid reservoir (page 7-22) 7.

  • Page 16: Special Features

    Special features EAU74041 switch “ ” located on the left han- Cruise control system dlebar. The cruise control system This model is equipped with a cruise indicator light “ ” will come on. control system designed to maintain a 2. Push the “SET–” side of the cruise set cruising speed.
  • Page 17 Special features new cruising speed by pushing the Push the power switch to turn off the to use the resume function until a new “SET–” side of the setting switch. If you cruise control system. The “ ” indica- cruising speed has been set. do not set a new cruising speed, when tor light and the “SET”...

  • Page 18: D-Mode (Drive Mode)

    Special features When not traveling with a set cruising curs, the setting switch cannot be EAU74053 D-mode (drive mode) speed, if the start/engine stop switch is used to adjust the set cruising D-mode is an electronically-controlled set to the “ ”...

  • Page 19: Traction Control System

    Special features EAU73914 Traction control system  The current drive mode is shown in The traction control system (TCS) the drive mode display (page helps maintain traction when accelerat- 4-11). ing on slippery surfaces, such as un-  The current drive mode is saved paved or wet roads.
  • Page 20 Special features system off. hicle gets stuck in mud, sand, or other soft surfaces. TCS “1” ECA16801 TCS “1” minimizes traction control sys- NOTICE tem assist. Select this mode for sporty Use only the specified tires. (See riding. page 7-17.) Using different sized tires will prevent the traction control TCS “2”...

  • Page 21: Quick Shift System

    Yamaha dealer check the vehicle as soon as possible. The quick shift system operates when 4. Have a Yamaha dealer check the traveling at least 20 km/h (12 mi/h) with vehicle and turn off the “...

  • Page 22: Instrument And Control Functions

    When necessary, take the vehi- placed. Therefore, handle the keys cle along with all three keys to a carefully. Yamaha dealer to have them re-regis- Do not submerse in water.  tered. Do not expose to high tempera- ...

  • Page 23: Main Switch/Steering Lock

    Instrument and control functions EAU10474 cense plate light and auxiliary light To lock the steering Main switch/steering lock come on, and the engine can be start- ed. The key cannot be removed. The headlights come on automatically when the engine is started and stay on until the key is turned to “OFF”, even if the engine stalls.

  • Page 24: Handlebar Switches

    Instrument and control functions Right To unlock the steering EAU66055 Handlebar switches Left 1. Stop/Run/Start switch “ ” 1. Push. 2. Drive mode switch “MODE” 2. Turn. 3. Hazard switch “ ” 1. Select switch “SELECT” From the “LOCK” position, push the 2.
  • Page 25 Instrument and control functions EAU66040 tle cable is stuck. display of the multi-function meter unit. Turn signal switch “ ” (See page 4-8.) To signal a right-hand turn, push this EAU66010 Hazard switch “ ” switch to “ ”. To signal a left-hand EAU73931 Drive mode switch “MODE”...

  • Page 26: Indicator Lights And Warning Lights

    EAU11081 High beam indicator light “ ” gine off and have a Yamaha dealer check the vehicle. 1. Engine trouble warning light “ ” This indicator light comes on when the 2.
  • Page 27 Do not continue to operate the en- light does not go off after traveling 10 gine if it is overheating. km/h (6 mi/h), have a Yamaha dealer When the vehicle is turned on, these check the vehicle. lights should come on for a few sec- onds and then go off.
  • Page 28 3 keys to a Yamaha If the indicator light does not come on dealer to have the standard keys EAU74091 initially when the key is turned to “ON”,...

