30-51 30/1-58-56%: -- Starting switch ~ battery charge warning light - tron':
parking lights ~ dashboard light - number plate and
. tailtghts ~ two-pole socket — 100 mm dia. tloocllight
with built in switch - passing lights.
— position 3:
£51-56a 3611-58 -— Starting switch — battery charge warning light - front
parking lights — dashboard light - number plate and
tailights - two~pole socket - 100 mm die. tloodiight
with built-in switch - driving lights.
- position 41
The key can be removed when at position 0 onéy.
Starter switch.
The starting switch operation is dependent upon the position of the combination lighting and starting
switch.
Each position of the iever on the switch corresponds to a circuit, and precisely:
~— position £1: 15/54 —— All equipment off.
~— position 't: §5;'54-19 —— Glow plugs.
~— position 2: 15,r'54-'E9-filla - Glow plugs - starting.
The lever returns automatically to position 0 from levers 1 and 2.
Fuses.
The equipment belonging to the electrical system is protected by tour 8 A fuses contained in a box pieced
near the dashboard and by two other tuses. I
— Fuse 54,3 protects: L. H. side front parking light - R. H. side taliight ~ 100 mm die. tloocilight
with built~irr switch.
— Fuse SUEZ protects: Driving lights.
-— Fuse 301'? protects: Passing lights.
— Fuse 54,"2 protects:
plate light ~ two-pole socket.
protects the control box;
protects the electric horn (optional).
—~ Other fuses 1:
The generator with spy-light, the starter and the glow plug circuits are without fuse protection.
Find the cause ot fuse failure prior to repiacing a fuse.
B2
R. H. side tront parking light - dashboard light - L. H. tailight and number
