Summary of Contents for Yamaha MT-10

  • Page 1 Read this manual carefully before operating this vehicle. OWNER’S MANUAL MTN1000DH BW8-28199-20 0...
  • Page 2 EAU46093 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold.
  • Page 3 EAU10103 Welcome to the Yamaha world of motorcycling! As the owner of the MTN1000DH, you are benefiting from Yamaha’s vast experience and newest technology regarding the design and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.

  • Page 4: Important Manual Information

    Important manual information EAU10134 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
  • Page 5 Important manual information EAU10201 MTN1000DH OWNER’S MANUAL ©2016 by Yamaha Motor Co., Ltd. 1st edition, November 2016 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd. is expressly prohibited. Printed in Japan.

  • Page 6: Table Of Contents

    Valve clearance ......8-18 Ignition circuit cut-off system..5-37 Tires..........8-18 Special features ....... 4-1 Cast wheels ......... 8-20 YRC (Yamaha Ride Control) ..4-1 For your safety – pre-operation Adjusting the clutch lever free Glossary ......... 4-3 checks ..........6-1 play...........
  • Page 7 Table of contents Checking and lubricating the sidestand........8-28 Lubricating the swingarm pivots ... 8-29 Checking the front fork ....8-29 Checking the steering....8-30 Checking the wheel bearings ..8-30 Battery .......... 8-30 Replacing the fuses ...... 8-32 Vehicle lights ........ 8-35 Supporting the motorcycle....

  • Page 8: Location Of Important Labels

    Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label is available from your Yamaha dealer. 1, 2...
  • Page 9 Location of important labels STATIONARY NOISE TEST INFORMATION Use PREMIUM unleaded gasoline with min. 95 octane (RON). TESTED 95 dB(A) 5750 r/min 2S3-2817K-10 SILENCING SYSTEM : YAMAHA IDENTIFICATION : B67 B67-2118G-00 39R-00 9716 41R-04 9613 100kPa=1bar kPa,psi kPa,psi 53R-01 0736...

  • Page 10: Safety Information

    Safety information EAU1028B Take a training course. Beginners • Use extra caution when you are should receive training from a cer- approaching passing tified instructor. Contact an autho- through intersections, since in- Be a Responsible Owner rized motorcycle dealer to find out tersections are the most likely As the vehicle’s owner, you are respon- about the training courses nearest...
  • Page 11 Safety information tice riding your motorcycle with both hands and keep both control levers, footrests, or wheels where there is no traffic until you feet on the passenger footrests. and cause injury or an accident.  have become thoroughly famil- Never carry a passenger unless Always wear protective clothing iar with the motorcycle and all of...
  • Page 12 Yamaha accessories, which are avail- to minimize imbalance or instabili- of the motorcycle is changed. To avoid able only from a Yamaha dealer, have the possibility of an accident, use ex- been designed, tested, and approved ...
  • Page 13 Yamaha, even if sold and limit suspension travel, steering not recommended.  installed by a Yamaha dealer.
  • Page 14 Safety information  Check that the fuel cock (if equipped) is in the “OFF” position and that there are no fuel leaks.  Point the front wheel straight ahead on the trailer or in the truck bed, and choke it in a rail to pre- vent movement.

  • Page 15: Description

    Description EAU10411 Left view 2, 3 1. Headlight (page 8-35) 9. Fuse box (page 8-32) 2. ERS coupler (page 5-33) 3. Spring preload adjusting bolt (page 5-33) 4. Battery (page 8-30) 5. Spring preload adjusting ring (page 5-34) 6. Shift pedal (page 5-27) 7.

  • Page 16: Right View

    Description EAU10421 Right view 1, 2 5, 6 1. Main fuse (page 8-32) 9. Coolant drain bolt (page 8-14) 2. ABS motor fuse (page 8-32) 10.Brake pedal (page 5-28) 3. Owner’s tool kit (page 8-2) 11.Rear brake fluid reservoir (page 8-23) 4.