  • Page 29: Multi-Function Meter Unit

    Instrument and control functions accident. EAU79183 Multi-function meter unit multi-function meter unit equipped with the following:  a speedometer  a tachometer  a clock  a fuel meter  a coolant/air temperature display  an eco indicator  a transmission gear display 1.
  • Page 30 Instrument and control functions Speedometer The tachometer allows the rider to To set the clock monitor the engine speed and keep it 1. Turn the key to “ON”. within the ideal power range. 2. Push the “CLOCK” button for two When the key is turned to “ON”, the ta- seconds.
  • Page 31 If a problem is detected in the electrical circuit, the fuel level segments and “ ” will flash repeatedly. If this occurs, have a Yamaha dealer check the vehicle. 1. Coolant temperature display 1. Air temperature display Coolant/Air temperature display...
  • Page 32 Instrument and control functions Eco indicator Transmission gear display This display indicates which drive mode has been selected: “1”, “2” or “3”. For more details on the modes and on how to select them, see page 3-3. TCS display 1. Eco indicator “ECO” 1.
  • Page 33  screen brightness and shift indica- available. Have a Yamaha dealer ODO  TRIP 1  TRIP 2  km/L or tor light control mode check the vehicle.
  • Page 34 Instrument and control functions Instantaneous fuel consumption starts flashing, the display automatical- shown. mode ly changes to the fuel reserve tripmeter To switch between the “km/L” and mode “TRIP F” and starts counting the “L/100 km”, push the “CLOCK” and distance traveled from that point.
  • Page 35 Instrument and control functions Brightness and shift indicator light  “AVE – –.– km/L”: The average This function allows you to select control mode distance that can be traveled on the engine speed at which the indi- 1.0 L of fuel is shown. cator light will be deactivated.
  • Page 36 Instrument and control functions  On - the indicator light will come vating the indicator light. To adjust the brightness of the shift in- on when activated. (This setting 2. Push the “CLOCK” button to con- dicator light is selected when the indicator firm the selected engine speed.

  • Page 37: Clutch Lever

    Instrument and control functions EAU12822 EAU76301 EAU26826 Clutch lever Shift pedal Brake lever 1. Clutch lever 1. Shift pedal 1. Match mark 2. Brake lever position adjusting dial The clutch lever is located on the left The shift pedal is located on the left 3.

  • Page 38: Brake Pedal

    Instrument and control functions the brake lever. EAU12944 EAU63040 Brake pedal The Yamaha ABS (Anti-lock Brake System) features a dual electronic con- trol system, which acts on the front and rear brakes independently. Operate the brakes with ABS as you would conventional brakes.

  • Page 39: Fuel Tank Cap

    However, special tools are it 1/4 turn clockwise. The lock will be re- required, so please consult your leased and the fuel tank cap can be Yamaha dealer. opened. ECA20100 To close the fuel tank cap NOTICE 1.

  • Page 40: Fuel

    Instrument and control functions less the key is in the lock. In addition, EAU13222 Fuel the key cannot be removed if the cap is Make sure there is sufficient gasoline in not properly closed and locked. the tank. EWA11092 EWA10882 WARNING WARNING Make sure that the fuel tank cap is...
  • Page 41 ECA11401 same identifier when fueling. NOTICE Use only unleaded gasoline. The use Your Yamaha engine has been de- of leaded gasoline will cause severe signed to use premium unleaded gaso- damage to internal engine parts, line with a research octane number of such as the valves and piston rings, 95 or higher.

  • Page 42: Fuel Tank Overflow Hose

    Instrument and control functions pairable damage to the catalytic EAU72972 EAU13434 Fuel tank overflow hose Catalytic converter converter. This model is equipped with a catalytic converter in the exhaust system. EWA10863 WARNING The exhaust system is hot after op- eration. To prevent a fire hazard or burns: Do not park the vehicle near ...

  • Page 43: Seat

    Instrument and control functions EAU57992 EAU70412 Seat Adjusting the front fork This model is equipped with adjustable To remove the seat suspension. The spring preload, re- 1. Open the seat lock cover, insert bound damping force, and compres- the key into the seat lock, and then sion damping force of each leg can be turn the key counterclockwise.
  • Page 44 Instrument and control functions and thereby soften the suspension, en the rebound damping, turn the and thereby soften the compression turn the adjusting nut on each fork in di- adjusting bolt on each fork leg in direc- damping, turn the adjusting bolt on rection (b).

