WHAT'S ON THE DISPLAY

The Humminbird® VHF55S uses an LCD display, together with an 8-button keypad, to control all
user functions. The figure shows a typical view you might see on the display at initial power-up.
Stored icon [diskette]
Receiving icon [BUSY]
Transmit on [TX]
Low power transmit icon
[LO]
High power transmit icon
[HI]
Priority channel icon [P]
Scan mode icon [SCAN]
Signal power level icon
Keys locked icon [key]
5 5
Canadian band icon [C]
International band icon [I]
U.S. band icon [U]
Channel number [88]
Weather station alarm [A]
Weather station icon [WX]
Memory channel icon [M]
Dual Watch icon [DU]
Tri Watch icon [TRI]
Receive Only icon [B]
Battery Level icon
Duplex (Receive and
Transmit on same
channel) icon [A]