  • Page 17: Controls And Instruments

    Description EAU10431 Controls and instruments 1. Clutch lever (page 5-27) 9. Brake lever (page 5-27) 2. Left handlebar switches (page 5-3) 3. Auxiliary DC jack (page 5-36) 4. Main switch/steering lock (page 5-2) 5. Instrument panel (page 5-5, 5-8) 6. Front brake fluid reservoir (page 8-23) 7.

  • Page 18: Special Features

    EWA15432 YRC (Yamaha Ride Control) WARNING oughly familiar with the way the mo- Yamaha Ride Control is a system that torcycle handles with various YRC The traction control system is not a incorporates numerous sensors and settings before attempting more ad-...
  • Page 19 SCU which makes in- check the vehicle as soon as possible. Resetting the traction control sys- dependent adjustments of both the 4. Have a Yamaha dealer check the front and rear suspension’s compres- vehicle and turn off the “ ” warn-...

  • Page 20: Glossary

    TCS - Traction Control System 2. Cruise control system indicator light “ ” Improper use of the cruise con- YRC - Yamaha Ride Control trol system may result in loss of control, which could lead to an accident. Do not activate the...
  • Page 21 Special features dlebar. The cruise control system “SET–” side of the setting switch. If you Push the power switch to turn off the indicator light “ ” will come on. do not set a new cruising speed, when cruise control system. The “ ”...
  • Page 22 Special features to use the resume function until a new When not traveling with a set cruising curs, the setting switch cannot be cruising speed has been set. speed, if the start/engine stop switch is used to adjust the set cruising set to the “...

  • Page 23: Instrument And Control Functions

     a Yamaha dealer to have them re-reg- Do not place any key close to istered. Do not use the key with the red magnets (this includes, but not bow for driving.

  • Page 24: Main Switch/Steering Lock

    Instrument and control functions ference. EAU10474 cense plate light and auxiliary light Main switch/steering lock come on, and the engine can be start- ed. The key cannot be removed. The headlights come on automatically when the engine is started and stay on until the key is turned to “OFF”, even if the engine stalls.

  • Page 25: Handlebar Switches

    Instrument and control functions To lock the steering To unlock the steering EAU66054 Handlebar switches Left 1. Push. 1. Push. 2. Turn. 2. Turn. 1. Mode switch “MODE” 1. Turn the handlebars all the way to From the “LOCK” position, push the 2.
  • Page 26 Instrument and control functions Right leased, the switch returns to the center might be a traffic hazard. position. To cancel the turn signal ECA10062 NOTICE lights, push the switch in after it has re- turned to the center position. Do not use the hazard lights for an extended length of time with the en- EAU66030 gine not running, otherwise the bat-...

  • Page 27: Indicator Lights And Warning Lights

    Instrument and control functions only be turned off from the main Operate the wheel switch as follows. EAU4939C Indicator lights and warning screen. Select TCS, and then Rotate up - rotate the wheel upward to lights push and hold the select switch scroll up/left or increase a setting value.
  • Page 28 Turn signal indicator lights “ ” and The ABS may not work correctly. If any “ ” of the above occurs, have a Yamaha EAU79310 Each indicator light will flash when its dealer check the system as soon as Engine trouble warning light “...
  • Page 29 Shift timing indicator light go off. vehicle and all 3 keys to a Yamaha This indicator light can be set to come If the indicator light does not come on dealer to have the standard keys on and go off at the desired engine initially when the key is turned to “ON”,...