  • Page 45: Adjusting The Shock Absorber Assembly

    Instrument and control functions may turn or click beyond the stated EAU74241 distance A is, the lower the spring Adjusting the shock absorber minimum settings, such adjust- preload. assembly  ments are ineffective and may Use the special wrench includ- damage the suspension.
  • Page 46 Instrument and control functions by soften the compression damping, Spring preload: turn the adjusting bolt in direction (b). Minimum (soft): Distance A = 77.5 mm (3.05 in) Standard: Distance A = 81.5 mm (3.21 in) Maximum (hard): Distance A = 85.5 mm (3.37 in) 3.
  • Page 47 Instrument and control functions absorber assembly to a Yamaha the compression damping force and may be the same. dealer for any service.  thereby soften the compression damp- Although a damping force adjuster ing, turn the adjusting screw in direction may turn or click beyond the stated (b).

  • Page 48: Luggage Strap Holders

    EAU67050 EAU49454 Luggage strap holders EXUP system Auxiliary DC jack This model is equipped with Yamaha’s EXUP (EXhaust Ultimate Power valve) system. This system boosts engine power by means of a valve that controls exhaust flow within the exhaust cham- ber.

  • Page 49: Sidestand

    Instrument and control functions Yamaha dealer repair it if it does not 3. Turn the accessory off. EAU15306 Sidestand function properly. 4. Insert the accessory plug into the The sidestand is located on the left side auxiliary DC jack. of the frame. Raise the sidestand or lower it with your foot while holding the vehicle upright.

  • Page 50: Ignition Circuit Cut-Off System

    Instrument and control functions EAU57952 Ignition circuit cut-off system This system prevents in-gear engine starts unless the clutch lever is pulled and the sidestand is up. Also, it will stop the running engine should the sides- tand be lowered while the transmission is in gear.
  • Page 51 The neutral switch may not be working. 6. Move the sidestand up. The motorcycle should not be ridden until 7. Pull the clutch lever. checked by a Yamaha dealer. 8. Shift transmission into gear. 9. Move the sidestand down. Does the engine stall? The sidestand switch may not be working.

  • Page 52: For Your Safety - Pre-Operation Checks

    • If necessary, add recommended coolant to specified level. 7-14 • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary.
  • Page 53 • Make sure that operation is smooth. • Check throttle grip free play. Throttle grip 7-16, 7-25 • If necessary, have Yamaha dealer adjust throttle grip free play and lubricate cable and grip housing. • Make sure that operation is smooth. Control cables 7-25 •...
  • Page 54 For your safety – pre-operation checks ITEM CHECKS PAGE Instruments, lights, signals • Check operation. — and switches • Correct if necessary. • Check operation of ignition circuit cut-off system. Sidestand switch 4-28 • If system is not working correctly, have Yamaha dealer check vehicle.

  • Page 55: Operation And Important Riding Points

     a lean angle sensor. This sensor  understand, ask your Yamaha dealer. The transmission is in the neutral stops the engine in case of a vehi- EWA10272 position.

  • Page 56: Shifting

    ( ), press the light should come on. If not, ask a shift pedal down repeatedly until it Yamaha dealer to check the elec- reaches the end of its travel, and trical circuit. then slightly raise it. 3. Start the engine by pushing the ...

  • Page 57: Tips For Reducing Fuel Consumption

    Operation and important riding points ECA23990 EAU16811 EAU16842 Tips for reducing fuel Engine break-in NOTICE consumption There is never a more important period Even with the transmission in  in the life of your engine than the period the neutral position, do not Fuel consumption depends largely on between 0 and 1600 km (1000 mi).

  • Page 58: Parking

    Do not park on a slope or on soft  Yamaha dealer check the vehi- ground, otherwise the vehicle cle. may overturn, increasing the risk of a fuel leak and fire.

  • Page 59: Periodic Maintenance And Adjustment

    – possibly leading to any repair establishment or individual pending on the weather, terrain, geo- death. See page 1-2 for more in- that is certified (if applicable). Yamaha graphical location, and individual use, dealers are trained and equipped to formation about carbon monox- the maintenance intervals may need to perform these particular services.

  • Page 60: Tool Kit

    Periodic maintenance and adjustment EAU73411 ence required for a particular job, have Tool kit your Yamaha dealer perform it for you. 1. Tool kit The tool kit is located on the bottom of the seat. (See page 4-22.) Also, an additional tool kit was handed out separately at the time of vehicle purchase.

