ACS: Alternator control switch.
ACV: Alternating current voltage.
Air Gap Spark Test: A good check for ignition voltage and general ignition system condition. Spark should arc 3/8" (1
cm) minimum from end of high tension lead to ground. Several testers are available commercially.
Alternator: Electrical generator producing alternating current voltage.
Bore: Diameter of cylinder.
BTDC: Before Top Dead Center.
Bump Steer: When skis toe in and toe out through suspension travel.
CDI: Capacitor Discharge Ignition. Ignition system which stores voltage generated by the stator plate exciter coil in a
capacitor or condenser (in CDI box). At the proper moment a voltage generated by the stator plate pulser coil closes an
electronic switch (thyristor) in the CDI box and allows the voltage in the capacitor to discharge into the primary windings
of the ignition coil.
Center Cylinder: On three cylinder engines, the cylinder between Mag and PTO ends.
Center Distance: Distance between center of crankshaft and center of driven clutch shaft.
Chain Pitch: Distance between chain link pins (No. 35 = 3/8" or 1 cm). Polaris measures chain length in number of
pitches.
Clutch Buttons: Plastic bushings which transmit rotation of the clutch to the movable sheave in the drive and driven
clutch.
Clutch Offset: Drive and driven clutches are offset so that drive belt will stay nearly straight as it moves along the clutch
face as the engine torques back.
Clutch Weights: Three levers in the drive clutch which relative to their weight, profile and engine RPM cause the drive
clutch to close.
Coil: A winding of wire around an iron core which has the ability to generate an electrical current when a magnetic field
passes through it.
Combustion Chamber: Space between cylinder head and piston dome at TDC.
Compression: Reduction in volume or squeezing of a gas.
Condenser/Capacitor: A storage reservoir for electricity, used in both E.T. and CDI systems.
Crankshaft Run-Out: Run-out or "bend" of crankshaft measured with a dial indicator while crankshaft is supported
between centers on V blocks or resting in lower half of crankcase. Measure at various points especially at PTO.
Maximum allowable run-out is .006" (.02 cm).
DCV: Direct current voltage.
Detonation: The spontaneous ignition of the unburned fuel/air mixture after normal spark ignition. Piston looks
"hammered" through, rough appearance around hole. Possible causes: 1) lean fuel/air mixture; 2) low octane fuel; 3)
over-advanced ignition timing; 4)compression ratio too high for the fuel octane.
Dial Bore Gauge: A cylinder measuring instrument which uses a dial indicator. Good for showing taper and
out-of-round in the cylinder bore.
Displacement: The volume of the cylinder displaced by
the piston as it travels from BDC to TDC. The formula is:
Effective Compression Ratio: Compression ratio measured from after the piston closes the exhaust port.
Electrical Open: Open circuit. An electrical circuit which isn't complete. (i.e. poor connections or broken wire at hi-lo
beam switch resulting in loss of headlights.
Electrical Short: Short circuit. An electrical circuit which is completed before the current reaches the intended
component. (i.e. a bare wire touching the snowmobile chassis under the seat resulting in loss of taillights and brake
lights).
End Seals: Rubber seals at each end of the crankshaft.
Engagement RPM: Engine RPM at which the drive clutch engages to make contact with the drive belt.
Flat Head Bolt: To be used where finished surfaces require a flush fastening unit. Countersunk.
Foot Pound: Ft. lb. A force of one pound at the end of a lever one foot in length, applied in a rotational direction.
g: Gram. Unit of weight in the metric system.
Head Volume: Cylinder head capacity in cc, head removed from engine with spark plug installed.
GENERAL INFORMATION
2
Bore x Stroke x 3.1416
4
= Displacement in
CCs
1.9