  • Page 30: Display

     Revolution peak hold indicator confirming the proper oil level,  Lap timer have a Yamaha dealer check the  Fuel level warning icon vehicle. Do not continue to op-  Oil pressure warning icon erate the vehicle! ...
  • Page 31 Instrument and control functions good contrast and readability in various TRACK MODE Speedometer lighting conditions. However, due to the The speedometer shows the vehicle’s nature of this technology, it is normal traveling speed. 12 : 00 for a small number of pixels to be inac- 1000 r/min ×...
  • Page 32 If all the fuel meter display segments  2. Short push the wheel switch and TRIP-1 and TRIP-2 will reset and flash repeatedly, have a Yamaha deal- the item will flash for five seconds. continue counting after 9999.9 has er check the related circuits.
  • Page 33 Instrument and control functions  “ ” and by the transmission gear dis- ting. When a YRC item is highlighted play “ ”. but cannot be adjusted, the YRC item box will return to black. To change YRC modes or make setting Revolution peak hold indicator changes This small bar momentarily appears...
  • Page 34 Instrument and control functions lap time (marked by the LATEST indi- vated, press the /LAP switch to Warning icons cator) for five seconds. start the lap timer.  12 : 00 The engine must be running to use 1000 r/min ×...

  • Page 35: Menu Screen

    Instrument and control functions Coolant temperature warning “ ” gine off and have a Yamaha dealer EAU79360 MENU screen This icon comes on if the coolant tem- check the vehicle. perature reaches 117 C or higher. 12 : 00 MENU km/h Stop the vehicle and turn off the engine.
  • Page 36 Instrument and control functions Turn the shift indicator 12 : 00 MENU on/off and adjust km/h Shift Indicator Should vehicle motion be detected, the tachometer settings. Display Mode screen will automatically exit MENU Set the multi-function YRC Setting Display Setting display window items.
  • Page 37 Instrument and control functions four modes MODE-A, control is desirable. 12 : 00 MENU km/h MODE-B, MODE-C, MODE-D by ad- Display Mode justing the setting levels (or on/off sta- TCS can only be turned on or off via the YRC Setting tus as applicable) of YRC items PWR, main screen.
  • Page 38 Instrument and control functions 12 : 00 YRC Setting There are two automatic setting km/h YRC Setting 12 : 00 km/h modes; A-1, and A-2. A-1 and A-2 can A - 1 A - 1 A - 2 be adjusted to within a -5 to +5 offset of A - 2 M - 1 their factory preset settings.
  • Page 39 Instrument and control functions 1. Select the “ ” mark located to the COM, Fr REB, Rr COM, Rr REB, right of ERS. that you want to adjust. YRC Setting 12:00 km/h 2. The display will change to the front (+ 0 ) (+ 0 ) rear...
  • Page 40 Instrument and control functions “Reset” allows you to delete the lap To reset the lap time record data time record data. 1. When “Lap Time” is selected, both 12 : 00 Lap Time GP GPS km/h “Display” and “Reset” are dis- Reset ? played.
  • Page 41 Instrument and control functions 12 : 00 12 : 00 MENU MENU km/h km/h 12 : 00 Maintenance km/h Display Mode Display Mode 0 km YRC Setting YRC Setting INTERVAL 1 123456 km LapTime LapTime INTERVAL 2 123456 km Maintenance Maintenance Unit Unit...
  • Page 42 Instrument and control functions 3. Select the background color (se- lect BLACK for a black background or WHITE for a white background). 4. Select the units you want to use. 1. Photo sensor 5. Select the triangle symbol to exit. To set the wallpaper “Wallpaper”...
  • Page 43 Instrument and control functions following items. Display Description Shift Indicator 12 : 00 Shift Indicator 12 : 00 km/h km/h 1000 r/min 1000 r/min Set the shift indicator × × pattern to “ON”, “Flash”, or Shift IND Shift IND Setting Shift IND Setting “OFF”...
  • Page 44 Instrument and control functions range is 5500–13000 r/min. The blue area on the tachometer indi- cates the currently set operational range of the shift indicator light. “Shift IND Brightness” The shift timing indicator light has six brightness levels. 1. Select “Tach IND Setting”. “Tach IND Setting”...
  • Page 45 Instrument and control functions value (or the red zone), will be dis- this figure until the red zone, will be played in green. displayed in orange. Shift Indicator 12 : 00 km/h 1000 r/min × Shift Indicator 12 : 00 km/h Tach IND Setting Orange...
  • Page 46 Instrument and control functions olution peak hold indicator on or off. information display items (like TRIP-1, To set the display groups 1. Select “Peak Rev IND Setting”. ODO, C. TEMP, etc.) are grouped on 1. Select “Display Setting”. the main screen. There are four display 12 : 00 MENU groups.
  • Page 47 Instrument and control functions 4. Select the STREET MODE 1-1. 7. Select the triangle symbol to exit. 2. Select the desired brightness level 5. Select the desired information dis- To set the other display groups, re- by rotating the wheel switch, and play item with the wheel switch.
  • Page 48 Instrument and control functions “Clock”. 4. The minutes figure will become 6. Short push the wheel switch again 2. When “Clock” is selected, the highlighted. to exit and go back to MENU hours figure will be highlighted. screen. “All Reset” This module contains the all reset func- tion which resets everything, except the odometer and clock, to its factory pre-...