  • Page 61: Periodic Maintenance Charts

    EAU71033 Periodic maintenance charts  Items marked with an asterisk should be performed by your Yamaha dealer because these items require special tools, data, and technical skills.  From 50000 km (30000 mi), repeat the maintenance intervals starting from 10000 km (6000 mi).
  • Page 62 Periodic maintenance and adjustment ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) • Check the air cut-off valve, reed Air induction valve, and hose for damage.

  • Page 63: General Maintenance And Lubrication Chart

    (24000 mi) • Perform dynamic inspection using Diagnostic system       Yamaha diagnostic tool. check • Check the error codes. 2 * Air filter element • Replace. Every 40000 km (24000 mi) • Check operation. Clutch ...
  • Page 64 Periodic maintenance and adjustment ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) • Check chain slack, alignment and condition. Every 1000 km (600 mi) and after washing the motorcycle, riding in the rain or Drive chain •...
  • Page 65 Periodic maintenance and adjustment ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) Rear suspension relay arm and 24 * ...
  • Page 66 Periodic maintenance and adjustment EAU72800  Air filter • This model’s air filter is equipped with a disposable oil-coated paper element, which must not be cleaned with com- pressed air to avoid damaging it. • The air filter element needs to be replaced more frequently when riding in unusually wet or dusty areas. ...

  • Page 67: Checking The Spark Plugs

    Do not attempt to diagnose wipe off any grime from the spark plug such problems yourself. Instead, have threads. a Yamaha dealer check the vehicle. Tightening torque: If a spark plug shows signs of electrode Spark plug (new): erosion and excessive carbon or other 18 N·m (1.8 kgf·m, 13 lb·ft)

  • Page 68: Canister

    Periodic maintenance and adjustment EAU36112 lowing: EAU73973 Canister Engine oil  Check each hose connection. The engine oil level should be checked  Check each hose and canister for before each ride. In addition, the oil cracks or damage. Replace if dam- must be changed and the oil filter car- aged.
  • Page 69 Periodic maintenance and adjustment rial enters the crankcase. 5. Check the O-ring for damage, and replace if necessary. 6. Install the engine oil filler cap. To check the engine oil level 1. After warming up the engine, wait To change the engine oil (and filter) a few minutes for the oil level to 1.
  • Page 70 Skip steps 4–6 if the oil filter cartridge is An oil filter wrench is available at a seated. not being replaced. Yamaha dealer. 6. Install a new oil filter cartridge, and 4. Remove the oil filter cartridge with 5. Apply a thin coat of clean engine then tighten to the specified an oil filter wrench.
  • Page 71 ECA20860 NOTICE If the oil pressure warning light flick- ers or remains on even if the oil level is correct, immediately turn the en- gine off and have a Yamaha dealer 7-13...

  • Page 72: Why Yamalube

    3. If the coolant is at or below the standards. Thus, Yamalube mineral, minimum level mark, remove the If genuine Yamaha coolant is not avail- semisynthetic and synthetic oils have coolant reservoir cap. WARNING! able, use an ethylene glycol antifreeze their own distinct characters and value.

  • Page 73: Air Filter Element

    EAU33032 Changing the coolant maintenance and lubrication chart. The coolant must be changed at the in- Have a Yamaha dealer replace the air tervals specified in the periodic mainte- filter element. nance and lubrication chart. Have a Yamaha dealer change the coolant.

  • Page 74: Checking The Engine Idling Speed

    This service must be performed when 1. Throttle grip free play the engine is cold. Throttle grip free play: 3.0–5.0 mm (0.12–0.20 in) Periodically check the throttle grip free play and, if necessary, have a Yamaha dealer adjust it. 7-16...

  • Page 75: Tires

    Operation of this vehicle with im- combined weight of the rider, passen- cracked, have a Yamaha dealer re- ger, cargo, and any accessories. proper tire pressure may cause se- place the tire immediately.
  • Page 76 EWA10472 WARNING characteristics of the motorcy- cle may be different, which Have a Yamaha dealer replace  could lead to an accident. excessively worn tires. Besides Always make sure that the valve being illegal, operating the vehi- ...

  • Page 77: Cast Wheels

    Other tires may run for cracks, bends, warpage or oth- the danger of bursting at super er damage before each ride. If any damage is found, have a Yamaha high speeds. dealer replace the wheel. Do not Brand-new tires can have a rela- ...

