INDY 500 SKS EUROPEAN
MODEL: . . . . . . . . . .
MODEL NUMBER: . E02SS5AE
ENGINE MODEL: . . S2209- -5044PL5A
ELECTRICAL
Flywheel I.D. . . . . . . 4010523
CDI Marking . . . . . . . 4010584
Alternator Output . . . 280 Watts
Ignition Timing . . . . . 12° BTDC@22500 RPM
0.0327² BTDC
0.8294mm BTDC
Spark Plug / Gap . . . Champion RN2C / 0.028² (0.7mm)
Voltage Regulator . . LR7
Electric Start . . . . . . . Option
LR7= Full wave voltage regulator
Magneto Pulses . . . . 6
SUSPENSION / CHASSIS
Body Style . . . . . . . . Gen II
Front Suspension . . Indy XC 10
Front Shocks . . . . . . Indy Select
IFS Spring Rate . . . . 100#/in.
Front Spring Preload 3/4² Thread Adjust
Front Vertical Travel 9.6² (24.4cm)
Rear Suspension . . . XTRA-10 EURO
Rear Axle Travel . . . 9.5² (24.1cc)
Front Track Shock . . Nitrogen Cell
Spring Rate . . . . . . . . 190#/in. variable
Rear Track Shock . . Indy Select
Rear Springs . . . . . . .405² (sq.) / 77°
Track Type . . . . . . . . 15²x136²x1.25² (38.1x345.44x3.175cm)
Track Tension . . . . . . 3/8² - 1/2² (1-1.3 cm) slack with 10# (4.54kg) weight 16² (40.64cm) ahead of rear idler
shaft.
Overall Snowmobile Length
Overall Snowmobile Height
Maximum Snowmobile Width
OPTIONAL REAR TORSION SPRINGS
(STD)
.405²(Sq.) Diameter x 77°
L.H. 7041655--067
R.H 7041655--067
. . . . . . . . . . . . . . . . . 116² (295cm)
. . . . . . . . . . . . . . . . . 45² (114cm)
. . . . . . . . . . . . . . . 43.5² (110.5cm)
GENERAL INFORMATION
CAPACITIES
Fuel Tank . . . . . . . . . . 11.8 gallons (44.7 liters)
Oil Tank . . . . . . . . . . . . 3 quarts (2.8 liters)
Coolant . . . . . . . . . . . . 5 quarts (4.7 liters)
Chaincase Oil . . . . . . . 11 fl. oz. (325cc)
CHAINCASE
Sprockets / Chain . . . 18-41, 68P HYVO
Reverse . . . . . . . . . . . . Option
Brake Pads . . . . . . . . . Type 81, Large
Chaincase Center Dist.7.05² (17.91cm)
Driveshaft Sprockets . 2 Drivers Wide
Brake Type . . . . . . . . . Polaris HPB