  • Page 49: Clutch Lever

    Instrument and control functions EAU12822 EAU67010 EAU26825 Clutch lever Shift pedal Brake lever 1. Clutch lever 1. Shift pedal 1. “ ” mark 2. Brake lever position adjusting dial The clutch lever is located on the left The shift pedal is located on the left 3.

  • Page 50: Brake Pedal

    “ ” mark on the brake lever. EAU12944 EAU63040 Brake pedal The Yamaha ABS (Anti-lock Brake System) features a dual electronic con- trol system, which acts on the front and rear brakes independently. Operate the brakes with ABS as you would conventional brakes.

  • Page 51: Fuel Tank Cap

    However, special tools are it 1/4 turn clockwise. The lock will be re- required, so please consult your leased and the fuel tank cap can be Yamaha dealer. opened. ECA20100 To close the fuel tank cap NOTICE 1.

  • Page 52: Fuel

    Instrument and control functions EAU13222 Fuel The fuel tank cap cannot be closed un- Make sure there is sufficient gasoline in less the key is in the lock. In addition, the tank. the key cannot be removed if the cap is EWA10882 not properly closed and locked.

  • Page 53: Fuel Tank Overflow Hose

     Make sure that the end of the fuel Your Yamaha engine has been de- tank overflow hose is not blocked, signed to use premium unleaded gaso- and clean it if necessary.

  • Page 54: Catalytic Converter

    Instrument and control functions EAU13434 pairable damage to the catalytic EAU57991 Catalytic converter Seat converter. This model is equipped with a catalytic converter in the exhaust system. To remove the seat 1. Open the seat lock cover, insert EWA10863 WARNING the key into the seat lock, and then turn the key counterclockwise.

  • Page 55: Adjusting The Front Fork

    Instrument and control functions EAU67383 force. [ECA22770] Adjusting the front fork This model is is equipped with ÖHLINS electronic racing suspension. The compression and rebound damp- ing forces are electronically adjusted. (See ERS on page 5-16.) ECA22471 NOTICE  Use extra care to avoid scratch- ing the gold-anodized finish 1.

  • Page 56: Adjusting The Shock Absorber Assembly

    Instrument and control functions EAU67393 er the spring preload; the shorter Adjusting the shock absorber distance A is, the lower the spring assembly preload.  This model is is equipped with ÖHLINS Use the special wrench in the electronic racing suspension. owner’s tool kit to make the ad- The compression and rebound damp- justment.

  • Page 57: Luggage Strap Holders

    Take the shock locknut specified absorber assembly to a Yamaha 1. Luggage strap holder torque. dealer for any service. [ECA22760] There is a luggage strap holder on each Tightening torque: passenger footrest.

  • Page 58: Exup System

    Instrument and control functions EAU67050 EAU49453 EXUP system Auxiliary DC jack This model is equipped with Yamaha’s EWA14361 WARNING EXUP (EXhaust Ultimate Power valve) system. This system boosts engine To prevent electrical shock or power by means of a valve that controls...