  • Page 78: Checking The Brake Lever Free Play

    There should be no free play at the (b). brake lever end. If there is free play, have a Yamaha dealer inspect the brake system. EWA14212 WARNING A soft or spongy feeling in the brake lever can indicate the presence of air in the hydraulic system.

  • Page 79: Brake Light Switches

    Periodic maintenance and adjustment EAU36505 EAU22393 touches the brake disc, have a Yamaha Brake light switches Checking the front and rear dealer replace the brake pads as a set. brake pads The brake light should come on just be- fore braking takes effect. The brake...

  • Page 80: Checking The Brake Fluid Level

    LOWER lock.  If the brake fluid level goes down suddenly, have a Yamaha dealer check the cause before further rid- ing. EWA15991 WARNING Improper maintenance can result in 1.

  • Page 81: Changing The Brake Fluid

    EAU22734 EAU22762 Changing the brake fluid Drive chain slack Have a Yamaha dealer change the The drive chain slack should be brake fluid every 2 years. In addition, checked before each ride and adjusted have the seals of the master cylinders if necessary.

  • Page 82: Cleaning And Lubricating The Drive Chain

    Periodic maintenance and adjustment 1. Loosen the axle nut and the lock- EAU23026 Cleaning and lubricating the nut on each side of the swingarm. drive chain 2. To tighten the drive chain, turn the drive chain slack adjusting bolt on The drive chain must be cleaned and each side of the swingarm in direc- lubricated at the intervals specified in...

  • Page 83: Checking And Lubricating The Cables

    Yamaha dealer at the intervals speci- ed if necessary. If a cable is damaged fied in the periodic maintenance chart.

  • Page 84: Checking And Lubricating The Brake And Shift Pedals

    Periodic maintenance and adjustment Shift pedal EAU44276 EAU23144 Checking and lubricating the Checking and lubricating the brake and shift pedals brake and clutch levers The operation of the brake and shift The operation of the brake and clutch pedals should be checked before each levers should be checked before each ride, and the pedal pivots should be lu- ride, and the lever pivots should be lu-...

  • Page 85: Checking And Lubricating The Sidestand

    The operation of the sidestand should The swingarm pivots must be lubricat- Clutch lever: be checked before each ride, and the ed by a Yamaha dealer at the intervals Lithium-soap-based grease sidestand pivot and metal-to-metal specified in the periodic maintenance contact surfaces should be lubricated if and lubrication chart.

  • Page 86: Checking The Front Fork

    [EWA10752] have a Yamaha dealer check or re- tion. WARNING! To avoid injury, 2. Hold the lower ends of the front pair it. securely support the vehicle so...

  • Page 87: Checking The Wheel Bearings

    WARNING To charge the battery Electrolyte is poisonous and  Have a Yamaha dealer charge the bat- dangerous since it contains sul- tery as soon as possible if it seems to furic acid, which causes severe have discharged. Keep in mind that the burns.

  • Page 88: Replacing The Fuses

    Periodic maintenance and adjustment the main switch off, then con- battery tends to discharge more quickly EAU73994 Replacing the fuses nect the positive lead before if the vehicle is equipped with optional connecting negative The main fuse and ABS motor fuse are electrical accessories.
  • Page 89 Periodic maintenance and adjustment el B off. 1. Starter relay cover 1. Quick fastener 2. Left side panel A 1. Left side panel B The fuse boxes, which contain the fus- 2. Washer es for the individual circuits, are located 3.
  • Page 90 Periodic maintenance and adjustment If a fuse is blown, replace it as follows. 1. Ignition fuse 1. ABS solenoid fuse 1. Turn the key to “OFF” and turn off 2. Signaling system fuse 2. Fuel injection system fuse the electrical circuit in question. 3.

  • Page 91: Vehicle Lights

    7.5 A bulbs. ABS ECU fuse: 7.5 A If a light does not come on, check the ABS solenoid fuse: fuses and then have a Yamaha dealer 10.0 A check the vehicle. Fuel injection system fuse: ECA16581 15.0 A NOTICE...

