INDY 500 RMK
MODEL: . . . . . . . . . .
MODEL NUMBER: . S02SR5AS
ENGINE MODEL: . . S2186- -5044PL5A
ELECTRICAL
Flywheel I.D. . . . . . . Kokusan 4060223
CDI Marking . . . . . . . 4010259
Alternator Output . . . 280 Watts
Ignition Timing . . . . . 22° BTDC@3000RPM±1.5°
0.1139² BTDC (±0.0175²)
2.8927mm BTDC (±0.48mm)
Spark Plug / Gap . . . Champion RN2C / 0.025² (0.64mm)
Voltage Regulator . . LR7
Electric Start . . . . . . . Option
LR7= Full wave voltage regulator
Magneto Pulses . . . . 6
SUSPENSION / CHASSIS
Body Style . . . . . . . . Gen II
Front Suspension . . Indy X-10 38² CRC
Front Shocks . . . . . . Nitrogen Cell
IFS Spring Rate . . . . 100#/in.
Front Spring Preload 1/8² Thread Adjust
Front Vertical Travel 8.05 in.(21cm)
Rear Suspension . . . XTRA-Lite 136²
Rear Axle Travel . . . 12² (30.5cm)
Front Track Shock . . Nitrogen Cell
Spring Rate . . . . . . . . 200#/in. variable
Rear Track Shock . . Indy Select
Rear Springs . . . . . . .347² (sq.) / 77°
Track Type . . . . . . . . 15²x136²x1.5² (38.1x345.44x3.81cm)
Track Tension . . . . . . 3/8² - 1/2² (1-1.3 cm) slack with 10# (4.54kg) weight 16² (40.64cm) ahead of rear idler
shaft.
Overall Snowmobile Length
Overall Snowmobile Height
Maximum Snowmobile Width
OPTIONAL REAR TORSION SPRINGS
(STD)
.347²(Sq.) Diameter x 77°
L.H. 7041627--067
R.H 7041628--067
. . . . . . . . . . . . . . . . . 116² (295cm)
. . . . . . . . . . . . . . . . . 45² (114cm)
. . . . . . . . . . . . . . . 43.5² (110.4cm)
FIRM
.375" (Sq.) Diameter x 77_ _ _ _
L.H. 7041631--067
R.H. 7041632--067
GENERAL INFORMATION
CAPACITIES
Fuel Tank . . . . . . . . . . 11.8 gallons (44.7 liters)
Oil Tank . . . . . . . . . . . . 3 quarts (2.8 liters)
Coolant . . . . . . . . . . . . 5 quarts (4.7 liters)
Chaincase Oil . . . . . . . 9 fl. oz.(266cc)
CHAINCASE
Sprockets / Chain . . . 18-41, 68P HYVO
Reverse . . . . . . . . . . . . Option
Brake Pads . . . . . . . . . Type 81, Large
Chaincase Center Dist.7.05² (17.91cm)
Driveshaft Sprockets . 2 Drivers Wide
Brake Type . . . . . . . . . Polaris HPB