  • Page 59: Sidestand

    Instrument and control functions EAU15306 Yamaha dealer repair it if it does not EAU57950 Sidestand Ignition circuit cut-off system function properly. The sidestand is located on the left side The ignition circuit cut-off system (com- of the frame. Raise the sidestand or...
  • Page 60 Instrument and control functions WARNING With the engine turned off: 1. Move the sidestand down. If a malfunction is noted, have a Yamaha 2. Make sure that the start/engine stop switch is set to “ ”. dealer check the system before riding.

  • Page 61: For Your Safety - Pre-Operation Checks

    • If necessary, add recommended coolant to specified level. 8-13 • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary.
  • Page 62 • Make sure that operation is smooth. • Check throttle grip free play. Throttle grip 8-17, 8-27 • If necessary, have Yamaha dealer adjust throttle grip free play and lubricate cable and grip housing. • Make sure that operation is smooth. Control cables 8-26 •...
  • Page 63 For your safety – pre-operation checks ITEM CHECKS PAGE Instruments, lights, signals • Check operation. — and switches • Correct if necessary. • Check operation of ignition circuit cut-off system. Sidestand switch 5-37 • If system is not working correctly, have Yamaha dealer check vehicle.

  • Page 64: Operation And Important Riding Points

     a lean angle sensor to stop the en-  understand, ask your Yamaha dealer. The transmission is in the neutral gine in case of a turnover. In this EWA10272 position.

  • Page 65: Shifting

    If not, ask a EAU67080 Shifting NOTICE Yamaha dealer to check the elec- trical circuit. If a warning or indicator light does 3. Start the engine by pushing the not come on initially when the key is “...

  • Page 66: Tips For Reducing Fuel Consumption

    Operation and important riding points the neutral position, do not EAU16811 EAU16842 Tips for reducing fuel Engine break-in coast for long periods of time consumption There is never a more important period with the engine off, and do not in the life of your engine than the period tow the motorcycle for long dis- Fuel consumption depends largely on between 0 and 1600 km (1000 mi).

  • Page 67: Parking

     Do not park on a slope or on soft Yamaha dealer check the vehi- ground, otherwise the vehicle cle. may overturn, increasing the risk of a fuel leak and fire.

  • Page 68: Periodic Maintenance And Adjustment

    – possibly leading to pending on the weather, terrain, geo- that is certified (if applicable). Yamaha death. See page 2-2 for more in- graphical location, and individual use, dealers are trained and equipped to...

  • Page 69: Owner's Tool Kits

    Periodic maintenance and adjustment EAU73410 ence required for a particular job, have Owner’s tool kits a Yamaha dealer perform it for you. 1. Owner’s tool kit The owner’s tool kit is located on the bottom of the seat. (See page 5-32.)

  • Page 70: Periodic Maintenance Chart For The Emission Control System

     From 50000 km (30000 mi), repeat the maintenance intervals starting from 10000 km (6000 mi).  Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills. EAU71051 Periodic maintenance chart for the emission control system...
  • Page 71 Periodic maintenance and adjustment ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) • Check the air cut-off valve, reed Air induction valve, and hose for damage.

  • Page 72: General Maintenance And Lubrication Chart

    (24000 mi) • Perform dynamic inspection using Diagnostic system       Yamaha diagnostic tool. check • Check the error codes. 2 * Air filter element • Replace. Every 40000 km (24000 mi) • Check operation.  ...
  • Page 73 Periodic maintenance and adjustment ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) • Check chain slack, alignment and condition. Every 1000 km (600 mi) and after washing the motorcycle, riding in the rain or Drive chain •...
  • Page 74 Periodic maintenance and adjustment ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) Rear suspension relay arm and   ...
  • Page 75 Periodic maintenance and adjustment EAU72800  Air filter • This model’s air filter is equipped with a disposable oil-coated paper element, which must not be cleaned with com- pressed air to avoid damaging it. • The air filter element needs to be replaced more frequently when riding in unusually wet or dusty areas. ...

