600 EDGE RMK
MODEL: . . . . . . . . . .
MODEL NUMBER: . S02NJ6ES
ENGINE MODEL: . . S2187- -6044PL6E
ELECTRICAL
Flywheel I.D. . . . . . . 4010629
CDI Marking . . . . . . . 4010554
Alternator Output . . . 280 Watts
Ignition Timing . . . . . 24_@3500RPM±500°
With TPS Unplugged.
.1350² BTDC
3.43mm BTDC
Spark Plug / Gap . . . Champion RN57YCC / 0.025² (0.64mm)
Voltage Regulator . . T1
Electric Start . . . . . . . Option
Magneto Pulses . . . . 6
SUSPENSION / CHASSIS
Body Style . . . . . . . . EDGE RMK
Front Suspension . . EDGE RMK
Front Shocks . . . . . . Nitrex
IFS Spring Rate . . . . 100#/in.
Front Spring Preload 3/4² Thread Adjust
Front Vertical Travel 7.2² - 7.6² (18.3 - 19.3cm)
Rear Suspension . . . EDGE RMK
Rear Axle Travel . . . 13.8² (35cm)
Front Track Shock . . Nitrex
Spring Rate . . . . . . . . 170#/in.
Rear Track Shock . . Indy Select
Rear Springs . . . . . . .375² (sq.) / 77°
Track Type . . . . . . . . 15²x136²x1.75² (38.1x345.44x4.45cm)
Track Tension . . . . . . 3/8² - 1/2² (1-1.3 cm) slack with 10# (4.54kg) weight 16² (40.64cm) ahead of rear idler
shaft.
Overall Snowmobile Length
Overall Snowmobile Height
Maximum Snowmobile Width
OPTIONAL REAR TORSION SPRINGS
SOFT
--
N/A
N/A
.347² ² ² ² (Sq.) Diameter x 47° ° ° ° .359² ² ² ² (Sq.) Diameter x 47° ° ° ° .375² ² ² ² (Sq.) Diameter x 47° ° ° °
L.H.(144"/151")
7042081--067
R.H.(144"/151")
7042082--067
. . . . . . . . . . . . . . . . . 102.5² (306cm)
. . . . . . . . . . . . . . . . . 47.5² (120.7cm)
. . . . . . . . . . . . . . . 47.25² (120cm)
(STD)
.347² ² ² ² (Sq.) Diameter x 77° ° ° ° .359² ² ² ² (Sq.) Diameter x 77° ° ° °
L.H.(136" ) 7041627--067
R.H.(136") 7041628--067
L.H.(144"/151")
7042068--067
R.H.(144"/151")
7042069--067
GENERAL INFORMATION
CAPACITIES
Fuel Tank . . . . . . . . . . 11.8 gallons (44.7 liters)
Oil Tank . . . . . . . . . . . . 3.25 quarts (3.07 liters)
Coolant . . . . . . . . . . . . 4.3 quarts (4.07 liters)
Chaincase Oil . . . . . . . 11 fl. oz.(325cc)
CHAINCASE
Sprockets / Chain . . . 19-39 72P HYVO
Reverse . . . . . . . . . . . . Option
Brake Pads . . . . . . . . . Type 81, Large
Chaincase Center Dist.7.92² (20.12cm)
Driveshaft Sprockets . 2 Drivers Wide, XHS
Brake Type . . . . . . . . . Polaris HPB Liquid Cooled
FIRM
L.H.(136") 7041629--067
R.H.(136") 7041630--067
L.H.(144"/151")
7042079--067
R.H.(144"/151")
7042080--067
1.21