  • Page 92: Supporting The Motorcycle

    1. Maintenance stand (example) self. However, should your motorcycle require any repair, take it to a Yamaha Since this model is not equipped with a dealer, whose skilled technicians have centerstand, use maintenance stands...

  • Page 93: Troubleshooting Charts

    Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the compression. 4. Compression The engine does not start. There is compression.
  • Page 94 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended coolant as soon as possible.

  • Page 95: Motorcycle Care And Storage

    Be performance and extend the useful life high-pressure washers  sure to consult a Yamaha dealer for of many components. Washing, clean- steam-jet cleaners. Excessive advice on what products to use be- ing, and polishing will also give you a water pressure may cause water fore cleaning the vehicle.
  • Page 96 Motorcycle care and storage gasoline, rust removers, brake to do the job. Avoid spraying water 4. Rinse off thoroughly with clean wa- fluid, or antifreeze, etc. directly into the muffler, instrument ter. Be sure to remove all deter- panel, air inlet, or other inner areas gent residues, as they can be such as underseat storage com- harmful to plastic parts.
  • Page 97 Motorcycle care and storage operating the vehicle. EWA20660 ish. [EWA20650] WARNING 5. Treat rubber, vinyl, and unpainted Contaminants left on the brakes or plastic parts with a suitable care The thermally induced discoloring of tires can cause loss of control. product.

  • Page 98: Storage

    Motorcycle care and storage EAU83472 perform any outstanding mainte- into the spark plug bore. Storage nance. c. Install the spark plug cap onto Always store the vehicle in a cool, dry 2. Follow all instructions in the Care the spark plug, and then place place.
  • Page 99 Motorcycle care and storage the tires from becoming degraded in one spot. 9. Cover the muffler outlet with a plastic bag to prevent moisture from entering it. 10. Remove the battery and fully charge it, or attach a maintenance charger to keep the battery opti- mally charged.

  • Page 100: Specifications

    Specifications Dimensions: Fuel injection: EAU84922 Starting system: Electric starter Overall length: Throttle body: Engine oil: 2095 mm (82.5 in) ID mark: Overall width: Recommended brand: B671 00 Drivetrain: 800 mm (31.5 in) Overall height: Gear ratio: 1110 mm (43.7 in) 1st: Seat height: 2.600 (39/15)
  • Page 101 Specifications Loading: Rear turn signal light: Maximum load: Auxiliary light: 170 kg (375 lb) The vehicle's maximum load is the combined License plate light: weight of the rider, passenger, cargo and any accessories. Front brake: Type: Hydraulic dual disc brake Rear brake: Type: Hydraulic single disc brake...

  • Page 102: Consumer Information

    These identification numbers are needed when registering the vehicle with the authorities in your area and when ordering spare parts from a Yamaha dealer. VEHICLE IDENTIFICATION NUM- 1. Vehicle identification number 1. Engine serial number...

  • Page 103: Diagnostic Connector

    Yamaha dealer. Vehicle data uploaded will be handled appropriately according to the following Privacy Policy. Privacy Policy https://www.yamaha-motor.eu/eu/ privacy/privacy-policy.aspx Yamaha will not disclose this data to a third party except in the following cas- 10-2...
  • Page 104 Consumer information es. In addition, Yamaha may provide vehicle data to a contractor in order to outsource services related to the han- dling of vehicle data. Even in this case, Yamaha will require the contractor to properly handle the vehicle data we provided and Yamaha will appropriate- ly manage the data.

  • Page 105: Index

    Index Drive chain, cleaning and lubricating ..7-24 Maintenance and lubrication, periodic ..7-5 Drive chain slack ........7-23 Maintenance, emission control ABS ............4-17 Drive mode switch ........4-4 system ..........7-3 ABS warning light ........4-6 Matte color, caution ........ 8-1 Air filter element........
  • Page 106 Index Swingarm pivots, lubricating ....7-27 Throttle grip and cable, checking and lubricating ........7-25 Throttle grip free play, checking.... 7-16 Tires ............7-17 Titanium muffler, cleaning....... 8-3 Tool kit ............ 7-2 Traction control system......3-4 Traction control system indicator light..4-6 Traction control system switch....
  • Page 108 Original instructions PRINTED IN JAPAN 2019.08-0.1×1 !