  • Page 76: Checking The Spark Plugs

    Do not attempt to diagnose wipe off any grime from the spark plug such problems yourself. Instead, have threads. a Yamaha dealer check the vehicle. If a spark plug shows signs of electrode Tightening torque: Spark plug (new): erosion and excessive carbon or other 18 N·m (1.8 kgf·m, 13 lb·ft)

  • Page 77: Canister

    Periodic maintenance and adjustment EAU36112 lowing: EAU73971 Canister Engine oil and oil filter  Check each hose connection. cartridge  Check each hose and canister for cracks or damage. Replace if dam- The engine oil level should be checked aged. before each ride.
  • Page 78 An oil filter wrench is available at a oil of the recommended type to Yamaha dealer. raise it to the correct level. 5. Apply a thin coat of clean engine oil to the O-ring of the new oil filter To change the engine oil (and filter) cartridge.
  • Page 79 Periodic maintenance and adjustment Recommended engine oil: Full synthetic 10W-40 Oil quantity: Oil change: 3.90 L (4.12 US qt, 3.43 Imp.qt) With oil filter removal: 4.10 L (4.33 US qt, 3.61 Imp.qt) Be sure to wipe off spilled oil on any 1.

  • Page 80: Coolant

    3. If the coolant is at or below the gine off and have a Yamaha dealer minimum level mark, remove the  The coolant level must be checked check the vehicle.
  • Page 81 If water has been added to the coolant, have a 1. Coolant drain bolt Yamaha dealer check the anti- 2. Gasket freeze content of the coolant as soon as possible, otherwise the 5. Remove the coolant reservoir cov-...
  • Page 82 Periodic maintenance and adjustment er A by removing the bolts and reservoir cap, and then turn the quick fastener. coolant reservoir upside down to empty it. 6. Remove the coolant reservoir cov- er B and coolant reservoir by re- moving the bolts. 1.
  • Page 83 19. Start the engine, and then check 10 N·m (1.0 kgf·m, 7.2 lb·ft) the vehicle for coolant leakage. If coolant is leaking, have a Yamaha 11. Pour the specified amount of the dealer check the cooling system. recommended coolant into the ra- diator and coolant reservoir.

  • Page 84: Air Filter Element

    Check the engine idling speed and, if Measure the throttle grip free play as maintenance and lubrication chart. necessary, have it corrected by a shown. Have a Yamaha dealer replace the air Yamaha dealer. filter element. Engine idling speed: 1200–1400 r/min 1.

  • Page 85: Valve Clearance

    Therefore, it 170 kg (375 lb) must be adjusted by a Yamaha dealer is essential to maintain the tires in good * Total weight of rider, passenger, car- at the intervals specified in the periodic...
  • Page 86 WARNING has a nail or glass fragments in it, or if in” for it to develop its optimal  the sidewall is cracked, have a Yamaha characteristics. The front and rear tires should dealer replace the tire immediately. be of the same make and de-...

  • Page 87: Cast Wheels

    If any  Manufacturer/model: Always adjust the tire air pres- BRIDGESTONE/BATTLAX HY- damage is found, have a Yamaha sure according to the operating PERSPORT S20R dealer replace the wheel. Do not conditions. FRONT and REAR:...

  • Page 88: Adjusting The Clutch Lever Free Play

    There should be no free play at the 1. Clutch lever free play (b). brake lever end. If there is free play, 2. Clutch lever free play adjusting bolt have a Yamaha dealer inspect the brake system. Clutch lever free play: EWA14212 5.0–10.0 mm (0.20–0.39 in)

  • Page 89: Brake Light Switches

    The front and rear brake pads must be come on just before braking takes ef- checked for wear at the intervals spec- fect. If necessary, have a Yamaha deal- ified in the periodic maintenance and er adjust the brake light switches.

  • Page 90: Checking The Brake Fluid Level

    Periodic maintenance and adjustment touches the brake disc, have a Yamaha EAU22582 Rear brake Checking the brake fluid level dealer replace the brake pads as a set. Before riding, check that the brake fluid is above the minimum level mark.

  • Page 91: Changing The Brake Fluid

    EAU22733 EAU22762 Changing the brake fluid Drive chain slack age. Have a Yamaha dealer change the The drive chain slack should be  Refill with the same type of brake fluid at the intervals specified in checked before each ride and adjusted brake fluid.
  • Page 92 [ECA10572] ers are in the same position, the drive chain slack is correct, and EAU74260 To adjust the drive chain slack the drive chain moves smoothly. Consult a Yamaha dealer before ad- justing the drive chain slack. 8-25...

  • Page 93: Cleaning And Lubricating The Drive Chain

    If a cable is damaged wet areas. Service the drive chain as or does not move smoothly, have a follows. Yamaha dealer check or replace it. ECA10584 WARNING! Damage to the outer NOTICE housing of cables may result in in-...

  • Page 94: Checking And Lubricating The Throttle Grip And Cable

    In addi- pedals should be checked before each tion, the cable should be lubricated by a ride, and the pedal pivots should be lu- Yamaha dealer at the intervals speci- bricated if necessary. fied in the periodic maintenance chart. Brake pedal The throttle cable is equipped with a rubber cover.

  • Page 95: Checking And Lubricating The Brake And Clutch Levers

    EWA10732 WARNING If the sidestand does not move up and down smoothly, have a Yamaha dealer check or repair it. Otherwise, the sidestand could contact the ground and distract the operator, re- sulting in a possible loss of control.

  • Page 96: Lubricating The Swingarm Pivots

    The swingarm pivots must be lubricat- fork does not operate smoothly, face and hold it in an upright posi- ed by a Yamaha dealer at the intervals have a Yamaha dealer check or re- tion. WARNING! To avoid injury, specified in the periodic maintenance pair it.

  • Page 97: Checking The Steering

    If any free (See page 5-32.) smoothly, have a Yamaha dealer check play can be felt, have a Yamaha This model is equipped with a VRLA the wheel bearings. dealer check or repair the steering.
  • Page 98 To charge the battery necessary. Have a Yamaha dealer charge the bat- 3. Fully charge the battery before in- tery as soon as possible if it seems to stallation. NOTICE: When install- have discharged.

  • Page 99: Replacing The Fuses

    Periodic maintenance and adjustment EAU73993 Replacing the fuses The main fuse and ABS motor fuse are located under seat. (See page 5-32.) 1. Starter relay cover 1. Quick fastener 2. Left side panel A The fuse boxes, which contain the fus- es for the individual circuits, are located behind the left side panels.
  • Page 100 Periodic maintenance and adjustment el B off. 1. Ignition fuse 1. ABS solenoid fuse 2. Signaling system fuse 2. Fuel injection system fuse 1. Left side panel B 3. ABS ECU fuse 3. Electronic throttle valve fuse 2. Washer 3. Bolt 4.
  • Page 101 Main fuse: check if the device operates. 50.0 A Terminal fuse 1: 4. If the fuse immediately blows 2.0 A again, have a Yamaha dealer Headlight fuse: check the electrical system. 10.0 A Signaling system fuse: 7.5 A Ignition fuse: 15.0 A...

  • Page 102: Vehicle Lights

    1. Headlight 1. Maintenance stand (example) self. However, should your motorcycle 2. Auxiliary light require any repair, take it to a Yamaha Since this model is not equipped with a dealer, whose skilled technicians have This model is equipped with full-LED...
  • Page 103 Periodic maintenance and adjustment heaters or furnaces. Gasoline or gasoline vapors can ignite or ex- plode, causing severe injury or property damage. 8-36...

  • Page 104: Troubleshooting Charts

    Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the compression. 4. Compression The engine does not start. There is compression.
  • Page 105 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended coolant as soon as possible.

  • Page 106: Motorcycle Care And Storage

    Rust and corrosion can develop matte colored finished parts. Be Cleaning even if high-quality components are sure to consult a Yamaha dealer for ECA24070 NOTICE used. A rusty exhaust pipe may go un- advice on what products to use be- noticed on a car, however, it detracts fore cleaning the vehicle.
  • Page 107 Motorcycle care and storage sure to rinse off any detergent and then rinse thoroughly with clean nium muffler) to prevent corrosion. residue using plenty of water, as water. Use a toothbrush or bottlebrush it is harmful to plastic parts. for hard-to-reach areas. Stubborn dirt Cleaning the titanium muffler ...
  • Page 108 8. Let the motorcycle dry completely before storing or covering it. EWA11132  Consult a Yamaha dealer for ad- WARNING vice on what products to use. Contaminants on the brakes or tires  Washing, rainy weather or humid can cause loss of control.

  • Page 109: Storage

    Motorcycle care and storage EAU26183 2. Fill up the fuel tank and add fuel spark plug caps. Storage stabilizer (if available) to prevent 4. Lubricate all control cables and the the fuel tank from rusting and the pivoting points of all levers and Short-term fuel from deteriorating.

  • Page 110: Specifications

    Specifications Dimensions: EAU70621 Compression ratio: Fuel tank capacity: 12.0 : 1 17 L (4.5 US gal, 3.7 Imp.gal) Overall length: Starting system: Fuel reserve amount: 2095 mm (82.5 in) Electric starter 4.0 L (1.06 US gal, 0.88 Imp.gal) Overall width: Lubrication system: Fuel injection: 800 mm (31.5 in)
  • Page 111 Specifications 5th: Tire air pressure (measured on cold Wheel travel: 1.381 (29/21) 120 mm (4.7 in) tires): 6th: Rear suspension: Front: 1.250 (30/24) Type: 250 kPa (2.50 kgf/cm , 36 psi) Chassis: Swingarm (link suspension) Rear: Frame type: Spring: 290 kPa (2.90 kgf/cm , 42 psi) Diamond Coil spring...
  • Page 112 Specifications License plate light: Terminal fuse 1: 2.0 A Meter lighting: Headlight fuse: 10.0 A Neutral indicator light: Brake light fuse: 1.0 A High beam indicator light: Signaling system fuse: 7.5 A Turn signal indicator light: Ignition fuse: 15.0 A Oil pressure and coolant temperature warning Radiator fan motor fuse: light:...

  • Page 113: Consumer Information

    These identification numbers are needed when registering the vehicle with the authorities in your area and when ordering spare parts from a Yamaha dealer. VEHICLE IDENTIFICATION NUM- 1. Vehicle identification number 1. Engine serial number...

  • Page 114: Diagnostic Connector

    Fuel-injection and emission-relat- space provided. This information will be ed data needed when ordering spare parts from a Yamaha dealer. Yamaha will not disclose this data to a third party except:  With the consent of the vehicle owner ...

  • Page 115: Motorcycle Noise Regulation (For Australia)

    Consumer information EAU26571 Motorcycle noise regulation (for Australia) TAMPERING WITH NOISE CON- TROL SYSTEM PROHIBITED: Owners are warned that the law may prohibit:  The removal or rendering inopera- tive by any person other than for purposes of maintenance, repair or replacement, of any device or element of design incorporated into any new vehicle for the pur-...

  • Page 116: Index

    Index Drive chain slack ........8-24 Luggage strap holders ......5-35 ABS............5-28 ABS warning light........5-6 Engine break-in ........7-3 Main switch/steering lock ......5-2 Air filter element ........8-17 Engine idling speed, checking ....8-17 Maintenance and lubrication, periodic..8-5 Auxiliary DC jack........5-36 Engine oil and oil filter cartridge ...
  • Page 117 Troubleshooting charts ......8-37 Turn signal indicator lights ...... 5-6 Turn signal switch........5-4 Valve clearance ........8-18 Vehicle identification number....11-1 Vehicle lights ........8-35 Wheel bearings, checking ....8-30 Wheels..........8-20 YRC settings......... 5-14 YRC (Yamaha Ride Control) ....4-1 12-2...
